Release Notes and Installation Guide
Version: 1.00.05 SP5 (build 12863)
SERVICE PACK 5
SOMO® 655

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOMO 655 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Socket SOMO 655

Summary of Contents for Socket SOMO 655

  • Page 1 SERVICE PACK 5 SOMO® 655 Release Notes and Installation Guide Version: 1.00.05 SP5 (build 12863)

  • Page 2: Copyright Notice

    Other than the above, Socket Mobile can assume no responsibility for anything resulting from the application of information contained in this manual. Please refrain from any applications of the SoMo 655 that are not described in this manual. Please refrain from disassembling the SoMo 655. Disassembly of this device will void the product warranty.

  • Page 3: Release Notes

    Connect the SoMo to an Ethernet jack on your wired network. 4. Go Wi-Fi! a. Updated Redpine Signals Driver (v3.2.12, Socket Mobile’s v1.77). b. Eliminated potential data transfer cessation for environments in which AP Beacon interval is greater than 100 milliseconds.

  • Page 4: Check The Sp Version Of Your Unit

    To download the latest Service Pack (SP), please log into your Support account at http://support.socketmobile.com/ and click the green arrow To check the SP version on your unit, see instructions below. Check the SP Version of Your Unit. From the Start screen, tap on Settings | System | System Info. Tap on OS Version to view information.
  • Page 5 STEP 2: Back up Data on the Device If you have any data on the SoMo 655, please back it up to an external location before you run the update. STEP 3: Transfer Files using a Memory Card...
  • Page 6 5. While holding the button, use the stylus to gently press the Reset button on the back of your SoMo 655. Keep holding the Right Programmable Application button. 6. An EBOOT screen will appear with a timer, counting down from 5 seconds.
  • Page 7 10. The Windows Welcome wizard will prompt you to set up Windows Mobile. Follow the instructions on your screen. 11. After setting up Windows Embedded Handheld, the Today screen will appear, and the SoMo 655 will be ready to use.

  • Page 8: Enroll Certificate

    Go Wi-Fi! Advanced Features The features described in this appendix are for ADVANCED USERS ONLY. For software setup instructions, please refer to Chapter 2. For basic connection instructions, please refer to Chapter 4. View IP Addresses You can only view IP address data if the SoMo is actively connected to a WLAN network. 12.

  • Page 9: Manage Certificates

    Manage Certificates 14. In the main screen of Go Wi-Fi!, tap Menu | Certificates | Certificates. Use the utility to manage your root, personal and intermediate authentication certificates. To view a certificate, tap and hold the stylus on a certificate in the list. In the pop-up menu, tap View.

  • Page 10: Statistical Graphs And Tables

    Ping 18. In the main screen of Go Wi-Fi!, tap Menu | Ping. 19. Tap Menu | Configure. Enter the appropriate settings and tap OK. 20. Tap Start. To end the test, tap Stop. A prompt will report the statistics. Tap ok. Statistical Graphs and Tables 21.

  • Page 11: Manage Profiles

    Manage Profiles The Manage Profiles screen displays the configured networks (i.e., profiles) and allows you to rank the networks in order of priority for connection attempts. In the main screen of Go Wi- Fi!, tap and hold the stylus on the radio tower icon. In the pop-up menu, tap Manage Profiles. Alternatively, tap Menu | Settings | Manage Profiles.

  • Page 12: Power Save

    Power Save 24. In the main screen of Go Wi-Fi!, tap Menu | Settings | Power Save. For automatic power management, check the box Manage the radio power automatically. This will enable best performance when charging and best power savings when running on battery power.
  • Page 13 In the main screen of Go Wi-Fi! , tap Menu | Settings | Diagnostics. When the user dismisses (exits) the Diagnostic screen, a pop-up will appear stating “Saved WLAN Driver Stats in <file_name.txt>”. The screen content and this text file is for Socket Mobile technical support only and not for use by the end user.
  • Page 14 Logging In the main screen of Go WiFi!, tap Menu | Settings | Logging. The log files can be sent to Socket Mobile technical support to troubleshoot connection issues.
