- Page 1 4 Le Pas du Château 85670 SAINT PAUL MONT PENIT TEL : +33 (0)2 51 98 55 64 FAX : +33 (0)2 51 98 59 07 Email : info@medicatlantic.fr Site Internet : http://www.winncare.fr USER’S MANUAL SHOWER-TROLLEY C4300 2017_09_01 580122 Anglais...
- Page 2 As a result, maintenance of the contracted good’s warranty depends on compliance with the conditions for use recommended by WINNCARE and the use of original accessories, which also guarantees you safe use of the product and its accessories.
- Page 3 2. STORAGE The shower-trolley must be stored in room at 5–40° C with the same requirements as for transport. 3. ASSEMBLY CONDITIONS 3.1. Set-up Remove the protective packaging, tapes and hoops. 3.2. Installing accessories 3.2.1. Clothes basket The clothes basket is positioned under the head of the trolley. 4.
- Page 4 4.3. Technical caracteristics Jack of variable height: COMPACT M5 10000 N 4.4. Mechanical and dimensional caracteristics Normal working load: 170kg (or 26½ stones) (patient + water: 155 kg ; accessories: 15kg) Maximum load lifted: 250kg (or 39½ stones) Weight of shower-trolley: 79kg (or 12½ stones) Height: 520mm / 875mm (1'8½"...
- Page 5 4.5.2. Central braking (optional) When the trolley does not need to be moved, apply the brakes by stepping on the pedal at the foot of the stretcher. (position 1) Check that the wheels are locked by trying to move the trolley. You have two more positions: the free-wheel position (2) and the directional wheel position (3).
- Page 6 If you use different types of medical equipment, you must carry out a risk analysis and make a CE declaration. Use only parts and accessories supplied by WINNCARE in order to ensure safety and keep the product in line with regulations.
- Page 7 5.2. Technical maintenance The medical equipment must be carefully examined at least once a year for safety. A visual check must be made of the wheels with brakes, the height adjustment and all screws and parts either holding the equipment together or allowing movement. 5.3.
