Valcom PagePac PAGEPAL V-5335700 Quick Start Manual page 5

Terminal Block Connector
This is a 20 Pin lugless-type terminal block
located at J2 (See Figure 1). See Table 1 for con-
tact descriptions.
Factory Test Connector Wall Plug Transformer
J3 - No user connections 115 VAC, 60 Hz, U.L.
and CSA Listed.
Night Bell is not active when it is
intended to be activated with a low
AC or DC voltage.
Night Bell is not active when it is
intended to be activated with a
Ring voltage.
Technical Manuals Online! - http://www.tech-man.com Technical Manuals Online! - http://www.tech-man.com
Table 2. RJ-11 Pinout
Pin Number
1 Not Used.
2 C1 control input for Dry Loop (Page Port) activation by
closure (may also be used for Ground Start grounding
point).
3 Ring (– polarity is important for Ground Start).
4 Tip (+ polarity is important for Ground Start).
5 C control input for Dry Loop (Page Port) activation by
contact closure.
6 Not Used.
Table 3. Troubleshooting Suggestions
Problem
The input voltage level is too low or missing. (Minimum 10
VAC)
Make sure that the input connections are to pins 18 and 19
of J2 (polarity is important).
A higher priority in the PagePal
Check the MAIN OUTPUT volume control setting.
The input voltage level is too low or missing. (Minimum 40
VAC)
Make sure that the input connections are to pins 19 and 20
of J2.
A higher priority in the PagePal is active.
Check the MAIN OUTPUT volume control setting.
firealarmresources.com
Description
Troubleshooting Steps
®
is active.
5 947170
