Redbusbar SmokeSight Quick Start Manual

Residential smoke alarm
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Part Number: SS10MANN
Description:
240 VAC Mains Power Photoelectric Smoke Alarm with 2xAA 1.5VDC Battery Backup
PLEASE LEAVE THESE INSTRUCTIONS WITH THE OCCUPANT, TO BE RETAINED FOR THE LIFE OF THE ALARM.
THIS SMOKE ALARM MUST BE INSTALLED BY A LICENSED ELECTRICIAN.
1
Read all Instructions before Installation and Operation
Regular testing of this smoke alarm is necessary to ensure the unit is functional and that the battery is in good
condition. It is recommended that the smoke alarm be replaced after 10 years of normal service. The only user-
serviceable parts are the replaceable backup batteries. Refer to 'Replacing the Backup Batteries'.
RISK OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
• This product must only be installed and serviced by
appropriately qualified and/or licenced electrical
personnel.
• This product must only be used for the purpose
described in these instructions and must be installed in
accordance with the local regulations.
• Hazardous voltages may be present at wires
connected to this product.
• Before working on this product, isolate the electrical
supply.
• Ensure that the product has been correctly installed
and tested for safe operation before reconnecting the
electrical supply.
Failure to comply with these instructions may result in
death or serious injury.
Smoke Alarm – Top View
SmokeSight SS10MANN V0.6
SmokeSight Residential Smoke Alarm
1. Mains (Green) LED
2. Alarm (Red) LED
1
3. Smoke Alarm Backup
2
Battery Holder
By Redbusbar
EQUIPMENT INSTALLATION HAZARD
• This alarm cannot be operated from power derived
from a square wave, modified square wave or modified
sine wave inverter. These inverters are sometimes
used in off grid installations such as solar or wind
power sources. They produce high peak voltages that
will damage the alarm.
• Ensure that the mains supply, active and neutral is
wired to the correct terminals.
• Ensure that green LED is ON when mains supply is on.
• Ensure that red LED is not fast flashing.
• Smoke Test each interlinked alarm. Check to ensure
every interlinked alarm, alarms correctly. If any unit
fails to alarm, check all wiring and connections.
Failure to follow these instructions may result in
equipment damage or injury.
Smoke Alarm – Bottom View
3
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmokeSight and is the answer not in the manual?

Questions and answers

Related Manuals for Redbusbar SmokeSight

Summary of Contents for Redbusbar SmokeSight

  • Page 1 SmokeSight Residential Smoke Alarm By Redbusbar Part Number: SS10MANN Description: 240 VAC Mains Power Photoelectric Smoke Alarm with 2xAA 1.5VDC Battery Backup PLEASE LEAVE THESE INSTRUCTIONS WITH THE OCCUPANT, TO BE RETAINED FOR THE LIFE OF THE ALARM. THIS SMOKE ALARM MUST BE INSTALLED BY A LICENSED ELECTRICIAN.

  • Page 2: Specifications

    In a residential dwelling, mount the smoke alarm in the centre of the ceiling. In mobile homes, wall mount the smoke alarm on an inside partition to avoid the thermal barrier that may form under the ceiling. SmokeSight SS10MANN V0.6 Page 2...

  • Page 3: Locations To Avoid

    Where bugs or insects are present as they may block the openings and prevent an alarm, or may cause false alarms.  Within 1 metre of electrical noise sources, e.g. fluorescent lights, LED lights and fan motors. Electrical noise may cause nuisance alarms. SmokeSight SS10MANN V0.6 Page 3...

  • Page 4: Installation

    • Maximum of 40 interlinked smoke alarms. Alternate smoke alarms (Part# SS10MAMA or SS10LNAN) • Only SmokeSight alarms can be interlinked. may be purchased separately if wired connection is not Failure to follow these instructions may result in possible.

  • Page 5: When The Alarm Sounds

    4. Stay close to the floor if air is smoky. Breathe shallowly through a wet cloth if possible. 5. Once outside, go to your selected meeting place and make sure everyone is there. 6. Call the Fire Brigade from your neighbour’s home - not from yours! SmokeSight SS10MANN V0.6 Page 5...

  • Page 6: Replacing The Backup Battery

    TEST+HUSH BUTTON AFTER BATTERY REPLACEMENT Troubleshooting The SmokeSight smoke alarm constantly monitors its internal functions to maintain your safety. If it is alarming or chirping, note answers to the following questions to diagnose the problem, and your solution: 1. If it’s alarming (3 loud tones repeating every 1.5 seconds), refer to smoke alarm troubleshooting below.
  • Page 7 1. Identify which smoke alarm/s are in alarm state – Look for the alarm/s sounding and with red LED fast flashing. 2. On each smoke alarm in alarm state press the Test+Hush button to silence the alarm 3. Disconnect all smoke alarms in the alarm state by removing them from their base. SmokeSight SS10MANN V0.6 Page 7...
  • Page 8 10 Warranty Redbusbar Pty Ltd, warrants this product to be free from defects in materials and workmanship for a period of 5 (five) years from the date of installation. Refer to the Redbusbar terms of sale for full warranty conditions http://www.redbusbar.com/Terms-and-Conditions.html...
