Manufacturer:
Model Number(s):
Core Module Version:
Comments:
Document Revision Date:
O
S
VERVIEW AND
UPPORTED
The Suite 7.1 surround sound preamplifier provides an RS-232 connection through the ISO-CAT II or
ISO-232 isolation box. This serial connection to the g! system provides full two-way communications,
enabling reliable control as well as providing feedback to the g! system when changes (such as the
current source or volume levels) occur at the receiver.
T
P
HESE
REAMPS SUPPORT THE FOLLOWING FEATURES
Basic Source and Volume Control: Select any available source and control volume with two-way
feedback. Changes made at the preamp (turning the volume control, changing source) are immediately
reflected in the g! interface.
Surround Mode Control: Change the surround mode from the g! interface.
T
P
HESE
REAMPS DO NOT SUPPORT THE FOLLOWING FEATURES
Any feature not specifically noted as supported should be assumed to be unsupported.
I
O
NSTALLATION
VERVIEW
1. During the rough-in phase install the necessary speaker and video cabling for the theater installation.
2. Also during the rough-in phase, run a Cat5 wire from the location of the preamp and isolation box
back to the Network Assembly of the g! system to provide the serial connection needed to control the
preamp. Refer to the RS-232 Connection Options Integration Note for other serial connection
options.
3. Install the speakers, display and other theater components.
4. Program the preamp according to the manufacturer's documentation: see ADA Programming below.
5. Test the theater to ensure that the sources play correctly and that the audio and video operate as
expected.
6. Connect the g! system to the preamp electrically. See the connection diagram for more information.
7. Configure the g! system for the preamp and confirm communication between the preamp and the g!
system controller.
8. Test the system by changing sources and volume to confirm the correct source plays.
ELAN Home Systems ● 1690 Corporate Circle ● Petaluma, CA 94954 USA
tech support: 800.622.3526 • main: 760.710.0990 • sales: 877.289.3526 • email: elan@elanhomesystems.com
©2013 ELAN Home Systems. All rights reserved. ELAN and g! are trademarks of ELAN Home Systems. All other trademarks are the property of their respective owners.
ADA
Suite 7.1
Firmware: Release 4.15, Prom v1.70g, DSP 2.1.5201
1/10/2013
F
EATURES
:
Integration Note
:
Advertisement
Related Manuals for Ada Suite 7.1
Summary of Contents for Ada Suite 7.1
- Page 1 UPPORTED EATURES The Suite 7.1 surround sound preamplifier provides an RS-232 connection through the ISO-CAT II or ISO-232 isolation box. This serial connection to the g! system provides full two-way communications, enabling reliable control as well as providing feedback to the g! system when changes (such as the current source or volume levels) occur at the receiver.
- Page 2 DDRESS TO The ADA preamp must currently be set with a bus address of 0. This can be done using the front panel menu, or using the ADA setup software. Perform the following steps to set the bus address at the front panel (see the ADA documentation for more information): 1.
- Page 3 System RS-232 Controller ADA Bus RS-232 ISO-CAT II or ADA RS-232 Isolation Box ISO-232 DM9M to RJ45 Adapter ATERIALS D e v ic e M a nuf a c t ure r P a rt N um be r...
- Page 4 ONFIGURATION ETAILS The following table provides settings used in the g! Configurator. Please refer to the g! Configurator Reference Guide for more details. “<Select>” Select the appropriate item from the list (or drop-down) in the Configurator. “<User Defined>”, etc. Type in the desired name for the item. Devices Variable Name Setting...
- Page 5 OMMON ISTAKES 5 of 5...
