Atlas Copco LRP 700 VSD+ Instruction Book

Intelligent liquid ring vacuum pumps
Hide thumbs
Table of Contents

Advertisement

Quick Links

Atlas Copco
Intelligent liquid ring
vacuum pumps
LRP 700 VSD+, LRP 900 VSD+,
LRP 1000 VSD+
Instruction Book
1950 8400 02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LRP 700 VSD+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atlas Copco LRP 700 VSD+

Summary of Contents for Atlas Copco LRP 700 VSD+

  • Page 1 Atlas Copco Intelligent liquid ring vacuum pumps LRP 700 VSD+, LRP 900 VSD+, LRP 1000 VSD+ Instruction Book 1950 8400 02...
  • Page 3 Atlas Copco iquid ring vacuum pumps Intelligent l LRP 700 VSD+, LRP 900 VSD+, LRP 1000 VSD+ From Following Serial No. Onwards: CQV 180613725 Instruction book Original instructions Copyright notice Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings.

  • Page 5: Table Of Contents

    Instruction book Table of contents Safety precautions ............................7 Safety icons ..............................7 Safety precautions, general .......................... 7 Safety precautions during installation ......................8 Safety precautions during operation ......................9 Safety precautions during maintenance or repair ..................10 General description........................... 12 Vacuum and flow rate ..........................
  • Page 6 Instruction book Dimension drawings ............................ 73 Installation proposal ............................ 74 Electrical connections ..........................77 Pictographs ..............................79 Service Liquid and cooling water requirement .................... 80 Variants ..............................85 Once through ............................... 85 Tube & shell Heat exchanger ........................87 Weather proof .............................. 88 Operating instructions ..........................

  • Page 7: Safety Precautions

    Instruction book Safety precautions Safety icons Explanation Danger for life Warning Important note Safety precautions, general General precautions 1. The operator must employ safe working practices and observe all related work safety requirements and regulations. 2. If any of the following statements does not comply with the applicable legislation, the stricter of the two shall apply.

  • Page 8: Safety Precautions During Installation

    13. If the ground is not level or can be subject to variable inclination, consult the manufacturer. 14. Ensure compatibility with the working environment. 15. Any vacuum pump placed in an application with inlet gas stream temperatures above the published maximum temperature should be approved by Atlas Copco prior to start-up. 1950 8400 02...

  • Page 9: Safety Precautions During Operation

    Instruction book 16. The maximum cooling water inlet pressure can protect the cooling water system installed of outside the machine. Also consult sections Safety precautions during operation Safety precautions during maintenance or repair. Processing of any other gas requires additional safety precautions typical to the application which are not included herein.

  • Page 10: Safety Precautions During Maintenance Or Repair

    Instruction book Also consult following safety precautions: Safety precautions during operation Safety precautions during maintenance or repair. Processing of any other gas requires additional safety precautions typical to the application which are not included herein. Some precautions are general and cover several machine types and equipment; hence some statements may not apply to your machine.
  • Page 11 Instruction book Also consult following safety precautions: Safety precautions during operation Safety precautions during maintenance. Processing of any other gas requires additional safety precautions typical to the application which are not included herein. Some precautions are general and cover several machine types and equipment; hence some statements may not apply to your machine.

  • Page 12: General Description

    Instruction book General description Vacuum and flow rate A vacuum is any pressure in a system that is below the ambient atmospheric pressure. It can be denoted in absolute terms or in effective (gauge) terms: • mbar(a) – absolute pressure – denotes how much the pressure is above absolute zero vacuum. •...

  • Page 13: Introduction

    The LRP 700 VSD+ up to LRP 1000 VSD+ are single-stage, Liquid ring vacuum pumps driven by an electric motor. The vacuum pumps are controlled by the Atlas Copco Elektronikon® Graphic regulator. The regulator is fitted on top of an electric cabinet comprising transformers, relays, etc.
  • Page 14 Instruction book Open view of LRP vacuum pumps Reference Name Canopy Emergency stop button Elektronikon® controller Customer main power supply Centrifugal pump Spray nozzle Heater exchanger Main motor Discharge separator Liquid ring pump TP-1 Process inlet TP-2 Process exhaust TP-3 Discharge separator make-up TP-4 Discharge separator overflow...

  • Page 15: Flow Diagram

    Instruction book 2.3 Flow diagram Total Recovery flow for LRP VSD+ For the flow diagram for the variants, refer to Variants. Air flow Air comes in through air inlet and is displaced by the liquid ring pump. A mixture of air and liquid goes through process exhaust and flows into the discharge separator. After passing through the air/liquid separator, clean air containing a small amount of liquid is discharged.

  • Page 16: Electrical System

    Instruction book If the vacuum pressure decreases and the motor operates at minimum speed, the regulator stops the motor. When the motor is stopped automatically and the vacuum pressure comes to the set-point, the regulator starts the motor again. Electrical system Electric components The electrical system has following components: Electrical cabinet (typical example)

  • Page 17: Smartbox And Smartlink

    SMARTLINK Service rules out all uncertainties. Scheduling maintenance visits becomes as simple and easy as it should be; the service log book is always just one click away and the online link with Atlas Copco allows to request and quickly receive quotes for spare parts or additional services. •...

  • Page 18: Elektronikon® Graphic Controller

    Instruction book Elektronikon® Graphic controller Elektronikon® Graphic controller Control panel Display of the Elektronikon® Graphic controller Introduction The Elektronikon® controller has following functions: • Controlling the vacuum pump • Protecting the vacuum pump • Monitoring components subject to service • Automatic restart after voltage failure (made inactive) Automatic control of the vacuum pump operation The controller maintains the pressure within programmable limits by automatically adapting the motor speed.
  • Page 19 The regulator has a built-in function to automatically run the vacuum pump for a very short time (~2.5 seconds) if liquid ring pump has been stationary for too long. For vacuum pumps leaving the factory, this function is made inactive. If desired, the function can be activated. Consult the Atlas Copco Customer Center.

  • Page 20: Control Panel

    Instruction book Control panel Elektronikon regulator Elektronikon regulator Reference Designation Function Shows the vacuum pump operating condition and a number of icons to navigate Display through the menu. Pictograph Automatic operation Pictograph General alarm General alarm Flashes if a shut-down warning condition exists. Pictograph Service Service LED...

  • Page 21: Icons Used

    Instruction book Icons used Status icons Name Icon Description When the vacuum pump is stopped, the icon stands still. Stopped/Running When the vacuum pump is running, the icon is rotating. Motor stopped Vacuum pump status Running Purge and Intermediate states Running Vacuum Control Local start/stop Machine control mode...
  • Page 22 Instruction book Name Icon Description Warning Service Service required Value lines display icon Main screen display Chart display icon General icons No communication / network problem Not valid Input icons Icon Description Pressure temperature Digital input Special protection System icons Icon Description Vacuum pump element...
  • Page 23 Instruction book Menu icons Icon Description Inputs Outputs Alarms (Warnings, shutdowns) Counters Test Settings Service Saved data Access key/User password Network Regulation Info General Navigation arrows Icon Description Down 1950 8400 02...

  • Page 24: Main Screen

    Instruction book Main screen Control panel Scroll keys Enter key Escape key Function The Main screen is the screen that is shown automatically when the voltage is switched on and one of the keys is pushed. It is switched off automatically after a few minutes when no keys are pushed. Typically, 5 different main screen views can be chosen: 1.
  • Page 25 Instruction book Text on figures Inlet pressure (ii) Flow (iii) Element outlet (iv) Temperature ES, …… (text varies upon the vacuum pumps actual condition) (vi) Menu • Section A shows information regarding the vacuum pump operation (e.g. the Inlet pressure or the temperature at the vacuum pump outlet).
  • Page 26 Instruction book Chart views Instead of viewing values, it is also possible to view a graph of one of the input signals (see section Inputs menu) in function of the time. When Chart (High Resolution) is selected, the chart shows the variation of the selected input (in this case the pressure) per minute.

  • Page 27: Calling Up Menus

    Instruction book Calling up menus Control panel Scroll keys Enter key Escape key Description When the voltage is switched on, the main screen is shown automatically. • To go to the Menu screen, select Menu, using the Scroll keys • Press the Enter key to select the menu.

  • Page 28: Inputs Menu

    Instruction book that corresponds with the selected icon. • Use the Scroll keys to select an icon. • Press the Escape key to return to the Main screen. Inputs menu Control panel Scroll keys Enter key Escape key Menu icon, inputs Function •...
  • Page 29 Instruction book Menu (ii) Regulation • Using the scroll keys, move the cursor to the inputs icon (see above, section Menu icon) • Press the enter key, a screen similar to the one below appears: Inputs (ii) Inlet pressure (iii) Emergency stop (iv) Liquid level low switch...
  • Page 30 Instruction book The first item in the list is highlighted. In this example, the inlet Pressure is selected (chart icon). To change, press the Enter button again. A pop-up window similar to the one below opens: Press Enter again to remove this input from the chart. Another confirmation pop-up opens: Select Yes to remove or No to quit the current action.

  • Page 31: Outputs Menu

    Instruction book Outputs menu Control panel Menu icon, outputs Function To call up Information regarding the actually measured data and the status of some outputs such as the motor overload protection. Procedure Starting from the Main screen (see Main screen): •...
  • Page 32 Instruction book Outputs (ii) Run enable pump motor (iii) Liquid fill valve (iv) Automatic Operation General warning • The screen shows a list of all output switches and their corresponding icons and readings. • If an input is in warning or shut down, the original icon is replaced by the warning or shut down icon respectively.

  • Page 33: Counters

    Instruction book Counters Control panel Scroll keys Enter key Escape key Menu icon, counters Function To call up: • The running hours • The number of motor starts • The number of hours that the regulator has been powered up •...
  • Page 34 Instruction book Text on figures Menu (ii) Regulation • Using the scroll keys, move the cursor to the counters icon (see above, section Menu icon) • Press the enter key, following screen appears: Text on figures Counters (ii) Running hours (iii) Motor starts VSD 1-20 % rpm in % (the percentage of the time during which the motor speed was between 1...

  • Page 35: Control Mode Selection

    Instruction book Control mode selection Control panel Scroll keys Enter key Escape key Function To select the control mode, i.e. whether the vacuum pump is in local control, remote control or controlled via a local area network (LAN). Procedure Starting from the main screen, go to the Menu screen. Next, use the scroll buttons to go to the regulation icon (ii) and press the enter button: There are 3 possibilities: •...

  • Page 36: Service Menu

    Instruction book After selecting the required regulation mode, press the enter button on the controller to confirm your selection. The new setting is now visible on the main screen. See section Icons used for the meaning of the icons. 3.10 Service menu Control panel Scroll keys Enter key...
  • Page 37 Instruction book Procedure Starting from the Main screen, • Move the cursor to the action button Menu and press the Enter key. Following screen appears: • Using the Scroll keys, move the cursor to the Service icon (see above, section Menu icon). •...
  • Page 38 Instruction book Example for service level (A): The figures at the left are the programmed service intervals. For Service Interval A, the programmed number of running hours is 4000 hours (upper row) and the programmed number of real time hours is 8760 hours, which corresponds to one year (second row).
  • Page 39 Instruction book Modify the value as required using the scroll key and press the Enter key to confirm. Note: Running hours can be modified in steps of 100 hours, real time hours can be modified in steps of one hour. Next Service Text on figures Next service...

  • Page 40: Modifying The Setpoint

    Instruction book 3.11 Modifying the setpoint Control panel Scroll keys Enter key Escape key Menu icon, setpoint Function On vacuum pumps with a frequency converter driven main motor, it is possible to program two different setpoints. This menu is also used to select the active setpoint. Procedure Starting from the Main screen, •...
  • Page 41 Instruction book Text on figures Regulation (ii) setpoint 1 (iii) Indirect stop level 1 (iv) setpoint Indirect stop level 2 (vi) Modify • The screen shows the actual settings. To modify the settings, move the cursor to the action button Modify and press the Enter key. Following screen appears: •...

  • Page 42: Event History Menu

    Instruction book 3.12 Event history menu Control panel Scroll keys Enter key Escape key Menu icon, Event History Function To call up the last shut-down and last emergency stop data. Procedure Starting from the Main screen, • Move the cursor to the action button Menu and press the Enter key. Following screen appears: •...

  • Page 43: Selection Process Type

    Instruction book Example of Event History screen • Scroll through the items to select the desired shut-down or emergency stop event. • Press the Enter key to find the date, time and other data reflecting the status of the vacuum pump when that shut-down or emergency stop occurred.
  • Page 44 Instruction book • Move the cursor to the Setting Button Menu and press the Enter key. Following screen appears: • Move the cursor to the Setting Button Menu and press the Enter key. Following screen appears: • Use the scroll keys to go to select the Process Type button, and press the Modify button. •...

  • Page 45: Modifying General Settings

    Instruction book • If the process is Wet, the valve should be open. • If the process is Dry, the valve should be close. 3.14 Modifying general settings Control panel Scroll keys Enter key Escape key Menu icon, Settings 1950 8400 02...
  • Page 46 Instruction book Function To display and modify a number of settings. Procedure Starting from the Main screen, • Move the cursor to the action button Menu and press the Enter key. Following screen appears: • Next, move the cursor to the Settings icon (see above, section menu icon) using the Scroll keys.

  • Page 47: Liquid Top-Up

    Instruction book Text on figures General (ii) Language used (iii) Time (iv) Date Date format (vi) Modify • To modify, select the Modify button using the Scroll keys and press the Enter key. • A screen similar to the one above is shown, the first item (Language) is highlighted. Use the scroll keys to select the setting to be modified and press the Enter key.

  • Page 48: Regreasing

    Instruction book • Move the cursor to the Regulation Button Menu and press the Enter key. Following screen appears: • Use the scroll keys to go to select the Liquid top-up time button, and press the Modify button. • Use the scroll keys to set the liquid top-up time and press the Enter key to confirm. 3.16 Regreasing Function To call up the regreasing screen.

  • Page 49: Auto-Clean

    Instruction book • Using the scroll keys, move the cursor to the Regreasing icon and push the start button to regrease the system. 3.17 Auto-Clean Description This feature can be enabled in cases where regular refreshing of the service liquid will give optimal results. The LRP VSD+ auto-clean feature relies on the operation of two additional solenoid valves.
  • Page 50 Instruction book Auto mode: This mode is set activated as default. To inactive this function: Starting from the Main screen, • Move the cursor to the action button Menu and press the Enter key. Following screen appears: • Press the Enter key. Then Move the cursor to the Automatic Drain, Following Regulation screen appears: •...
  • Page 51 Instruction book • Press the Enter key. Then Move the cursor to the Drain Cycle time, Following Regulation screen appears: • Use the Up and Down arrow keys or Scroll keys to modify the values of the seconds. Short drain cycle time may cause the increasing of liquid consumption. When this function is activated automatically, controller identifies the status of machine at first: If machine is running or stand-by, the solenoid valve for separator drain is activated for certain drainage period, meanwhile the solenoid valve for water injection is opened to fill the clean water according to the...
  • Page 52 Instruction book • Press the Enter key to select the test. Move the cursor to Manual Drain. Following screen appears: • Press the Enter Key. Following screen appears: • Press the Enter Key. Following screen appears: • Move the cursor to Activated and press the Enter key: The function of manual drain is activated.

  • Page 53: Info Menu

    Except process 2 needs manual operation, all the other actions are programmed. A chemical cleaning agent other than the above ones may be used. Be sure to consult the chemical manufacturer and Atlas Copco in advance. Installation and Maintenance Unchanged from the instructions for the standard LRP VSD+.

  • Page 54: Week Timer Menu

    Move the cursor to the action button Menu and press the Enter key. Following screen appears: • Using the Scroll keys, move the cursor to the Info icon (see above, section Menu icon). • Press the Enter key. The Atlas Copco internet address appears on the screen. 3.19 Week timer menu Control panel Scroll keys...
  • Page 55 Instruction book • To program time-based start/stop commands for the vacuum pump. • To program time-based change-over commands for the net pressure band. • Four different week schemes can be programmed. • A week cycle can be programmed, a week cycle is a sequence of 10 weeks. For each week in the cycle, one of the four programmed week schemes can be chosen.
  • Page 56 Instruction book The first item in this list is highlighted in red. Select the item requested and press the Enter key on the controller to modify. Programming week schemes • Select Week action schemes and press Enter. A new window opens. The first item in the list is highlighted in red.
  • Page 57 Instruction book Monday Actions Remove Start Stop Pressure setpoint 1 Modify • A new window opens. The action is now visible in the first day of the week. Monday Start Save Modify • A pop-up window opens. Use the Scroll keys to modify the values of the hours. Use the Scroll keys to go to the minutes.
  • Page 58 Instruction book Monday Start Save Modify • A new pop-up window opens. Use the Scroll keys on the controller to select the correct actions. Press the Enter key to confirm. Monday Are you sure? Save Modify Press the Escape key to leave this window. •...
  • Page 59 Instruction book A week cycle is a sequence of 10 weeks. For each week in the cycle, one of the four programmed week schemes can be chosen. • Select Week Cycle from the main Week Timer menu list. Week Timer Week Action Schemes Week Cycle Status...
  • Page 60 Instruction book Week Cycle Week 1 Week Action Scheme 1 Week Action Scheme 2 Week Action Scheme 3 Modify • Check the status of the Week Timer Use the Escape key on the controller to go back to the main Week Timer menu. Select the status of the Week Timer.
  • Page 61 Instruction book Week Timer Week Action Schemes Week Cycle Status Remaining Running Time • Press the Escape key on the controller to go to the main Week Timer menu. Select Remaining Running Time from the list and press the Enter key on the controller to Modify. Week Timer Week Action Schemes Week Cycle...

  • Page 62: User Password Menu

    Instruction book 3.20 User password menu Control panel Scroll keys Enter key Escape key Menu icon, Password Function If the password option is activated, it is impossible for not authorized persons to modify any setting. Procedure Starting from the Main screen (see Main screen), •...

  • Page 63: Web Server

    To allow the web server functionality, the network cable that is connected to the SMARTBOX should be unplugged and replaced by the cable of the company network. If both the web server functionality and SMARTBOX are required, please contact your local Atlas Copco Customer Centre for support.
  • Page 64 Instruction book Configure the network card • Go the ‘Network and Sharing Center’: • Click “Change adapter settings”. • Select the Local Area connection which is connected to the controller. • Click with the right button and select properties 1950 8400 02...
  • Page 65 Instruction book • Use the checkbox Internet Protocol version 4 (TCP/IPv4). • To avoid conflicts, uncheck other properties if they are checked. • After selecting TCP/IPv4 click on the properties button to change the settings. • Use the following settings: •...
  • Page 66 Instruction book Configure a company network (LAN) connection • Ask your companies IT responsible or IT department to generate a fixed IP address in your company network. • That IP address will be excluded from the DNS server, so it will be reserved for the Elektronikon Mk5 •...
  • Page 67 Instruction book • Go to ‘Network’ • Go to ‘Ethernet • Switch ‘Off’ the Ethernet communication to allow editing the settings • Adapt IP address • Adapt Gateway address • Adapt Subnet mask • Switch ‘On’ the Ethernet communication again 1950 8400 02...
  • Page 68 Instruction book • Wait some minutes so the LAN network can connect to the Elektronikon Mk5. Configuration of the web server. All screen shorts are indicative. The number of displayed fields depends on the selected. Configure your web interface of the Elektronikon The internal web server is designed and tested for Microsoft®...
  • Page 69 Instruction book On the left site of the interface you can find the navigation menu. If a license for ESi is foreseen, the menu contains 3 buttons. • Compressor: shows all compressor settings. • Es: shows the ESi status if a license is provided. •...
  • Page 70 Instruction book Machine status is always shown on the web interface Digital Inputs Gives an overview of all Digital inputs and status Digital Outputs Shows a list of all the digital outputs and status Special Protections Give an overview of all special protections of the compressor. Service Plan Shows all levels of the service plan and status.

  • Page 71: Programmable Settings

    For specific data, see section Preventive Maintenance. Consult Atlas Copco if a timer setting needs to be changed. The intervals must not exceed the nominal intervals and must coincide logically. See section Modifying general settings. 1950 8400 02...
  • Page 72 Proportional band The settings for the Proportional band and integration time are determined by experiment. and integration time Altering these settings may damage the Vacuum pump. Consult Atlas Copco. 1950 8400 02...

  • Page 73: Installation

    Instruction book Installation Dimension drawings 1950 8400 02...

  • Page 74: Installation Proposal

    Instruction book Installation proposal 1950 8400 02...
  • Page 75 Instruction book Location: Locate the vacuum pump on a level surface that is clean, vibration free, well lit, well ventilated and capable taking the weight of the pump. The entire length of the frame base must be supported. Shim where necessary (do not use wood).
  • Page 76 In this case, consult Atlas Copco. Also, if operating above 1000 m (3300 ft), consult Atlas Copco. Moving/lifting The vacuum pumps can be moved by a lift truck using the slots in the frame. Take care not to damage the bodywork during lifting or transport.

  • Page 77: Electrical Connections

    To use the machine in light industrial, commercial or residential environments with a shared supply network or in an IT network, extra measures can be required: contact Atlas Copco. Electrical connections for LRP 700 VSD+ up to LRP 1000 VSD+...
  • Page 78 Stop the vacuum pump and switch off the voltage before connecting external equipment. Only potential-free contacts are allowed. • LAN control: The vacuum pump is controlled via a local network. Consult Atlas Copco. Vacuum pump status indication The Elektronikon controller is provided with potential-free auxiliary NO contacts (NO = normally open) (K07, K08 and K09) for remote indication of: •...

  • Page 79: Pictographs

    Instruction book Pictographs Pictographs Reference Designation Switch off the voltage and depressurize the vacuum pump before starting maintenance or Repairs Warning, hot surface Stop the vacuum pump before cleaning the coolers Warning, voltage Switch off the voltage and wait at least 10 minutes before maintenance If the rotation direction is wrong, open the isolating switch in the voltage supply line and reverse two incoming electric lines Motor regreasing instruction...

  • Page 80: Service Liquid And Cooling Water Requirement

    Instruction book Service Liquid and cooling water requirement General Cooling water needs to fulfill certain requirements in order to avoid problems of scaling, fouling, corrosion or bacterial growth. In open circuit cooling towers, protective measures must be taken to avoid the growth of harmful bacteria such as legionella pneumophila when there is a risk of inhalation of the water droplets.
  • Page 81 Instruction book 3. Hardness Different types of hardness are in relation with each other and together with the pH and the alkalinity of the water they determine the equilibrium situation of the water, determined and specified by the RSI. In addition, the calcium hardness must be limited to: Ca (ppm Ca CO3) Type of cooling system Standard...
  • Page 82 Instruction book The values of A, B, C and D can be found in below table: Total dissolved Temperature Ca hardness M-Alkalinity solids (mg/l) (°C) (ppm CaCO3) (ppm CaCO3) < 30 0 - 1 09-11 10-11 30 - 320 2 - 6 12-14 12-14 >...
  • Page 83 Instruction book 6. Chlorides (Cl-) Chloride ions will create pitting corrosion on stainless steel. Their concentration should be limited, depending from the RSI value. RSI < 5.5 5.6 < RSI < 6.2 6.3 < RSI < 6.8 6.9 < RSI < 7.5 7.6 <...
  • Page 84 Cpa: specific heat capacity of the additives X: the percentage of additives X: the percentage of additives Maximum flow rate and Actual flow rate is dependent on the application. For cooling liquid temperatures outside this range consult Atlas Copco. 1950 8400 02...

  • Page 85: Variants

    Instruction book Variants The LRP VSD+ is available in several variants designed to meet more specifically the process requirements of industrial vacuum applications. Once through Description This variant can be used for optimal integration with existing water recirculation system, or process contamination, excessive heat loads make internal total water recirculation problematic.
  • Page 86 Instruction book Flow diagram of vacuum pump with once through system Installation Water in (TP-3) is G1 1/4’ female connector. The water supply should have a flow rate no more than 6 m /h, water pressure no less than 1.barg. If the liquid flow is less than the below requirements, the suction capacity may be reduced Liquid flow requirement The service water requirement is same as standard machine (See...

  • Page 87: Tube & Shell Heat Exchanger

    Instruction book Water out (TP-11): Use a suitable glue or gasket as a seal and connect the system drain (3’ female connector; DN80 universal flange as variant) to the drain circuit. Ensure that there is no obstruction in the drain circuit. All the pipes should be independently supported, pipe size must never be less than the respective connection on machine.

  • Page 88: Weather Proof

    Maintenance Unchanged from the instructions for the standard LRP VSD+. Tube & Shell Heat exchanger may need to be cleaned regularly based on application, consult Atlas Copco about how to clean it. Weather proof Description This variant is designed with higher ingress protection rating for outdoor installation. However, additional shelters or protection should still be considered for optimal lifetime and longevity of the pump.

  • Page 89: Operating Instructions

    • Provide labels, warning the operator that: • The vacuum pump may automatically restart after voltage failure and/or for automatic seizure prevention (if activated, consult Atlas Copco). • The vacuum pump is automatically controlled and may be restarted automatically. •...

  • Page 90: Starting

    Instruction book • Check the programmed settings. Consult section Programmable settings. • Check the direction of rotation of main motor and circulation pump, by short start. If the rotation is not correct, change U1 and V1. • Check the liquid level of liquid separator, the system should auto fill the service liquid. •...

  • Page 91: Taking Out Of Operation

    Instruction book Checking the display Check the display (2) regularly for readings and messages. The display normally shows the vacuum pump vacuum pressure, while the status of the vacuum pump is indicated by means of a number of icons. Remedy the trouble if alarm LED (7) is lit or flashes, see section Icons used.

  • Page 92: Maintenance

    For overhauling or carrying out preventive maintenance, service kits are available (see section Service kits). Service contracts Atlas Copco offers several types of service contracts, relieving you of all preventive maintenance work. Consult your Atlas Copco Customer Center. General When servicing, replace all removed O-rings and washers.
  • Page 93 Exposure of the vacuum pump to external pollutants, operation in highly humid environments, low duty cycles may require a shorter service exchange interval. Contact Atlas Copco if in doubt. Keep the grease drains at the bottom of bearing housing unplugged after regreasing. Run the machine at low speed (refer to Elektronikon®...

  • Page 94: Drive Motor

    Low speed running for 1 min is needed after regreasing of motor and liquid ring pump. Important • Always consult Atlas Copco if a timer setting must be changed. • Any leakage should be attended to immediately. Damaged hoses or flexible joints must be replaced.

  • Page 95: Pump

    Instruction book Attention Keep the grease drains unplugged after regreasing. Run the machine at low speed with the function "Regreasing" (refer to Elektronikon® Graphic controller), until it is stopped automatically. Attach the drain plugs in the grease drains. Pump Bearing maintenance Attention Never mix greases of different brands or types.

  • Page 96: Heat Exchanger

    Clean with an air jet in the reverse direction to normal flow. • If it is necessary to wash the coolers with a cleaning agent, consult Atlas Copco. After maintenance on the fan and on the coolers, remove all the loose parts.

  • Page 97: Separator Clean

    Instruction book Separator clean Warning The operator must apply all relevant Safety precautions. Procedure • Stop the vacuum pump, close the isolation valve and switch off the voltage. • Drain all the liquid in vacuum pump and separator (1). • Open the required service panels.

  • Page 98: Pressure Switch

    Service kits For overhauling and for preventive maintenance, a wide range of service kits is available. Service kits comprise all parts required for servicing the component and offer the benefits of genuine Atlas Copco parts while keeping the maintenance budget low.

  • Page 99: Disposal Of Used Material

    Instruction book Installation proposal. 7. Store the pumping system as described below. Short term storage If the pumping system is to be stored for no longer than one month: 1. Store the pumping system indoors, in cool, dry, vibration and dust free conditions, at an ambient temperature of not less than 5 °C.

  • Page 100: Problem Solving

    Variable port valve plate defect Replace the valve plate. Vacuum pump element out of order Consult Atlas Copco. Air consumption exceeds air delivery Check the connected equipment. of vacuum pump Check the process lines for correct size Too high pressure drop between and for leakage.
  • Page 101 Clear the mesh. Check the connections, replace the sensor Temperature sensor malfunctioning if necessary. Vacuum pump element out of order Consult Atlas Copco Water injection solenoid valve Check the solenoid valve and connections. malfunctioning No enough water supply Check the water supply.
  • Page 102 Instruction book Faults If a problem is detected, alarm or shutdown will appear on the Elektronikon display. Fault Description Cause Remedy Check the communication cable between the Module Failure Expansion module failure expansion module and controller No Valid Pressure Control Pressure sensor failure Check the pressure sensor cable connection Converter Alarm Main...
  • Page 103 Instruction book Protection General The display shows the problem (Main Motor Converter Alarm) and a fault code (31 in this case). Main motor convertor alarm Fault Neos If a problem is detected by the Neos converter, a specific code (Main motor converter alarm) will appear on the Elektronikon display, together with a fault code and a fault description.
  • Page 104 Instruction book Typical display Main motor convertor alarm Fault Motor over temperature Below table lists the most important error codes. If another code appears, please contact Atlas Copco. Fault Fault code Fault code Cause Actions (Hexi decimal) description (Decimal) Check if main supply voltage is within specs.
  • Page 105 (hardware) power section Drive failure Eeprom read failed Time-out Try to reset the error. If error returns, 0x6101 24833 (hardware) communication contact Atlas Copco. Failed temperature reading of Drive failure power board 0x6102 24834 (hardware) Time-out communication at initialization Drive failure...
  • Page 106 Drive failure Not able to identify power 0x610E 24846 (hardware) board Try to reset the error. If error returns, Drive failure contact Atlas Copco. Not able to identify IGBT 0x610F 24847 (hardware) module Drive failure Power board not compatible 0x6110...
  • Page 107 Failure on attempt to write Try to reset the error. If error returns, to 91F4 37364 (software) parameter Pyyy out of range contact Atlas Copco. Centrifuge pump drive fault codes and troubleshooting Display Fault Name Possible Causes Solutions Ground fault or short circuit exists in the...
  • Page 108 Instruction book Display Fault Name Possible Causes Solutions Braking unit and braking resistor are not Install braking unit and braking resistor. installed. Input voltage is too high. Adjust input voltage to normal range. Overvoltage at Err07 constant speed An external force drives motor during Cancel the external force or install a running.
  • Page 109 Instruction book Display Fault Name Possible Causes Solutions ground Top tube of the AC drive is damaged. Ask Replace the AC drive. professional to check. Accumulative Accumulative running time reaches the Clear the record through parameter Err26 running time setting value. initialization.
  • Page 110 Instruction book Fault name Possible causes Solutions It is motor or motor cable Check that wiring between AC drive and motor is problem. normal. Related AC drive and The motor does not rotate Restore the factory parameters and re-set the motor motor parameters are set after the AC drive runs.

  • Page 111: Technical Data

    Instruction book Technical data Reading on display Elektronikon® Graphic controller Important The readings mentioned below are valid under the reference conditions (see section Reference conditions and limitations). Reference Reading Vacuum pressure Depends on the setpoint (desired net pressure). Element outlet Approx.

  • Page 112: Electrical Cable Size

    Instruction book Electrical cable size Important The voltage on the vacuum pump terminals must not deviate more than 10% of the nominal voltage. It is however highly recommended to keep the voltage drop over the supply cables at nominal current below 5% of the nominal voltage (IEC 60204-1). •...
  • Page 113 Instruction book Vacuum pump specification Itot Imax max. fuse pack undervoltage Primary Seco- Primary Secon- UL class ndary dary class Pump Voltage Frequency Approval I tot I tot I tot I tot LRP900VSD 37.2 46.5 41.3 51.7 LRP900VSD CSA/UL 32.3 40.4 35.9 44.9...
  • Page 114 Instruction book Maximum allowed current is function of the ambient temperature for installation method B2. Installation method C according to table B.52.1. Single-core or multi-core cable on a wooden wall. Maximum allowed current in function of the ambient temperature for installation method C. Installation method F according to table B.52.1.
  • Page 115 Instruction book Calculation method for IEC: • Single supply cables (3 phases + PE - configuration (1)): Add 10% to the total vacuum pump current (Itot from the tables) Install the prescribed fuse on each cable • Parallel supply cable (2 x 3 phases + PE - configuration (2)): Add 10% to the total vacuum pump current (Itot from the tables) and divide by 2 Multiply the ampacity of the cables with 0.8 (see table A.52.17 (52-E1)) Install fuses of half the size of the recommended maximum fuse size on each cable.
  • Page 116 Instruction book AWG or kcmil Maximum current < 30 A < 50 A < 65 A < 85 A < 100 A < 115 A < 130 A < 150 A < 175 A < 200 A Calculation method for UL: •...

  • Page 117: Reference Condition And Limitations

    Instruction book Reference condition and limitations Reference conditions Relative humidity °C Process inlet temperature °F mbar(g) Exhaust back pressure mbar(a) 1013 Ambient barometric pressure 14.7 °C Cooling water temperature °F Limitations ºC Minimum ambient temperature ºF ºC Maximum ambient temperature ºF ºC Minimum allowable inlet temperature (Dry)

  • Page 118: Vacuum Pump Data

    Instruction book Vacuum pump data Reference condition All data specified below apply under reference conditions, see section Reference conditions and limitations. Common vacuum pump data Unit mbar(a) Ultimate pressure Torr mbar(g) Maximum exhaust back pressure Torr °C Maximum temperature of the air leaving the discharge °F LRP 1000 VSD+ motor data Frame...

  • Page 119: Technical Data Elektronikon® Controller

    Instruction book Rated torque Sound pressure level (according to ISO 2151 (2004)) dB(A) 78 (+/-3) Technical data Elektronikon® controller General 24V AC/16 VA 50/60Hz (+40%/-30%) Supply voltage 24V DC/0.7 A IP54 (front) Type of protection IP21 (back) Ambient and temperature condition IEC60068-2 Operating temperature range -10°C..

  • Page 120: Instructions For Use

    Instruction book Instructions for use Air separator vessel • This vessel can contain pressurized air, this can be potentially dangerous if the equipment is misused. • This vessel must only be used as an air / liquid separator and must be operated below 0.5 bar(g).

  • Page 121: Guidelines For Inspection

    Instruction book Guidelines for inspection Guidelines On the Declaration of Conformity / Declaration by the Manufacturer, the harmonized and/or other standards that have been used for the design are shown and/or referred to. The Declaration of Conformity / Declaration by the Manufacturer is part of the documentation that is supplied with this vacuum pump.
  • Page 122 Instruction book This page has been intentionally left blank. 1950 8400 02...
