- Page 1 INSTALLATION & MAINTENANCE MANUAL BL5BK / BL5G / BL5BLBK / BL5BLG BLKITBK / BLKITG...
- Page 2 These instructions should be used to aid installation of the following products: BL5BK / BL5G / BL5BLBK / BL5BLG / BLKITBK / BLKITG SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations.
- Page 3 INSTALLATION Note - If this product is being used in conjunction with an external PIR or sensor, please confirm with the manufacturer of the sensors that they are compatible with LED luminaires. • Provide power to the required point of installation (refer to BS7671 for correct cabling methods).
- Page 4 SURFACE MOUNTING • Drill two fixing holes in the rear of the luminaire housing, mark the location of the fixing holes and drill ensuring not to infringe with any gas/water pipes or electrical cables • Feed the mains cable through the grommet on either the rear or the side of the luminaire housing (see Fig.
- Page 5 RECESSED MOUNTING • For recessed mounting using the BLKITxx, cut a suitable hole in the mounting surface ensuring not to infringe with any gas/water pipes or electrical cables • Remove a knockout from the backbox (see Fig. 3) Fig. 3 •...
- Page 6 Fig. 4 TERMINATION AND ACCESSORIES • Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown), N - Neutral (blue) • Select the desired colour temperature by means of the sliding switch on the LED gear tray (where applicable) •...
- Page 7 WARNING This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing. Irreparable damage will occur if this instruction is not followed. This product is not suitable for direct installation in the ground, nor in a retaining wall where the ground may become saturated behind.
- Page 8 If this product should fail within its warranty period, it should be returned to the place of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation costs associated with the replacement product.
