Samsung SSA-S2100 Specifications

Standalone
RFID
Access
Controllers
SSA-S2100/S2101
PROXIMITY / SMART CARD & PIN
TIME & ATTENDANCE ACCESS CONTROLLER
KEY Features
•125KHz Proximity / 13.56MHz Contact-less Smart Card reader
and PIN
•Dual function for Access Control and Time & Attendance
•10,000 / 20,000 Users / 20,000 / 10,000 Event Buffers
(Selectable)
•Operating Mode selectable by Individual ID
•4 Level Door Open Time Setting by Individual ID
•Time Schedules Setting by Individual ID, Input Port, Output
Port and Reader Mode
•Network Communication via RS232, RS485 and built-in
TCP / IP
Standalone Configuration
•4 Input, 4 Output (2 Relay Output)
•26bit / 34bit Wiegand Output
•Serial Printer Port for event ticket issuing
•Input Cut-off Check
•User Name Display on LCD
•ARM/DISARM Function for Alarm Panel
•2 Men Operation Mode
•Duress Alarm Function
•Multiple Master IDs Registration
•Graphic LCD of Multi Languages Display
TIME SCHEDULES
TIME CODE : 10
TIME INTERVAL : 5
HOLIDAY CODE : 10
HOLIDAY : 100
Specifications
Model SSA-S2100
CPU Dual 8bit and 16bit Microprocessor
Memory Program Memory 256KByte ROM, 512KByte SRAM
Data Memory 512KByte Flash Memory
User 10,000 / 20,000 Users (Selectable)
Event Buffer 20,000 / 10,000 Event Buffers (Selectable)
Power / Current DC 12V / Max.350mA
Reader Port 1ea (26bit Wiegand, 4 / 8bit Burst for PIN for Anti-Pass-Back)
Frequency 125KHz
Communication RS232 / RS485, TCP/IP
Baud Rate 9,600bps/ 19,200bps / 38,400bps / 57,600bps (selectable)
Input Port 4ea (Exit Button, Door Sensor, Aux#1, Aux#2)
Output Port 2ea (2 FORM-C Relay Output (COM, NO, NC) / DC12V~18V, Rating Max.2A)
2ea (TTL Output / DC5V, Rating MAX.20mA, 26 / 34bit Wiegand Output Supported by TTL Output)
LCD Display (Language) English, Spanish, Portugal, Korean (Selectable)
Voice Output (Language) English
LED Indicator / Beeper 3 LED Indicators (Red, Green and Yellow) / Piezo Buzzer
Operating Temperature 0°C ~ +50°C (-32°F ~ +122°F)
Operating Humidity 10% ~ 90% relative humidity non-condensing
Color / Material Silver and Black / Polycarbonate
Dimension (W x H x D) 191.5 x 159.5 x 44.0 mm
Network Configuration
SSA-S2101
1ea (34bit Wiegand, 4 / 8bit Burst for PIN for Anti-Pass-Back)
14
13.56MHz
15
