- Page 1 Lift / Elevator TCP/IP Control Module with 6A DC12V PSU LCM16-IP User Manual Please read these instructions carefully before operating the unit and keep for further reference.
-
Page 2: Table Of Contents
Overview ..........................3 Intelligent Elevator ......................3 System components ......................4 Diagram ..........................5 Application ........................7 Chapter 2 LCM16-IP Elevator Controller ..................8 Overview ..........................8 Features ..........................9 Specification ........................9 Wiring ..........................10 socket define ........................10 DIP Switch ........................ -
Page 3: Chapter 1 System Overview
Chapter 1 System Overview 1.1 Overview With the rapid development of high technology, intelligent management has entered people's lives. The modern city is surrounded by high-rise buildings, and the elevator has become an indispensable tool for people to go up and down. The intelligent elevator system is a high-tech product that integrates information management, computer control and smart card technology with IC/ID card as medium. -
Page 4: System Components
customer needs. Permission When the card is issued, the permission of the card is authorized. After the user enters in the elevator and swipes the card on the card reader, the access control system determines whether the card is valid and has the permission to reach the floor, and automatically select the corresponding floor, and the elevator will go up to the designated floor. -
Page 5: Diagram
1.4 Diagram... - Page 6 System wiring...
-
Page 7: Application
Wiring diagram when the floor signal is an external signal (such as used for the shidean protocol) 1.5 Application Elevator control, floor management; VIP cabinet management, cabinet control. -
Page 8: Chapter 2 Lcm16-Ip Elevator Controller
Chapter 2 LCM16-IP Elevator Controller 2.1 Overview The LCM16-IP is the main component of the elevator control system, which can independently control the 16-floors elevator. Each LCM16-IP elevator controller can support seven elevator control expand boards to control 128-floors elevator. -
Page 9: Features
system is powered down or other conditions occur, the elevator can work normally without being affected by the above contact. Of course, we have taken multiple security measures at the same time (such as using a highly reliable switching power supply, adding a clutter suppressor to the input and output ports, using hardware watchdog technology, using highly reliable TCP/IP communication, all communication The data is based on CRC check technology, etc.) to ensure that the system will not drop and crash. -
Page 10: Wiring
PCB Dimension: 20 (L) × 14.5 (W) cm Working temperature: -20 ° C to 70 ° C Relative humidity: 5% to 95% 2.4 Wiring... -
Page 11: Socket Define
2.5 socket define PIN definition： !"#$%&' (%)#*+,&+"-' .%/0*$'... - Page 12 1&2%*-%&' 1&2%*-%&' 3453446' 070,&+8%' .!9:;' <"' .!9:;' 7%8+#%' #=)&"/+>%7' !"#$% &'(')*'% +'$,)"-% .&!/!(!#% .!9:;' .%07%*' .!9:;' .%07%*' 01234%(5&6%&'56'&% 7!""'(/%%/!%%(!8.9/'&%%!&%%01234% .!9:;' <"''?@A60+-''@"//=-+#0&+"-' (!"*'&/'&% B@5@C65BC' C=&,=&' @"--%#&''&"''DE""*''F=&&"-' GB3IHHH60+-&%-0-#%' GB' 3HH34' G-,=&''3I''&"''34IA' )J+K' GBLIHHHM+*%''NE0*/K' GBOIHHH@0-#%E''D+*%''NE0*/K' GB34IHHHP+)+&'/"7%' Q+%R0-7' Q+%R0-7'*%07%*' ?"J%*A'S3LP5TB(' 3LP(@A?"J%*' Relay output termination method With 16 relay passive outputs (control elevator button with normally closed end), NC1, COM1, NO1 (normally closed, common, normally open)...
- Page 13 When connecting by TCP/IP, pay attention to configuring the SW2 DIP switch. DP1 and DP2 are defined as follows: Switch State Function Description Write protect DIP 1 Configurable, writable Normal DIP 2 Force the IP of converter to default IP 10.1.1.10 RS485 When using RS485 communication, it can be used with FSC8105 group controller at the same time.
- Page 14 !2"*&'#+*#=+&V')J+,%V' GB' 34' P+)+&"*'/"7%' )%E%#&' W/=&=0E' 0##%))'...
-
Page 15: Dip Switch
DE""*W' With 10 channels of arbitrarily programmable input points, the system defaults to 4 groups for fixed functions as follows: 1. A set of maintenance switch inputs (IN1): All floors can pass when the maintenance switch has a signal, until the maintenance switch signal disappears and the controller returns to normal operation. - Page 16 STATUS RESET COLD ^^^' ^^^' ^^^' ^^^' ^^^' ^^^' ^^^' Switch S2（Function） S2 or Dip Switch 2 is the 2nd dip switch on the controllers, The functions for Dip Switch 2 are below: Switch State Description Write protect DIP 1 Configurable, writable Normal DIP 2...
-
Page 17: Overview
Relay output: 32 groups Check in through the LCM16-IP The relay of the expansion board can be directly controlled by the LCM16-IP The status of each point is the same as the relay of the motherboard LCM16-IP 3.3 Specification Extended floor: 16 floors PCB Dimension: 14 (L) ×... -
Page 18: Wiring
3.4 wiring 3.5 socket define Relay output interface 32 relay passive outputs_' NC1ACOM1 … NC16ANO16ACOM16 Expansion board diagnostic interface 2Pin expansion board interface INPUT is the power/signal input, OUTPUT is the expansion board power/signal output Expansion board extended interface Ex1...7 is the extension position selection end of the expansion board (short connection is valid), Ex1 is 17...32 layers, Ex2 is 33...48 layers... -
Page 19: Chapter 4 Flp8104
Chapter 4 FLP8104 4.1 Overview The FPU8104 floor collector combines the new building intercom technology to develop a smart elevator management system that collects user floor signals and elevator operating status through high-speed optocouplers, enabling visitor functions and control and management of temporary use of temporary elevators. The system allows the visitor to reach the tenant floor without the use of a card or remember password without the need for a resident permit, and cannot enter other floors. -
Page 20: Wiring Diagram
4.4 Wiring diagram Figure 4-1 FPU8104 4.5 Sockets power FPU8104 uses DC12V power input, and has DC5V power output DC12V input DC5V power output DIP setting The FPU8104 DIP switch consists of 8 bits, of which the first bit is used for the host and the attached machine, the 2nd to 5th bits are used to set the host and the attached address, and the 6th to 8th bits are reserved. - Page 21 Figure 4-2 FPU8104 DIP The SW8 of the FSC8105 DIP switch should be selected to OFF (as shown below), and the FPU8104 DIP switch SW1 should turn OFF. Figure4-3 FSC8105 SW8 OFF FPU8104 DIP Switch]' status Function Description host DIP 1 Attached Number of attached machines, OFF is 0 DIP 2-5...
- Page 22 machines that set by the host. For example, if one host has 2 attached machines, the host is set to 2 (converted binary 10), and the attached machine address starts from 1. Setting as the following picture Communication The communication between FPU8104 and group controller FSC8105 adopts RS485 communication mode;The communication between host FPU8104 and attached machines also uses RS485.
- Page 23 Under normal situation, the TX1 and RX1 indicators on the FPU8104 board are flashing rapidly, and there is no alarm sound. Relay input In order to facilitate the docking of the building intercom and the intelligent elevator system, a set of relay switch signal input (NO, COM) end is provided for the floor collector to connect the intercom host signal.
-
Page 24: Chapter 5 Fsc8104
Chapter 5 FSC8104 5.1 Overview If there are multiple elevators at the same time, mutual coordination and data exchange will be an inevitable problem. So we have developed a smart elevator management FSC8105 group controller. It is used as a communication coordination between various devices and as a bridge for communication with the host computer;... -
Page 25: Parameters
5.3 Parameters CPU: ARM® CortexTM-M3 32-bit controller Power supply: 12VDC Communication method: RS485, TCP/IP Rate: 9600bps, Transmission distance: 1.2Km (at 100Kbps) Working temperature: -20 ° C to 70 ° C Relative humidity: 5% to 95% 5.4 Wiring diagram Figure 5-2 FSC8105 5.5 Sockets The FSC8105 DIP switch consists of 8 bits]' Switch... - Page 26 Configurable, writable Normal DIP 2 Force the IP of converter to default IP 10.1.1.10 External watchdog invalid External watchdog is valid, recommended (more DIP 3 stable) Normal DIP 4 Reset the converter Set visitor time / 60 seconds DIP 5 Set visitor time / 120 seconds DIP 6-7 Reserved...
- Page 27 the controller board LPU8110, in which, J1-J4 is corresponding with 485 channel’s 120 Ohms resistance jumper, LED18-LED21 is corresponding with 485 channel communication indicator. 1 channel 485 external floor signal input 2 channel RS232 input COM0aRX0ATX0A GNDbCOM1aDB9b' 1 channel ETHERNET output Extended interface 4- channel relay expansion interfaceaNC1cCOM1cNO1d'd' NC4cCOM4cNO4b' 8-channel EIN expansion interfaceaEIN1d'd' EIN8AGNDb'...
-
Page 28: Chapter 6 Operation In Sphinx
Chapter 6 Operation in sphinx Make sure the installation of sphinx with Lift controller. a1b' Add device in sphinx, Setup---hardware---controller configuration---search click to search controller,then configure and save. - Page 29 security groups, Add permission in...
- Page 30 Direct floor visit floor Also can set the floor level . personal list (3) Add permission in...
- Page 31 (4) If you want to use visitor mode Aplease short IN10 and GND...
- Page 32 Sales +44(0)1707 330541 Enquiries sales@genieproducts.co.uk Website www.genieproducts.co.uk...
