  • Page 1: Table Of Contents

    PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page INJECTOR CHANGE AND GAS SETTING Page GAS CONNECTION IMAGES Page SPARE PART LIST- EXPLODING DRAWING...

  • Page 2: Ageneral Information

    PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Weight (kg) Dimensions (mm) GPOE430DN 1100x950x520 1120x960x660 GPOE630DN 1400x950x520 1450x1000x660 GPOE930DN 1400x1250x520 1470x1280x660 TECHNICAL INFORMATION GPOE430DN GPOE630DN GPOE930DN PRODUCT CODE INNER DIMENSIONS 615x615x150 915x615x150 915x915x150 (mm) Ø300 mm x 4 Ø300 mm x 6 Ø300 mm x 9 CAPACITY pizza...

  • Page 4: A3 Transportation

    PIZZA OVEN (GAS) TRANSPORTATION *This appliance can not be moved by hand from area to area.It must be moved on pallet with Kasap Tip Dik Buzdolapları forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. *Do not operate the appliance when the machine is empty.

  • Page 6: Doperation

    PIZZA OVEN (GAS) OPERATION * Control panel: Kasap Tip Dik Buzdolapları AMBIENT CLOCK / DATE TEMPERATURE PANNEL ON / OFF...
  • Page 7 PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları MAIN SCREEN MANUEL COOKING If cooking will be done manually, click here RECIPE COOKING if recipe cooking or recipe creation is to be made, click here SETTINGS The parameters, Time / date setting and Auto start are set here.
  • Page 8 PIZZA OVEN (GAS) MANUAL COOKING Kasap Tip Dik Buzdolapları TEMPERATURE Oven temperature, set value and heaters status are shown here. If the heater icon is red, the heater output is passive, if the heater icon is green, the heater is active. COOKING TIME From here, cooking time can be set and started.
  • Page 9 PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları RECIPE REGULATION RECIPE NAME Bagel The recipe name can be changed by clicking here. RECIPE PHOTO TEMPERATURE COOKING TIME EXIT WIHTOUT SAVE THE RECIPE Exits without saving the recipe RECIPE SAVE BUTTON It saves the recipe...
  • Page 10 PIZZA OVEN (GAS) RECIPE COOKING Kasap Tip Dik Buzdolapları TEMPERATURE Oven temperature, set value and heaters status are shown here. If the heater icon is red, the heater output is passive, if the heater icon is green, the heater is active. COOKING TIME Cooking time can be set and started here.

  • Page 11: Ecleaning & Maintenance

    PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE  CLEANING AND MAINTENANCE AFTER EVERY USE  Be sure that gas and electric connections are off before cleaning.  Clean the inside of the oven with soft cloth by using oil solvent spray,before the appliance gets cooled exactly.

  • Page 12: Ftroubleshooting

    PIZZA OVEN (GAS) TROUBLESHOOTING Check if the gas connection is done or not. Kasap Tip Dik Buzdolapları If the hoses that have gas entrance lose gas due to THE APPLIANCE slit,hole.etc.,the appliance is not operated. DOESN’T OPERATE Check the electrical connections and voltage. Check if the fuse is on or off.

  • Page 13: Ginjector Change And Gas Setting

    PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları INJECTOR CHANGE AND GAS SETTING PIZZA OVENS (GAS ) BURNER-INJECTOR CHANGE CHART GPOE630DN GPOE430DN GPOE930DN NG / LPG  mm  mm  mm 30 mbar 50 mbar 37 mbar 50 mbar Change of the burner injector The oven must be dispatched from the factory as it works with NG.The injectors of the...

  • Page 14: Hgas Connection Images

    PIZZA OVEN (GAS) GAS CONNECTION IMAGES Kasap Tip Dik Buzdolapları Image 1...

  • Page 15: Ispare Part List-Exploding Drawing

    PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING GPOE430DN...
  • Page 16 PIZZA OVEN (GAS) SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: GPOE430DN PRODUCT NAME P.CODE BASE FRAME Y.GPOE430DN.001-R1 PIZZA STONE Y.GPOE430DN.002-R1 BURNER Y.GPOE430DN.003-R1 WICK Y.GPOE430DN.004-R1 INJECTOR Y.GPOE430DN.005-R1 SPARKING PLUG+CABLE Y.GPOE430DN.006-R1 25W LAMP Y.GPOE430DN.007-R1 Y.GPOE430DN.008-R1 THERMO PART ELECTRIC PANEL SHEETMETAL Y.GPOE430DN.009-R1...
  • Page 17 PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING GPOE630DN...
  • Page 18 PIZZA OVEN (GAS) SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: GPOE630DN PRODUCT NAME P.CODE BASE FRAME Y.GPOE630DN.001-R1 PIZZA STONE Y.GPOE630DN.002-R1 BURNER Y.GPOE630DN.003-R1 WICK Y.GPOE630DN.004-R1 INJECTOR Y.GPOE630DN.005-R1 SPARKING PLUG+CABLE Y.GPOE630DN.006-R1 25W LAMP Y.GPOE630DN.007-R1 Y.GPOE630DN.008-R1 THERMO PART ELECTRIC PANEL SHEETMETAL Y.GPOE630DN.009-R1 GAS BLOCK Y.GPOE630DN.010-R1...
  • Page 19 PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING GPOE930DN...
  • Page 20 PIZZA OVEN (GAS) SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: GPOE930DN PRODUCT NAME P.CODE Y.GPOE930DN.001-R1 BASE FRAME Y.GPOE930DN.002-R1 PIZZA STONE Y.GPOE930DN.003-R1 BURNER Y.GPOE930DN.004-R1 WICK Y.GPOE930DN.005-R1 INJECTOR Y.GPOE930DN.006-R1 SPARKING PLUG+CABLE Y.GPOE930DN.007-R1 25W LAMP Y.GPOE930DN.008-R1 THERMO PART Y.GPOE930DN.009-R1 ELECTRIC PANEL SHEETMETAL Y.GPOE930DN.010-R1 GAS BLOCK Y.GPOE930DN.011-R1...

  • Page 21: Jelectric Circuit Schema

    PIZZA OVEN (GAS) Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA...
  • Page 22 PIZZA OVEN (GAS) ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları PANNEL CONNECTION BROWN WHITE GREEN YELLOW BACKUP FOR THIS SECTION IT IS THE PORT DO NOT CONNECT...
