Model 701974
User's
PBL5000
Manual
5 GHz Low Capacitance Probe (10:1/20:1)
Thank you for purchasing the PBL5000 5 GHz Low Capacitance Probe (Model 701974). This user's
manual explains usage, specifications, and the handling precautions. To ensure correct use, please
read this manual thoroughly before beginning operation. After reading this manual, keep it in a safe
place.
5th Edition: January 2022 (YMI)
All Rights Reserved, Copyright © 2005, Yokogawa Electric Corporation
All Rights Reserved, Copyright © 2010, Yokogawa Test & Measurement Corporation
Printed in Japan
Notes
•
The contents of this manual are subject to change without prior notice as a result of continuing
improvements to the product's performance and functionality. The figures given in this manual may
differ from those that actually appear on your product.
•
Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your nearest
YOKOGAWA dealer.
•
Copying or reproducing all or any part of the contents of this manual without the permission of
YOKOGAWA is strictly prohibited.
The following symbols are used in this manual.
Improper handling or use can lead to injury to the user or damage to the instrument.
This symbol appears on the instrument to indicate that the user must refer to the
user's manual for special instructions. The same symbol appears in the corresponding
place in the user's manual to identify those instructions. In the manual, the symbol is
used in conjunction with the word "WARNING" or "CAUTION."
WARNING
Calls attention to actions or conditions that could cause serious or fatal injury to the
user, and precautions that can be taken to prevent such occurrences.
Calls attentions to actions or conditions that could cause light injury to the user or
CAUTION
damage to the instrument or the user's data, and precautions that can be taken to
prevent such occurrences.
French
AVERTISSEMENT
Attire l'attention sur des gestes ou des conditions susceptibles de provoquer
des blessures graves (voire mortelles), et sur les précautions de sécurité
pouvant prévenir de tels accidents.
Attire l'attention sur des gestes ou des conditions susceptibles de provoquer des
ATTENTION
blessures légères ou d'endommager l'instrument ou les données de l'utilisateur, et
sur les précautions de sécurité susceptibles de prévenir de tels accidents.
Note
Calls attention to information that is important for proper operation of the instrument.
Safety Precautions
This product is designed to be used by a person with specialized knowledge. To use this product
correctly and safely, the general safety precautions described herein must be observed during all
phases of operation. YOKOGAWA assumes no liability for the customer's failure to comply with these
requirements.
This manual is part of the product and contains important information. Keep this manual in a safe
place so that you can refer to it immediately when using the product until you dispose of the product. In
addition, before using the probe, read the manuals of the oscilloscope to thoroughly familiarize yourself
with its specifications and operation.
The following symbols are used on this instrument.
Handle with care. Refer to the user's manual or service manual. This symbol appears on
dangerous locations on the instrument which require special instructions for proper handling
or use. The same symbol appears in the corresponding place in the manual to identify those
instructions.
Notes about Usage
Grounding of the measuring instrument
The protective grounding terminal of the measuring instrument must be connected to ground.
Connecting the object of measurement
Make sure to avoid an electric shock when connecting the probe to the object of
measurement. Do not remove the probe from the measuring instrument after the object of
measurement is connected.
Do not operated with suspected failures
If you suspect that the probe is damaged, contact your nearest YOKOGAWA dealer.
Nondestructive input voltage range
Do not apply a voltage exceeding the nondestructive input voltage between input and
ground.
Must be grounded
Before connecting the probe input terminal to the item under test, check that the measuring
instrument is properly grounded, that the probe output connector is connected to the BNC
connector of the instrument, and that the earth lead is correctly connected to ground.
Do not operate in wet/damp conditions
To avoid electric shock, do not operate the probe in wet or damp conditions.
Do not operate in explosive atmosphere
To avoid injury or fire hazard, do not operate the probe in an explosive atmosphere.
Do not disassemble or modify
Do not disassemble or modify the product. YOKOGAWA assumes no liability if you
disassemble or modify the product.
Avoid exposed circuitry
To avoid injury, remove jewelry such as rings, watches, and other metallic objects. Do not
touch exposed connections and components when power is present.
Handling of the probe
Do not touch the probe's input terminal or the probe itself with wet hands.
Damaged signal cable
If the signal cable is torn and the inner metal is exposed or if a color different from the outer
sheath appears, stop using the cable immediately.
IM 701974-01E
5th Edition
WARNING
Maximum input voltage
Do not apply any voltages exceeding the maximum input voltage to the probe.
French
Mise à la terre de l'instrument de mesure
S'assurer de connecter la mise à la terre protectrice de l'instrument de mesure.
Connexion de l'objet de la mesure
S'assurer d'éviter un choc électrique lors de la connexion de la sonde à l'objet de la mesure.
Ne pas retirer la sonde de l'instrument de mesure après avoir connecté l'objet de la mesure.
Ne pas utiliser en cas de défaillances suspectées
Si vous suspectez que la sonde est endommagée, contactez votre revendeur ou
représentant commercial YOKOGAWA.
Plage de tension d'entrée non destructive
Ne pas appliquer de tension supérieure à la plage de tension d'entrée non destructive entre
l'entrée et la terre.
Doit être mis à terre
Avant d'effectuer les connexions aux bornes d'entrée du produit, vérifiez que le connecteur
de sortie est connecté au connecteur BNC de l'instrument de mesure et que le plomb de la
terre est connectée à une mise à la terre appropriée.
Ne pas utiliser dans des conditions humides
Afin d'éviter un choc électrique, ne pas utiliser cette sonde dans des conditions humides.
Ne pas utiliser dans une atmosphère explosive
Afin d'éviter des risques de blessures ou d'incendie, ne pas utiliser cette sonde dans une
atmosphère explosive.
Ne pas démonter ou modifier
Ne pas démonter ou modifier le produit. YOKOGAWA se dégage de toute responsabilité si
vous démontez ou modifiez le produit.
Éviter les circuits exposés
Afin d'éviter des blessures, retirer les bijoux comme les bagues, montres et autres objets
métalliques. Ne pas toucher les connexions et les composants exposés après mise sous
tension.
Manipulation de la sonde
Ne pas toucher le terminal d'entrée de la sonde ou la sonde elle-même avec des mains
mouillées.
Câble de signal endommagé
Si le câble de signal est déchiré et que le métal intérieur est exposé ou si une couleur
différente de la gaine externe est visible, arrêter immédiatement d'utiliser ce câble.
Tension d'entrée maximum
Ne pas appliquer à la sonde de tension dépassant la tension d'entrée maximum.
Waste Electrical and Electronic Equipment (WEEE)
(EU WEEE Directive valid only in the EEA* and UK WEEE Regulations in the UK)
This product complies with the WEEE marking requirement. This marking indicates
that you must not discard this electrical/electronic product in domestic household
waste. When disposing of products in the EEA or UK, contact your local Yokogawa
office in the EEA or UK respectively.
*EEA: European Economic Area
Authorized Representative in the EEA (AR)
Yokogawa Europe B.V. is the authorized representative of Yokogawa Test & Measurement
Corporation for this product in the EEA. To contact Yokogawa Europe B.V., see the separate list of
worldwide contacts, PIM 113-01Z2.
1. Description
The PBL5000 5 GHz Low Capacitance Probe (Model 701974) is a low input capacitance passive
probe (attenuation ratios of 1/10 or 1/20) for use with oscilloscopes having an input impedance of
50 Ω. The attenuation ratio can be changed by replacing the resistor on the probe tip.
2. Appearance
As shown in the figure below, the probe consists of the probe itself, and standard parts.
6
5
No. Standard Parts
1.
Sleeve
2.
Probe head
3.
450 Ω resistor (2 pcs)
4.
950 Ω resistor (2 pcs)
5.
Probe cable
6.
SMA(J)-BNC(P) conversion adapter
7.
Manuals (see below)
Manual Title
Model 701974
PBL5000 5GHz Low Capacitance
Probe (10:1/20:1) User's Manual
Model 701974
5GHz Low Capacitance Probe
Inquiries
The "E" and "Z2" in the manual numbers are the language codes.
CAUTION
AVERTISSEMENT
ATTENTION
4
2
3
1
Part No.
B8099JE
B8099JF
B8099FE
B8099FF
–
–
–
Manual No.
Description
IM 701974-01E
This manual. Explains usage,
specifications, and the handling
precautions of the 701974.
IM 701974-92
Document for China
PIM 113-01Z2
List of worldwide contacts
IM 701974-01E 1/2
