User's
Manual
Please heed the following warnings when handling the probe. Yokogawa bears no responsibility for, nor
implies any warranty against damages occurring as a result of failure to take these precautions. Please
read the user's manual of the measuring instrument and fully understand the specifications and handling
procedures of that instrument before using the probe.
• The following safety symbols and words are used in this manual.
This symbol warns against danger to personnel and instruments, and indicates that the
user should refer to the relevant instructions in the user's manual.
WARNING
Calls attention to actions or conditions that could cause serious injury or death to the user,
and precautions that can be taken to prevent such occurrences.
CAUTION
Calls attentions to actions or conditions that could cause light injury to the user or damage
to the instrument or user's data, and precautions that can be taken to prevent such
occurrences.
• The following precautions must be taken to prevent electric shock and other potentially fatal accidents
and damage to instruments.
WARNING • Ground the Measuring Instrument
Always connect the main instrument's protective grounding.
• Connect the Probe's Earth Wire
Connect the earth wire (ground potential) to ground.
• Take Care When Connecting to the Item under Test
Take care to avoid electric shock when connecting the probe to the item under test. Also, never
disconnect the probe from the measuring instrument while the probe is connected to the circuit under
test.
• Never Use the Probe If You Suspect It Is Damaged
If you suspect the probe might be damaged, please consult with your Yokogawa dealer or
representative.
• Maintain Nondestructive Input Voltages
Do not apply a voltage exceeding the nondestructive input voltage between input and ground.
• Check the Grounding
Before connecting the probe input terminal to the item under test, check that the measuring instrument
is properly grounded, that the probe output connector is connected to the BNC connector of the
instrument, and that the earth lead is correctly connected to ground.
• Do Not Use the Probe in Humid Locations
To avoid electric shock, never use the probe in areas of high humidity.
• Do Not Use the Probe Near Flammable Gases
To avoid injury and fire, do not use the probe near flammable or explosive gasses or vapors.
• Avoid Exposed Circuits
To prevent injury, remove all jewelry such as rings and wristwatches. When the power is ON, do not
touch any exposed connectors or components.
• Handle the Probe Safely
Do not touch the probe input terminal with your hands. Also, never touch the probe with wet hands.
CAUTION
• Maximum Input Voltage
Do not apply a voltage exceeding the maximum voltage to the probe's input terminal.
Overview
The model 701974 PBL5000 5 GHz Low Capacitance Probe is a low input capacitance passive probe (attenua-
tion ratios of 1/10 or 1/20) for use with oscilloscopes having an input impedance of 50 Ω. The attenuation ratio
can be changed by replacing the resistor on the probe tip.
Model 701974
PBL5000
5 GHz Low Capacitance Probe(10:1/20:1)
Safety Precautions
