- Page 1 Translation of the original instructions with installation instructions Automatic backflush filter with external medium backflushing R5-3 Mat. No. of original instructions 70580785...
-
Page 2: Table Of Contents
Non-observance can result in minor or moderate injuries. CAUTION! (without a symbol) Potentially dangerous situation! Non-observance can result in property damage. Page 2 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 3: Other Symbols Used
Filtered fluid: Substance that is filtered. Filtration mode: The automatic filter operates normally and the valves are closed. Page 3 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 4: Functional Description
The filtered fluid enters the clean side and exits the automatic filter via the filter outlet. Fig. 1: Diagram of the main components R5-3 Page 4 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 5: Technical Data
Always store in a dry, frost-free room interrupted. Seaworthy packaging is specified in the contract documentation as an option. Page 5 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 6: Installation Instructions
To test the functioning of the electric actuators Refer to the Instruction Manual for the E900 filter controller. Page 6 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 7: Start-Up
The initial differential pressure varies according to the application. General guide: Installation on discharge side: p ≤ 0.1 bar Page 7 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 8: Troubleshooting
Automatic filter dirty Clean the automatic filter Contamination level Use a prefilter too high Page 8 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 9: Inspection And Maintenance Schedule
Loosen and remove the hexagon screws on the Turn off the compressed air supply. gear motor flange. Withdraw the gear motor vertically from the shaft. Page 9 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 10: Removing The Filter Insert
Mount in reverse order. Connect the gear motor. Fig. 7: Removing the inner insert from the automatic filter Page 10 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 11: Cleaning The Automatic Filter
( refer to section 14.5 / 14.6 ) Assembly Push a new or cleaned wire cloth cylinder (2) over the body (1). Page 11 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 12: Replacing The Insert And Filter Seals
Bush Quad ring O-ring Quad-Ring (only in the case of plastic bush ) Fig. 10: Replacing the insert/ filter seals Page 12 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 13: Dimension Drawings
Dimension drawings 15.1 Dimension drawing of the R5- 3 Fig. 11: Dimension drawing of the R5-3 Page 13 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 14: Part Drawing
Part drawing 16.1 Part drawing R5-3 Filter Fig. 12: Part drawing Filter Page 14 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... - Page 15 16.2 Part drawing insert Fig. 13: Part drawing insert Page 15 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04...
-
Page 16: List Of Parts
Hexagon screw Feather key Gasket O-ring Spacer bush Hexagon screw Feather key Cylinder pin Set srew Square flange Hexagon screw Gasket Page 16 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 17: Recommended Spare Parts
Square seal ring O-ring Gasket Gasket O-ring Please request a separate spare parts drawing and list of spare parts for special versions. Page 17 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... -
Page 18: Declaration Of Incorporation
Declaration of incorporation Page 18 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... - Page 19 Page 19 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04...
- Page 20 Page 20 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04...
- Page 21 Page 21 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04...
-
Page 22: Declaration Of Conformity
Declaration of conformity Index Page 22 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04... - Page 23 Gear motor ............... 8, 9, 10 Suspension ................. 3 Hand release ..............6 Valves ................. 3 Warning symbols ..............2 Page 23 Translation of the original instructions with installation instructions R5- Filtration Group GmbH,, 24.05.2019, Mat. No. 70580785, Revision 04...
- Page 24 Filtration Group GmbH Schleifbachweg 45 D-74613 Öhringen Phone +49 7941 6466-0 Fax +49 7941 6466-429 fm.de.sales@filtrationgroup.com www.fluid.filtrationgroup.com 70580785.I04.05/2019...
