- Page 1 CHU LUN SING CO.,LTD No.199,Gangshan N. Rd., Gangshan Township, Kaohsiung County 820, Taiwan http://www.sunrun.com.tw E-mail:sun.run@msa.hinet.net TEL:886-7-6210505 FAX:886-7-6217575 OPERATING INSTRUCTIONS HYDRAULIC AIR PUMP SPA-554TQ English E1~E5...
- Page 2 WARNING: Immediately replace worn or damaged parts with genuine SUN RUN CAUTION: Do not use worn socket and parts. SUN RUN parts are designed to fit square drive. properly and withstand rated loads. CAUTION: Please use the socket of good IMPORTANT: Hydraulic equipment must performance.
- Page 3 Instructions for: Models:SPA-554TQ Hydraulic Air Pump 2.SPECIFICATION 300mm Lubrication oil knob Air Press. Adjust Press. Gauge Zero button Oil/vent port Press. Adjust 320mm Model Air Supply DBa at Flow rate Oil tank Weight (with oil) Number Req'd Idle and @115VAC(L/min)
- Page 4 Instructions for: Models:SPA-554TQ Hydraulic Air Pump 3.OPERATION 3.2 When operating the pump for the first time: 3.21 Valve and hose connections must be tight, and the reservoir must be filled to the proper oil level. Start the motor. 3.22 Release Vent/ Fill cap to 1.5 circles.
- Page 5 Instructions for: Models:SPA-554TQ Hydraulic Air Pump 4. Maintain oil level 4.1 Bleeding Air From The System Air can accumulate in the hydraulic system if the reservoir level is too low. This air cause the torque wrench to respond in an unstable or slow manner. Just put torque wrench on the smooth ground that is no load condition and operates it in full stroke for several times that will bleed air from torque wench system.
- Page 6 Instructions for: Models:SPA-554TQ Hydraulic Air Pump PROBLEM CAUSE SOLUTION 1.Oil level too low. 1.Fill reservoir to 1/2"(15mm) from Pump is not delivering oil or delivers only enough oil to top of filler hole with all wrench plungers retracted. advance torque wrench(s) 2.Loose-fitting coupler to cylinder.
