Counter Top Payment Terminal
CT281
User's Manual
∙Please read the following warnings before using the product.
∙ S hapes and colors of the images shown in this manual may differ from the actual products.
∙ C ontents of the manuals may differ based on the software version of products or conditions of the wireless provider.
Advertisement
Table of Contents
Related Manuals for Bluebird CT281
Summary of Contents for Bluebird CT281
- Page 1 Counter Top Payment Terminal CT281 User's Manual ∙Please read the following warnings before using the product. ∙ S hapes and colors of the images shown in this manual may differ from the actual products. ∙ C ontents of the manuals may differ based on the software version of products or conditions of the wireless provider.
- Page 2 • This user manual is protected by copyright. • This user manual has been created by the Bluebird Inc. We have done our best not to create typos, editing errors, and leaving out any information. Please understand if there are any inconveniences.
- Page 3 End users cannot modify this transmitter device. Any Unauthorized modifi cation could void the user`s authority to operate this device. Hereby, Bluebird Inc. declares that this CT281 is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC.
-
Page 4: Table Of Contents
Contents ........Notice Before Using Device . -
Page 5: Notice Before Using Device
Notice Before Using Device This information is for your own safety. Please observe the following precautions. WARNING • This device is qualified for the standard of the safety of human body against electromagnetic wave. For your own safety, please use certified devices provided by headquarter. -
Page 6: Precautions Before Using Battery
Precautions Before Using Battery These are safety precautions in order to prevent a dangerous accident. Please use the battery correctly and carefully observe the instructions. WARNING • If the battery is taken apart by impact, applied heat, submersion, or hole-drilling, there is a risk of a dangerous explosion. -
Page 7: About The Product
The images in this User’s Manual may not refl ect the color and shape of the actual product. Please contact the Customer Care Center if you wish to purchase any additional or optional products. Power Cable PSTN Cable Power Adapter Battery CT281 Main Body... -
Page 8: Checking Names Of Parts
2. Checking names of parts Conn. LED Power LED Screen MSR Slot Cancel Button Clear Button Enter Button IC Card Slot Battery Cover Cable Slot Cable Cover Printer... -
Page 9: Buttons
3. Buttons The front panel includes the following features: A terminal display, Backlight LCD screen. • Five types of keys: • 1. 12-key, numeric keypad. 2. Four ATM-style function keys, labeled F1 to F4, below the LCD screen. 3. Four unlabeled, programmable function keys above the keypad. -
Page 10: Connection Ports
4. Connection Ports There are connection ports available on back side of the terminal. The ports are covered by protect cover. Various ports are provided in order to connect CT281 with any external peripheral devices, data communication or power supply. USB HOST... -
Page 11: Establish Telephone Line Connections
USB HOST POWER ETHERNET RS232 1/2 LINE 5. Establish Telephone Line Connections Connect the telephone cord to the communication port on the terminal, then route it directly to a telephone wall jack. USB HOST POWER ETHERNET RS232 1/2 LINE Changing the printing paper 1. -
Page 12: Closing Paper Roll Cover
Changing the printing paper 2. Closing Paper Roll Cover Please be careful not to insert printer paper in the opposite direction. Tear the paper off against the top case in the printer. WARNING 3. Direction for Receipt Cut Pull the Receipt Toward the LCD. The printer cover can open if the Receipt is pulled backward. -
Page 13: Paying With Card
Paying with card 1. Paying with MSR The card can be swiped in both directions. Please swipe the card. 2. Paying with IC Card Insert IC card. IC chip needs to go in fi rst. Please make sure that insert the card all the way in. -
Page 14: Learning Basics
Learning Basics 1. Insert / Remove the battery 1-1. Insert the battery 1 Push your battery in the direction 2 Put on the battery cover in the of the arrow. direction on the arrows. 1-2. Removing the battery 1 Slide down the battery cover to 2 Lift the battery in the direction of open it. -
Page 15: Insert / Remove The Usim Card
2. Insert / Remove the USIM card 2-1. Insert the USIM card Place the USIM card on the holder then push down the holder. 2-2. Removing the USIM card Push the top of the USIM card and slide it out from the holder. -
Page 16: Insert / Remove The Microsd Card
3. Insert / Remove the microSD card 3-1. Insert the microSD card 1 Open the storage card holder by lifting up the flap. 2 Insert the microSD card into the storage card holder with its gold contacts facing out. 3 Lock the storage card holder by pushing it down into place. -
Page 17: Removing Microsd Card
3-2. Removing microSD card 1 With the USIM card and storage card compartment opened, lift the storage card holder flap to open it. 2 Remove the microSD card. -
Page 18: To Connect The Terminal Power
4. To Connect the Terminal Power Power Cable Power Adapter USB HOST POWER ETHERNET RS232 1/2 LINE As you see in the picture, connect the adapter with the power cable to charge the power. • When The battery of the device is low, it may warn you with a ring and a message. -
Page 19: Device Specifications
Device Specifications PAYMENT OPTIONS • Bi-directional, Triple track (Tracks 1, 2, 3)CT281 • ISO 7816, 1.8V, 3V, 5V; synchronous and asynchronous cards; Contact Payment EMV Level 1 and 2 type approved • Optional, • MasterCard PayPass M/Chip • MasterCard PayPass MagStripe •... -
Page 20: Q & A
Q & A Water went into my device. What do I do? First, remove your battery from the device and dry them in a dry place. After drying for a period of time, try to turn it on. If it still does not turn on, the main-board or other parts needs to be replaced. -
Page 21: Service Center
• Do not intentionally damage the label on the product. • Damaged label may result in a disadvantage to the customer. • When you return the product to Bluebird for service, please put the product in a protective box. • No warranty will not be provided for any damage occurring during delivery. - Page 22 Service Center Charged Service 1. If it is not a default, it will be charged when requesting for after-sales service. - Service request due to inappropriate use of the customer - Loss of a PIN number - Use of programs that might effect the program (over-clock, forceful changes in the input of the system, personal developments) 2.
-
Page 23: Warranty Certificate
1 year from purchase Warranty 1. Bluebird Inc. (hereinafter referred to as Bluebird) provides the warranty service for its products in compliance with the regulations on compensation for damage of customer. 2. Upon receiving a notification on a defect of its product within the range of warranty during the warranty period, Bluebird will repair or replace the defective product according to its warranty policy. - Page 24 Customers Service Center Hours Mon. ~ Fri. : 9:30 A.M. ~ 6:30 P.M. (GMT Time: +9 Hours) W e ar e not open on Satur day, Sundays and National Holidays. Addr ess Customers service center, SSang-young IT twin tower B 703, Sangdaewon-dong 442-5, Joongwon-gu, Sungnam-si, K eonggi-do, K or ea Bluebir d constantly strives to bring...
