www.bluebirdsoft.com
Touch Mobile Payment Terminal
MT760
User's Manual
. Please read the following warnings before using the product.
. Shapes and colors of the images shown in this manual may di er from the actual products.
. Contents of the manuals may di er based on the software version of products or conditions of the wireless provider.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pidion MT760 and is the answer not in the manual?

Questions and answers

Related Manuals for Bluebird Pidion MT760

Summary of Contents for Bluebird Pidion MT760

  • Page 1 www.bluebirdsoft.com Touch Mobile Payment Terminal MT760 User’s Manual . Please read the following warnings before using the product. . Shapes and colors of the images shown in this manual may di er from the actual products. . Contents of the manuals may di er based on the software version of products or conditions of the wireless provider.
  • Page 2 • This user manual is protected by copyright. • This user manual has been created by the Bluebird Soft. We have done our best not to create typos, editing errors, and leaving out any information. Please understand if there are any inconveniences.
  • Page 3 End users cannot modify this transmitter device. Any Unauthorized modification could void the user`s authority to operate this device. Hereby, Bluebird Soft Inc. declares that this MT760 is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC.

  • Page 4: Table Of Contents

    Contents ........Notice Before Using Device .

  • Page 5: Notice Before Using Device

    Notice Before Using Device This information is for your own safety. Please observe the following precautions. WARNING • This device is qualified for the standard of the safety of human body against electromagnetic wave. For your own safety, please use certified devices provided by headquarter.

  • Page 6: Precautions Before Using Battery

    Precautions Before Using Battery These are safety precautions in order to prevent a dangerous accident. Please use the battery correctly and carefully observe the instructions. WARNING • If the battery is taken apart by impact, applied heat, submersion, or hole-drilling, there is a risk of a dangerous explosion.

  • Page 7: About The Product

    About the product 1. Checking components The images in this User’s Manual may not reflect the color and shape of the actual product. Please contact the Customer Care Center if you wish to purchase any additional or optional products. Power Cable Power Adapter Cradle Gender...

  • Page 8: Checking Names Of Parts

    About the product 2. Checking names of parts 2-1. Main Body Designed & Manufactured by Power LED Conn. LED Screen Four Button MSR Card Slot IC Card Slot Battery Cover Speaker Printer Line 2-2. Cradle RS232 ETHERNET USB HOST POWER USB DEVICE MT760 MANUAL...

  • Page 9: Buttons

    About the product 3. Buttons The front panel includes the following features: A terminal display, Backlight LCD screen. • Designed & Manufactured by Built-in MSR is located at the right side of the • device. There is the icon shows you the proper way to swipe the card.

  • Page 10: Closing Paper Roll Cover

    Changing the printing paper 2. Closing Paper Roll Cover Please be careful not to insert printer paper in the opposite direction. Tear the paper off against the top case in the printer. WARNING 3. Direction for Receipt Cut Pull the Receipt Toward the LCD. The printer cover can open if the Receipt is pulled backward.

  • Page 11: Paying With Card

    Paying with card 1. Paying with MSR The card can be swiped in both directions. Please swipe the card. 2. Paying with IC Card Insert IC card. IC chip needs to go in fi rst. Please make sure that insert the card all the way in.

  • Page 12: Learning Basics

    Learning Basics 1. Insert / Remove the battery 1-1. Insert the battery 1 Push your battery in the direction 2 Put on the battery cover in the of the arrow. direction on the arrows. 1-2. Removing the battery 1 Slide down the battery cover to 2 Lift the battery in the direction of open it.

  • Page 13: Insert / Remove The Usim Card

    Learning Basics 2. Insert / Remove the USIM card 2-1. Insert the USIM card Slide in the USIM card in the arrow direction. The devices supports 2 USIM slots. 1 Push the USIM card holder to ‘OPEN’ direction then lift up. 2 Place the USIM card on the holder then push down the holder.

  • Page 14: Removing The Usim Card

    Learning Basics 2-2. Removing the USIM card Push the top of the USIM card to slide it out in the arrow direction. Push the top of the USIM card and slide it out from the holder. 3. Insert / Remove the microSD card 3-1.

  • Page 15: Removing Microsd Card

    Learning Basics 2 Insert the microSD card into the storage card holder with its gold contacts facing out. 3 Lock the storage card holder by pushing it down into place. 3-2. Removing microSD card 1 With the USIM card and storage card compartment opened, lift the storage card holder flap to open it.

  • Page 16: To Connect The Terminal Power

    Learning Basics 4. To Connect the Terminal Power Power Cable Power Adapter Gender As you see in the picture, connect the adapter with the power cable to charge the power. • When The battery of the device is low, it may warn you with a ring and a message.

  • Page 17: Charging With Cradle

    Learning Basics 5. Charging with Cradle Power Cable Power Adapter Cradle MT760 MANUAL...

  • Page 18: Device Specifications

    Device Specifications Payment Options • Bi-directional, Triple track (Tracks 1, 2, 3) • ISO 7816, 1.8V, 3V, 5V; synchronous and asynchronous cards; Contact Payment EMV Level 1 and 2 type approved • Optional • MasterCard PayPass M/Chip • MasterCard PayPass MagStripe •...

  • Page 19: Q & A

    Q & A Water went into my device. What do I do? First, remove your battery from the device and dry them in a dry place. After drying for a period of time, try to turn it on. If it still does not turn on, the main-board or other parts needs to be replaced.

  • Page 20: Service Center

    • No warranty will not be provided for any damage occurring during delivery. We recommend you to use the box and protective cover supplied with the product. • Make sure to deliver the product in a safe way. Bluebird Soft assumes no responsibility for loss of the product during delivery. MT760...
  • Page 21 Service Center Charged Service 1. If it is not a default, it will be charged when requesting for after-sales service. - Service request due to inappropriate use of the customer - Loss of a PIN number - Use of programs that might effect the program (over-clock, forceful changes in the input of the system, personal developments) 2.

  • Page 22: Warranty Certificate

    3. If the defective product within the range of warranty is not repairable or replaceable, Bluebird shall refund the purchasing price within a designated period from the date of receiving a notice of defect. 4. Bluebird assumes no responsibility for repairing, replacement or refund until it receives the defective product from the customer.
  • Page 23 (GMT Time: +9 Hours) We are not open on Saturday, Sundays and National Holidays. Address Customers service center, SSang-young IT twintower B 703, Sangdaewon-dong 442-5, Joongwon-gu, Sungnam-si, Keonggi-do, Korea Bluebird constantly strives to bring utmost satisfaction to all our customers.
