RoyalTek REB-1315LP Operational Manual page 19

Value
0
1
2
3-5
6
GSA-GNSS DOP and Active Satellites
Table 2-4 contains the values of the following example:
$GPGSA, A, 3, 07, 02, 26, 27, 09, 04, 15, , , , , , 1.8,1.0,1.5*33
Name
Message ID
Mode 1
Mode 2
Satellite Used
Satellite Used
....
Satellite Used
PDOP
HDOP
VDOP
Checksum
＜CR＞＜LF＞
Value
M Manual-forced to operate in 2D or 3D mode
A Automatic-allowed to automatically switch 2D/3D
RoyalTek Confidential
REB-1315LP Operational Manual
Position Fix Indicators
Table 3
Description
Fix not available or invalid
GPS SPS Mode, fix valid
Differential GPS, SPS Mode, fix valid
Not Supported GPS PPS Mode, fix valid
Dead Reckoning Mode, fix valid
Table 4 GSA Data Format
Example Units
$GPGSA GSA protocol header
A See Table 4-2
3 See Table 4-1
07 Sv on Channel 1
02 Sv on Channel 2
....
Sv on Channel 12
1.8 Position Dilution of Precision
1.0 Horizontal Dilution of Precision
1.5 Vertical Dilution of Precision
*33
End of message termination
Table 5 Mode 1
Value Description
1 Fix not available
2 2D
3 3D
Table 6 Mode 2
Description
19
Description
