5 DISPLAY INSTALLATION
The display should be installed in the machine cab at the operator station, in a position
where it can easily be seen and accessed by the operator. Normally this will be on the
operator's right side, near the front of the cab.
The display is mounted using a RAM bracket, which will enable the display to be positioned
facing the operator. Mount the RAM bracket to a solid surface that is capable of supporting
the weight of the display.
Do not modify the frame of the machine by drilling or welding as this will compromise the
ROPS / FOPS integrity of the structure.
Ensure that machine controls, operator view of indicator lamps and gauges, and window /
door operation are not obstructed.
5.1
Electrical Connections
The display has a flying lead through which all electrical connections are made. A suitable
power supply should be identified, this should be ignition switched and capable of supplying
5A to the system.
The Series 1-H system should be protected by a 5A fuse on the ignition power supply.
Connect both the
Connect the BLACK wire to a good 0V connection, preferably directly to the vehicle chassis.
5.2
Relay Outputs
The Series 1-H outputs are through the
be +V outputs, if either are not used they should be insulated and protected from the
possibility of short circuit against a 0V chassis component or connection.
• The
GREEN
driving a sounder or lamp indicating that the limit has been reached.
YELLOW
• The
reached. It is suited to driving a solenoid valve controlling the boom lift function, and will
motion cut the hydraulic function at height limit.
5.3
CAN Bus Connection
The 12mm connector on the base of the display is the CAN bus connection to the angle
sensor, and should be connected to the angle sensor using the supplied cable.
www.gkdtechnologies.com
RED
BLUE
wires to the +V power supply, with the fuse protecting both.
and
wire will be live when the height limit is reached, and is therefore suited to
wire will be live when working, and will switch off when the height limit is
GREEN
and
YELLOW
7
wires. Note that these will
M1000005 V1.5 - 11/2021
