  • Page 1 USER MANUAL M2000022 V1.1 - 06/2021...
  • Page 2 www.gkdtechnologies.com M2000022 V1.1 - 05/2021...
  • Page 3: Table Of Contents

    CONTENTS Page SERIES 2-HS INTRODUCTION OPERATION FRONT SCREEN MODE MENU SETTING A HEIGHT LIMIT CANCELLING A HEIGHT LIMIT SETTING A SLEW LIMIT VIRTUAL WALLS DIG DEPTH INDICATOR CAB PROTECTION TEST FUNCTION ERROR CODES AND ERROR DIAGNOSIS GUIDE www.gkdtechnologies.com M2000022 V1.1 - 06/2021...
  • Page 4: Series 2-Hs Introduction

    SERIES 2-HS INTRODUCTION This is the operation manual for the 2 Series Height & Slew range of envelope restrictors. This product is a safety product. WARNING - THIS INDICATOR IS NOT FOR USE IN EXPLOSIVE ATMOSPHERES. ADJUSTMENT BY NON AUTHORIZED PERSONNEL WILL INVALIDATE THE WARRANTY. OPERATION The 2 Series Height &...
  • Page 5: Mode Menu

    MODE MENU From the main screen, press on the Mode button. The following window should appear: Set and Cancel Set and Cancel Slew Limits Virtual Walls Set and Cancel Dig Mode Height Limits Settlings To Settings Exit to Main Test Button Menu Screen SETTING A HEIGHT LIMIT...
  • Page 6: Cancelling A Height Limit

    When there is a height limit set, this will be shown on the main screen. As you approach the height limit, the internal buzzer will beep and the amber LED will flash. If the height is exceeded then the internal buzzer will sound and the boom lift will be cut (if an optional motion valve is fitted).
  • Page 7: Virtual Walls

    VIRTUAL WALLS From the main screen, press on the Mode button: Then press on the Virtual Wall button: You should be shown the screen below: Set Virtual Exit to Main Wall 1 Screen Set Virtual Set Virtual Wall 2 Wall 4 Set Virtual Enable/Disable Wall 3...
  • Page 8 Setting a virtual wall by entering a distance Press on the “Set Virtual Wall 1” button. Then press on the “Left Wall” button. A keypad will open for you to enter the distance to the left wall, in metres. Enter the distance and press OK. The screen should now change back to one similar to that pictured to the right.
  • Page 9 Setting a virtual wall using the bucket Move the machine and position the bucket where the first point of the wall is required. Press on the “Bucket” button. The system will log this point as the first point of the virtual wall. Slew the machine to move the bucket to the second position.
  • Page 10: Dig Depth Indicator

    DIG DEPTH INDICATOR The 2 Series Height & Slew provides a guide to levelling or trenching. The system monitors the Bucket Pin at all times and, depending on its position, can indicate whether you are too deep or not deep enough. Current Bucket Pin Target Level Indicator height from Ground...
  • Page 11: Cab Protection

    When in digging mode the system provides a level indicator. The indicator shows the target level. There are three states for the indicator, as shown below: Above Target Level Below Target Level On Target Level NOTE - The depth indication is measured to the load point. The orientation of the bucket will affect the accuracy of the indicator.
  • Page 12: Test Function

    Below is a link to the GKD Knowledge base where you can find definitions of all the error codes for the 2 Series Height & Slew System.
  • Page 13 NOTES: www.gkdtechnologies.com M2000022 V1.1 - 06/2021...
  • Page 14 GKD Technologies reserve the right to change these instructions in line with the policy of continuous improvement. 17 Cobham Road, Ferndown Industrial Estate, Wimborne, Dorset, UK. BH21 7PE +44 (0)1202 861 961 sales@gkdtechnologies.com www.gkdtechnologies.com ©GKD Technologies 05-2021...
