Crown DC-6 Installation & Operation Manual

Direct steam counter tilting kettles

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Installation & Operation Manual

Direct Steam Counter Tilting Kettles

DC-6, DC-10, DC-12 and DC-20

Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury

or death. Read the installation, operating and maintenance instructions thoroughly before installing or

ANUAL 10076

EV 6 (04/22)

$21.00

servicing this equipment.

CROWN FOOD SERVICE EQUIPMENT

70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9

Telephone: 919-762-1000

Model DC-6

WARNING

A Middleby Company

www.crownsteamgroup.com

IMPORTANT FOR FUTURE REFERENCE

Please complete this information and retain this

manual for the life of the equipment:

Model #: ___________________________

Serial #: ___________________________

Date Purchased: _____________________

Direct Steam Counter Tilting Kettles

ANUAL

ECTION

Table of Contents

Need help?

Do you have a question about the DC-6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Crown DC-6

Page 1 Serial #: ___________________________ Date Purchased: _____________________ Installation & Operation Manual Direct Steam Counter Tilting Kettles DC-6, DC-10, DC-12 and DC-20 Model DC-6 WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
Page 2: Safety
This manual should be retained for future reference. It is recommended that this manual be read thoroughly and that all instructions be followed carefully. Copyright © 2022 by Crown. All rights reserved. Published in the United States of America. PAGE OF 12 INSTALLATION &...
Page 3: Table Of Contents
Direct Steam Counter Tilting Kettles Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Safety ............................ 2 Service Connections ......................4 Introduction ........................... 5 Installation ..........................6 Operation ..........................7 Cleaning ..........................8 Preventive Maintenance ....................... 9 INSTALLATION &...
Page 4: Service Connections
BACK 3” [76mm] DC-12 70 lbs. [32 kg] DC-20 95 lbs. [43 kg] As continued product improvement is a policy of Crown, specifications are subject to changge without notice. PAGE OF 12 INSTALLATION & OPERATION MANUAL 10076 REV 6 (04/22)
Page 5: Introduction
Direct Steam Counter Tilting Kettles Introduction Introduction Description All direct connected steam jacketed kettles pertaining to this manual are direct steam operated pressure vessels of a double-wall stainless steel construction forming a steam chamber (jacket) enveloping the lower two thirds of the kettle bowl surface.
Page 6: Installation
1. These kettles must be installed on a suitable table or counter top. 2. On counter top make 7/8” holes at 13 - 3/4” centers for kettle legs on models DC-6, DC-10, and DC-12, 23-1/2” centers on Model DC-20. Provide sufficient space from rear wall to allow for tilting of kettle.
Page 7: Operation
Direct Steam Counter Tilting Kettles PERATION Operation WARNING The kettle and its parts are hot. Use care when operating, cleaning and servicing the appliance. Operating Instructions 1. Fill kettle with product to desired level. 2. Slowly turn the steam control valve ON to full open position. 3.
Page 8: Cleaning
Cleaning Direct Steam Counter Tilting Kettles Cleaning WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING Never spray water into electric controls or components! CAUTION The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION Do not use cleaning agents that are corrosive.
Page 9: Preventive Maintenance
Direct Steam Counter Tilting Kettles Preventive Maintenance Preventive Maintenance General Maintenance No general maintenance is required other than adhering to the Cleaning Procedure Instructions. Safety Valve Maintenance And Testing CAUTION Under normal operating conditions a “try lever test” should be performed every two months. Under severe service conditions, or if corrosion and/or deposits are noticed within the valve body, testing must be performed more often.
Page 10 Direct Steam Counter Tilting Kettles NOTES PAGE OF 12 INSTALLATION & OPERATION MANUAL 10076 REV 6 (04/22)
Page 11 Direct Steam Counter Tilting Kettles NOTES INSTALLATION & OPERATION MANUAL 10076 REV 6 (04/22) PAGE OF12...
Page 12 DIRECT STEAM COUNTER TILTING KETTLES A product with the Crown name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
