Green
Green flashing
You generally use the nShield Edge in Operational (O) mode, but you must put it into
Initialization (I) mode when creating the Security World.

7.2. Changing the mode

To change the mode:
1. Use the Mode button to highlight the required mode.
2. Within a few seconds, press and hold the Clear button for a couple of seconds.
If the mode changes, the new mode's LED stops flashing and remains lit. The Status LED
might flash irregularly for a few seconds and then flashes regularly when the nShield
Edge is ready.
Otherwise, the nShield Edge remains in the current mode, with the appropriate mode
LED lit.

7.3. Status LED

Long blue flash
Short blue flash
Irregular flash
Off
If the Status LED flashes irregularly and the nShield Edge is unresponsive for more than a
few minutes, see Troubleshooting.
nShield® Edge Installation Guide
In Operational mode
Operational mode selected
In Operational mode
In Maintenance or Initialization mode
Changing mode or processing data
No power
