H-8675
8' LAGUNA BENCH
TOOL NEEDED
Power Drill
3/8" Spacer x 2
Left Leg x 1
CAUTION! Do not drive attachment screws too
deeply, as the screw could protrude through
slat on the seating side of bench.
1. Verify all parts are present before beginning.
2. With one person holding the left leg and another
person holding the right leg, insert a rounded-edge
board between each leg, in line with the front of
the legs. From underneath, attach the front board
to the supports by fastening screws through the
pre-drilled holes on the underside of the leg. Do not
overtighten. (See Figure 1)
PAGE 1 OF 6
1-800-295-5510
uline.com
Two Person Assembly
Phillips Bit
(Optional)
Seat and Back
Board x 6
Center Leg x 2
PARTS
Right Leg x 1
ASSEMBLY
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Front and Top Board
with Rounded Edge x 2
2" Screw x 96
Figure 1
1020 IH-8675
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for U-Line H-8675
Summary of Contents for U-Line H-8675
- Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-8675 1-800-295-5510 uline.com 8' LAGUNA BENCH TOOL NEEDED Two Person Assembly Phillips Bit Power Drill (Optional) PARTS Seat and Back Front and Top Board 3/8" Spacer x 2...
- Page 2 ASSEMBLY CONTINUED 3. Repeat step 2 for the top rounded-edge board. (See Figure 2) Figure 2 4. Place middle supports evenly spaced at the center point of the top and front installed slats. From underneath, attach slats to middle supports at the pre-drilled holes using the Phillips head screws.
- Page 3 H-8675 800-295-5510 uline.mx BANCA LAGUNA DE 8' HERRAMIENTAS NECESARIAS Dos Personas para el Broca Taladro Ensamble (Opcional) PARTES 2 Espaciadores de 3/8" 6 Tablas de Asiento y Respaldo 2 Tablas Frontal y Superior con Borde Redondeado 96 Tornillos de 2"...
- Page 4 CONTINUACIÓN DE ENSAMBLE 3. Repita el paso 2 para la tabla superior con bordes redondeados. (Vea Diagrama 2) Diagrama 2 4. Coloque los soportes intermedios simétricamente espaciados en el punto central de la tabla superior y la frontal ya instaladas. Por debajo, fije las tablas a los soportes intermedios por los orificios preperforados utilizando los tornillos de cruz.
- Page 5 H-8675 1-800-295-5510 uline.ca BANC DE STYLE LAGUNA – 8 pi OUTILS REQUIS Embout Montage à deux Perceuse cruciforme personnes (optionnel) PIÈCES Entretoise de 3/8 po x 2 Planchette de dossier et de siège x 6 Planchette frontale et supérieure à bords arrondis x 2...
- Page 6 MONTAGE SUITE 3. Répétez l'étape 2 pour la planche supérieure à bords arrondis. (Voir Figure 2) Figure 2 4. Placez les pieds centraux à intervalles réguliers au niveau du point central des planchettes supérieures et frontales. Fixez les planchettes aux supports centraux, par en dessous, à...
