Front Panel - FWF 80F-2R Series
81F-2R
WiFi
STATUS 1 3
HA
POWER
2 4
1 2 3
FortiWiFi 81F-2R
1
LOGO
Blue: The device is on
Off: The device is off
2
STATUS Green: Operating normally; BLE is off
Flashing
Flashing Amber:
HA Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
POWER Green: Both power supplies are functioning
Amber: One power supply is functioning
Off: Power is off
Green: WiFi connected
WIFI
Flashing
Off: WiFi is off
3
Flashing
PORT
Off: No link established
LINK/ACT
4
WAN Flashing
Off: No link established
(WAN & SFP
are Shared Ports)
5
Flashing
SFP
Off: No link established
6
BLE/RESET Restores factory default and BLE settings
12
5 A WAN1 SFP1
6 B WAN2 SFP2
4 5
Green: Booting up
BLE is on
Green: WiFi activity
Green: 1000M/100M/10M data activity
Green: 1000M/100M/10M data activity
Green: 1000M/100M/10M data activity
BLE / RESET
6
