Box Includes - FWF 80F-2R Series
81F-2R
WiFi
STATUS 1 3
HA
POWER
2 4
FortiWiFi-80F/81F/-2R
Power Cable
Ethernet Cable
Wall Mount Kit
(Not included, sold separately)
10
5 A WAN1 SFP1
6 B WAN2 SFP2
QuickStart Guide
12V DC Power Adapter
3 WiFi Antennas
Wall Mount Hardware
(Not included, sold separately)
Back Panel - FWF 80F-2R Series
WiFi
CONSOLE
BLE / RESET
1
1 Antenna Connection (SMA) passive directional antenna connection
2
Console (RJ-45) CLI management computer interface
USB (USB A) USB 3.0 server port
3
SFP Shared Ports 1 & 2 (SFP) 1 Gbps SFP interface
4
WAN Shared Ports 1 & 2 (RJ45) 1 Gbps Ethernet interface
5
Ports 1 to 6 (RJ-45) 1 Gbps Ethernet interface
6
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet interface
7
Power Input 12V DC 5A, 100-240V AC 50/60Hz
(optional redundant power adapter and cable available for purchase)
WiFi
1
SFP 1 – shared – WAN 1
USB SFP 2 – shared – WAN 2 2
2 3 4 5
SCAN
3 5 A
4 6 B
6
7
