OWNER / OPERATOR MANUAL
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
APPLICABLE SERIAL NUMBERS :
DRIVE UNIT 100101 and up
HANDHELD BLOWER
HBZ2500
ENGINE UNIT 100101 and up
Thank you for purchasing a RedMax
product.
Before using our blower, please read
this manual carefully to understand the
proper use of your unit.
T4022-96110 (111)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HBZ2500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RedMax HBZ2500

Summary of Contents for RedMax HBZ2500

  • Page 1 California to cause cancer, birth defects or other reproductive harm. APPLICABLE SERIAL NUMBERS : DRIVE UNIT 100101 and up HBZ2500 Thank you for purchasing a RedMax product. Before using our blower, please read this manual carefully to understand the proper use of your unit.

  • Page 2: Safety First

    Instructions contained in warnings within this manual and warning seals marked with a symbol on the blower concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail.

  • Page 3: Table Of Contents

    SAFETY PRECAUTIONS················································································ 4 OPERATOR USE OF BLOWER WORKING CONDITION AVOID NOISE PROBLEM AVOID CHANCES OF DAMAGE SYMBOLS ON THE MACHINE ······································································· 7 PARTS LOCATION & SPECIFICATIONS ······················································· 8 ASSEMBLY······································································································ 8 BLOWER PIPE FUEL················································································································ 9 HOW TO MIX FUEL FUELING THE UNIT OPERATION ··································································································...

  • Page 4: Safety Precautions

    OPERATOR • Refrain from operating the blower if you are tired, ill, or upset, or if you are under the influence of alcohol, drugs or medication. • Always wear eye protection goggles.

  • Page 5: Working Condition

    • Avoid using any accessory or attachment other than those bearing the RedMax mark for use with the blower. • When suspending a job or inspecting the blower, be sure to stop engine.

  • Page 6: Avoid Noise Problem

    • Check if the air filter, air intakes and muffler are working in properly. • Never use more than one unit of the blower at a time. AVOID CHANCES OF DAMAGE • Avoid directing the blower nozzle toward...

  • Page 7: Symbols On The Machine

    REFER TO OWNER’S MANUAL FOR MAINTE- NANCE SPECIFICATIONS AND ADJUSTMENTS. KOMATSU ZENOAH CO. Use RedMax 50:1 Oil ! For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be careful not to take a mistake.

  • Page 8: Parts Location & Specifications

    Max. Air Velocity Noise Level (ANSI B175.2-2000) Assembly BLOWER PIPE • Align groove in blower pipe with projection on blower housing (or another blower pipe) and slide the pipe onto the blower housing (or another blower pipe). Rotate the pipe clockwise to lock it into place.

  • Page 9: Fuel

    3m(10ft) away from the fueling point before starting the engine. • The RedMax engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If RedMax oil is not available, use an anti-oxidant added quality oil expressly labeled for air-cooled 2-cycle engine use.

  • Page 10: Operation

    2. Pump the primer until fuel flows out in the clear tube. 3. Move the choke lever upward to close the choke. 4. Holding the blower handle, pull the starter rope with your right hand. (Throttle lever in idling position.) NOTE Avoid pulling the rope to its dead end or returning it by releasing the knob.

  • Page 11: Maintenance

    • Make sure that the engine has stopped and is cool before performing any service to the blower. Contact with rotating blower fan or hot muffler may result in a personal injury. AIR CLEANER • C h e c k the air cleaner every 25 hours of use or more frequently if used under dusty conditions.

  • Page 12: Muffler

    WARNING • Never use the blower without the screen at the air intake of the blower. Before each use, check that the screen is attached in place and is free from any...

  • Page 13: Storage

    • Install the screw through the stopper to insure that the air inlet screen does not move Storage BEFORE STORING THE BLOWER: 1.Drain a fuel tank and push the primer bulb until it becomes empty of fuel. 2.Remove the spark plug and drop a spoonful of 2-cycle oil into the cylider.

  • Page 14: Troubleshooting Guide

    (exhaust port) air cleaner When your unit seems to need further service, please consult with our RedMax service shop in your area. PROBABLE CAUSES incorrect fuel fuel filter is clogged out of normal range...

  • Page 15: Parts List

    (7) years after the machine is discontinued. It is also possible that some parts may be available even after the limit of seven (7) years.] APPLICABLE SERIAL NUMBERS : DRIVE UNIT 100101 and up HBZ2500 ENGINE UNIT 100101 and up Nov. 2001...
  • Page 16 Parts List Fig.1 ENGINE GROUP HBZ2500...
  • Page 17 Fig.1 ENGINE GROUP HBZ2500 Key# Part Number Description 4810-12111 CYLINDER 4810-12210 GASKET 4820-12130 BOLT TORX, M5x22 4810-13162 INSULATOR T1512-13120 GASKET, INSU 4810-13130 GASKET, CARB 4820-13180 BOLT TORX, M5x20 4810-16100 REEDVALVE-A(S) 4810-16110 • VALVECASE(S) 4810-16120 • REEDVALVE 4810-16130 • STOPPER 4810-16170 •...
  • Page 18 Parts List Fig.2 BLOWER GROUP HBZ2500...
  • Page 19 Fig.2 BLOWER GROUP HBZ2500 Key# Part Number Description 6811-11110 VOLUTE CASE T4022-11300 VOLUTE COVER-A 1600-33130 SCREW T4970-52001 SCREW TORX 6811-11130 GURG NET 6811-11160 STOPPER T4970-51410 SCREW TORX 6811-11150 LEVER 6811-72200 SWITCH T4022-11210 ENGINE COVER 4820-85510 SCREW TORX T4960-53510 SCREW TORX...

  • Page 20: California Emission Control Warranty Statement

    CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS THE CALIFORNIA AIR RESOURCES BOARD AND KOMATSU ZENOAH Co. ARE PLEASED TO EXPLAIN THE EMISSION CONTROL SYSTEM WARRANTY ON YOUR 1995 AND LATER LAWN AND GARDEN EQUIPMENT ENGINE. IN CALIFORNIA, NEW UTILITY AND LAWN AND GARDEN EQUIPMENT ENGINES MUST BE DESIGNED, BUILT AND EQUIPPED TO MEET THE STATE'S STRINGENT ANTI-SMOG STANDARDS.
  • Page 21 ZENOAH AMERICA INC. AT (770)-381-5147. IMPORTANT: YOU WILL RECEIVE A WARRANTY REGISTRATION CARD AT TIME OF PURCHASE. PLEASE FILL OUT THE CARD AND SEND IT TO RedMax / KOMATSU ZENOAH AMERICA WITHIN SEVEN (7) DAYS. BE SURE TO KEEP A COPY FOR YOUR RECORDS.
  • Page 22 (2) ans à compter de la date initiale de livraison d’une unité du modèle HBZ2500. Les pièces en rapport avec les émissions de gaz d'échappement sont: l'assemblage carburateur, l'assemblage bobine, le rotor, la bougie, le filtre à...
