Greenfire GF55 Technical Manual
Freestanding and fireplace insert pellet stove
Hide thumbs
Also See for GF55:
- Technical manual (32 pages) ,
- Owner's manual (20 pages) ,
- Owner's manual (16 pages)
Table of Contents
Advertisement
French Manual: https://bit.ly/3l4sqbo
Manuel en Français : https://bit.ly/3l4sqbo
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause injury,
property damage, or loss of life.
Refer to this manual. For assistance or
additional information consult an authorized
installer or service agency.
Tested by:
IMPORTANT: SAVE THESE INSTRUCTIONS
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 VENTURE ST., DELTA, BC, CANADA V4G 1H4
919-572e
Greenfire
TECHNICAL MANUAL
Freestanding and Fireplace
Insert Pellet Stove
GF55 & GFI55
®
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or
any other appliance.
Installation and service must be performed
by an authorized installer or service agency.
0268PM025E
06.20.22
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Greenfire GF55
Summary of Contents for Greenfire GF55
- Page 1 Greenfire GF55 & GFI55 ® TECHNICAL MANUAL Freestanding and Fireplace Insert Pellet Stove French Manual: https://bit.ly/3l4sqbo Manuel en Français : https://bit.ly/3l4sqbo WARNING: FOR YOUR SAFETY: Improper installation, adjustment, alteration, Do not store or use gasoline or other flammable service or maintenance can cause injury, vapours and liquids in the vicinity of this or property damage, or loss of life.
- Page 2 The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit. Emissions and Efficiency - GF55 / GFI55: This manual describes the installation and operation of the Regency GF55/GFI55 pellet heaters. This heater is U.S. ENVIRONMENTAL PROTECTION AGENCY certified to comply with 2020 particulate emission standards.
-
Page 3: Table Of Contents
Vertical Rise with Horizontal Termination ....13 GFI55 Pellet Insert ..........27 Through Concrete Wall with Vertical Rise .....13 Inside Vertical Installations .........13 WARRANTY Outside Vertical Installations .......14 Hearth Mount Installations ........14 Warranty ..............28 Exclusions and Limitations ........29 Greenfire Pellet Stove and Insert Technical Manual... -
Page 4: Safety Label
(Refer to page 18 in the manual) Once the Surround has Locate the rating plate on the GF55 by lifting up the hopper lid. been removed the rating plate will be located on the top of the unit as The rating plate will be located on the underside of the hopper lid. -
Page 5: Unit Dimensions
(620mm) " 24" (586mm) (610mm) " (146mm) 3" (76mm) " (41mm) " (866mm) " (508mm) " " (516mm) (356mm) " " (371mm) (319mm) " " 1" (291mm) (170mm) (25mm) 1" (25mm) " (145mm) Greenfire Pellet Stove and Insert Technical Manual... -
Page 6: Gfi55 Fireplace Pellet Insert
" (567mm) (567mm) " (35mm) " (35mm) FACEPLATE DIMENSIONS Regular Faceplate (A) Height 30" (761mm) (B) Width 39-15/16" (1014mm) Oversize Faceplate " (538mm) (A) Height 33" (838mm) (B) Width 45-15/16" (1167mm) " (609mm) Greenfire Pellet Stove and Insert Technical Manual... -
Page 7: Installation
A Greenfire dealer will fly ash. This is a very mild abrasive and will not damage the glass. -
Page 8: Removing Pellet Stove From Pallet
See figure 1. Figure 2: Removing GFI55 From Pallet. Figure 1: Removing GF55 From Pallet. OPENING THE DOOR The door lever can be found inbehind the right side of the door frame. To open the door, pivet the lever outwards and upwards until it unlocks. -
Page 9: Gf55 Freestanding Pellet Stove
*NOTE: If the unit is installed as a corner installation, clearances change from 2" to 3", see "Corner thru Wall Installation" section. Figure 4: Minimum Clearances to Combustibles Figure 6: Mobile Home Install Mounting Greenfire Pellet Stove and Insert Technical Manual... -
Page 10: Vent Termination Requirements
5. If the unit is incorrectly vented or the air to fuel mixture is out of balance, a slight discoloration of the exterior of the house might occur. Since these factors are beyond the control of FPI, we grant no guarantee against such incidents. NOTE: Venting terminals shall not be recessed into walls or siding. Greenfire Pellet Stove and Insert Technical Manual... -
Page 11: Exhaust & Fresh Air Intake Location
(508mm) " (356mm) 3" (7.5 cm) Wall thimble manufactured by pellet vent manufacturer. " " 1" (291mm) (170mm) (25mm) Figure 8: Freestanding Inlet and Outlet Location 3" (7.5 cm) Figure 10: Corner Installation Greenfire Pellet Stove and Insert Technical Manual... -
Page 12: Horizontal Exhaust Through Wall Install
45° elbow can be used as termination. The elbow must be turned down to prevent rain from entering. Figure 12: Straight through Wall Installation - Side View Greenfire Pellet Stove and Insert Technical Manual... -
Page 13: Vertical Rise With Horizontal Termination
Vertical vent pipe Clean out tee with Pipe adapter NOTE: All vent sections must maintain 3" (76 mm) clearances to combustibles. Figure 15: Inside Vertical Installation Figure 14: Vertical rise with Horizontal Termination Greenfire Pellet Stove and Insert Technical Manual... -
Page 14: Outside Vertical Installations
Combustible Floor the ash dump. 3" (7.5cm) Support Figure 17: Hearth Mount - Side View bracket Tee with cleanout Type "L", "PL" or all fuel vent Fresh air intake Figure 16: Outside Vertical Installation Greenfire Pellet Stove and Insert Technical Manual... -
Page 15: Gfi55 Pellet Insert
To lock the bolts at a height tighten the hex nut and washer against the square bolt. Leveling Legs Figure 22: Installing Pedestal Figure 25: Hopper Extension Screw Placement Figure 23: Square Bolt Greenfire Pellet Stove and Insert Technical Manual... -
Page 16: Exhaust & Fresh Air Intake Location
2" ID Protection Optional back of the fireplace (51 mm) Elbow or through the ash Combustible Floor Masonry Fireplace dump. Figure 28: Installation of Fireplace Insert Figure 27: Outside Air Connection Greenfire Pellet Stove and Insert Technical Manual... -
Page 17: Positive Flue Connection Without A Full Reline (Usa Only)
If the fireplace insert does not fit into a zero clearance fireplace we rec- the damper plate, may be removed from the smoke shelf and adjacent ommend you use an Greenfire freestanding model and install as a hearth damper frame if necessary to accommodate a chimney liner. Provided that mounted unit. -
Page 18: Control Panel In Surround Panel
Using four (4) T-20 screws up through the side panels into the top (see Figure 32). Figure 33: Installed Surround Panel Figure 32: Assembled Surround Panel Greenfire Pellet Stove and Insert Technical Manual... -
Page 19: Plated Door Installation
Clean all plated surfaces before starting the stove. Refer to "Cleaning wire and install Plated Surfaces in Routine Cleaning and Maintenance in the Owner's Manual. thermostat wires here. Figure 38: Thermostat wire placement Figure 37: Inner side of door Greenfire Pellet Stove and Insert Technical Manual... -
Page 20: Slider/Damper Set
(see Figure 41). The best settings are a reading of approximately 0.1" to 0.12" of water column on the high fire set- ting. Some fuels may require higher or lower settings. Greenfire Pellet Stove and Insert Technical Manual... -
Page 21: Troubleshooting
Blocked Hose Barb on Exhaust Channel - Use a paper clip to clean out Hose Barb or remove the Vacuum Hose from the Vacuum Switch and blow into the hose to remove blockage. Greenfire Pellet Stove and Insert Technical Manual... - Page 22 If the stove goes out and there are partially burned pellets left in the burn pot liner, the stove has shut down due to a lack of air, exhaust temperature, or power failure. Adjust the Slider / Damper. Check to see if the stove needs a more complete cleaning. Did the power go out? Contact your local Dealer for service. Greenfire Pellet Stove and Insert Technical Manual...
-
Page 23: Wiring Diagram
Black White Thermostat Yellow Auger Motor 5 Amp Fuse Convection Blower Black Yellow White Blue Brown White Brown Purple Purple Grey Grey Orange High Limit Orange Temperature Switch 200 °F Connect Thermostat Here Greenfire Pellet Stove and Insert Technical Manual... -
Page 24: Parts List
Control Panel W/Decal GFI55 GF55-026 Heyco Strain Relief 32) GFI55-910 Faceplate Regular GFI55 GF55-027 Sholder Bolt, Roll, Nut GF55/GFI55 2 Set 33) GFI55-912 Faceplate Oversize GFI55 11) GF55-028 Glass Side GF55/GFI55 34) GF55-921 Door Overlay Brush Nickel GF55 / GFI55... -
Page 25: Pellet Stove Components
PARTS LIST PELLET STOVE COMPONENTS Greenfire Pellet Stove and Insert Technical Manual... -
Page 26: Gf55 Freestanding Pellet Stove
PARTS LIST GF55 FREESTANDING PELLET STOVE Greenfire Pellet Stove and Insert Technical Manual... -
Page 27: Gfi55 Pellet Insert
PARTS LIST GFI55 PELLET INSERT Greenfire Pellet Stove and Insert Technical Manual... -
Page 28: Warranty
All claims must be complete and provide full details as requested by FPI to receive consideration for evaluation. Incomplete claims may be rejected. Revision Date: February 2019 Regency Pellet Products Warranty Greenfire Pellet Stove and Insert Technical Manual... -
Page 29: Exclusions And Limitations
Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: February 2019 Regency Pellet Products Warranty Greenfire Pellet Stove and Insert Technical Manual... - Page 30 To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx within ninety (90) days of purchase. Revision Date: February 2019 Regency Pellet Products Warranty Greenfire Pellet Stove and Insert Technical Manual...
- Page 31 For fireplace care and tips and answers to most common questions please visit our Customer Care section on our Web Site. Please feel free to contact your selling dealer if you have any questions about your Regency product. Greenfire Pellet Stove and Insert Technical Manual...
- Page 33 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________ Greenfire Pellet Stove and Insert Technical Manual...
- Page 34 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________ Greenfire Pellet Stove and Insert Technical Manual...
- Page 36 Dealer Name & Address: _______________________________________ ___________________________________________________________ Installer: ___________________________________________________ Phone #: ___________________________________________________ Date Installed: _______________________________________________ Serial #: ____________________________________________________ Printed in Canada Greenfire is a trademark of FPI Fireplace Products International Ltd. © Copyright 2022, FPI Fireplace Products International Ltd. All rights reserved.
