WARNING:
Improper installation, adjustment, alteration,
s e r v i c e
o r
m a i n t e n a n c e
injury, property damage, or loss of life.
Refer to this manual. For assistance or
additional information consult an authorized
installer or service agency.
Tested by:
GF55-919-572
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
Greenfire® GF55 & GFI55
Freestanding and Fireplace
c a n
c a u s e
IMPORTANT: SAVE THESE INSTRUCTIONS
TECHNICAL MANUAL
Insert Pellet Stove
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by an
authorized installer or service agency.
11.10.15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GF55 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Greenfire GF55

  • Page 1 Greenfire® GF55 & GFI55 TECHNICAL MANUAL Freestanding and Fireplace Insert Pellet Stove WARNING: FOR YOUR SAFETY: Improper installation, adjustment, alteration, Do not store or use gasoline or other flammable s e r v i c e m a i n t e n a n c e...
  • Page 2 The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit. Rates: This manual describes the installation and operation of the Regency GF55/GFI55 pellet heater. This heater meets the 2015 U.S. Environmental Protection Agency’s wood emission limits for wood emission limits sold after May 15, 2015.
  • Page 3: Table Of Contents

    Vertical Rise with Horizontal Termination ....13 GFI55 Pellet Insert............27 Through Concrete Wall with Vertical Rise ....13 Inside Vertical Installations ........13 WARRANTY Outside Vertical Installations ........14 Hearth Mount Installations ........14 Warranty ..............28 Exclusions and Limitations ..........29 Greenfire Pellet Stove and Insert Technical Manual...
  • Page 4: Safety Label

    GF55 & GFI55. We have printed a copy of the contents here for your reference. On the GF55 the safety label is located on the underside of the hopper lid. On the GFI55 the safety label is located on the hopper cover behind the top faceplate.
  • Page 5: Unit Dimensions

    (620mm) " 24" (586mm) (610mm) " (146mm) 3" (76mm) " (41mm) " (866mm) " (508mm) " " (516mm) (356mm) " " (371mm) (319mm) " " 1" (291mm) (170mm) (25mm) 1" (25mm) " (145mm) Greenfire Pellet Stove and Insert Technical Manual...
  • Page 6: Gfi55 Fireplace Pellet Insert

    " (567mm) (567mm) " (35mm) " (35mm) FACEPLATE DIMENSIONS Regular Faceplate (A) Height 30" (761mm) (B) Width 39-15/16" (1014mm) Oversize Faceplate " (538mm) (A) Height 33" (838mm) (B) Width 45-15/16" (1167mm) " (609mm) Greenfire Pellet Stove and Insert Technical Manual...
  • Page 7: Installation

    If this power cord should become damaged, a replacement power cord must be purchased from a Greenfire dealer. This unit's maximum power requirement is 520 watts. Contact your local building or fire official to obtain a permit and any information on installation restrictions and inspection requirements for GLASS: Do not abuse the glass by striking or slamming the door.
  • Page 8: Removing Pellet Stove From Pallet

    See figure 1. Figure 2: Removing GFI55 From Pallet. Figure 1: Removing GF55 From Pallet. OPENING THE DOOR The door lever can be found inbehind the right side of the door frame. To open the door, pivet the lever outwards and upwards until it unlocks.
  • Page 9: Gf55 Freestanding Pellet Stove

    *NOTE: If the unit is installed as a corner installation, clearances change from 2" to 3", see "Corner thru Wall Installation" section. Figure 4: Minimum Clearances to Combustibles. Figure 6: Mobile Home Install Mounting. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 10: Vent Termination Requirements

    5. If the unit is incorrectly vented or the air to fuel mixture is out of balance, a slight discoloration of the exterior of the house might occur. Since these factors are beyond the control of FPI, we grant no guarantee against such incidents. NOTE: Venting terminals shall not be recessed into walls or siding. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 11: Exhaust & Fresh Air Intake Location

    (508mm) " (356mm) 3" (7.5 cm) Wall thimble manufactured by pellet vent manufacturer. " " 1" (291mm) (170mm) (25mm) Figure 8: Freestanding Inlet and Outlet Location. 3" (7.5 cm) Figure 10: Corner Installation. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 12: Horizontal Exhaust Through Wall Install

    45° elbow can be used as termination. The elbow must be turned down to prevent rain from entering. Figure 12: Straight through Wall Installation - Side View. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 13: Vertical Rise With Horizontal Termination

    Vertical vent pipe Clean out tee with Pipe adapter NOTE: All vent sections must maintian 3" (76 mm) clearances to combustibles. Figure 15: Inside Vertical Installation. Figure 14: Vertical rise with Horizontal Termination. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 14: Outside Vertical Installations

    Combustible Floor the ash dump. (7.5cm) Support Figure 17: Hearth Mount - Side View. bracket Tee with cleanout Type "L", "PL" or all fuel vent Fresh air intake Figure 16: Outside Vertical Installation. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 15: Gfi55 Pellet Insert

    To lock the bolts at a height tighten the hex nut and washer against the square bolt Leveling Legs Figure 22: Installing Pedestal. Figure 25: Hopper Extension Screw Placement. Figure 23: Square Bolt. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 16: Exhaust & Fresh Air Intake Location

    Protection 2" ID Optional back of the fireplace (51 mm) Elbow or through the ash Combustible Floor Masonry Fireplace dump. Figure 28: Installation of Fireplace Insert. Figure 27: Outside Air Connection. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 17: Positive Flue Connection Without A Full Reline (Usa Only)

    If the fireplace insert does not fit into a zero clearance fireplace we recom- the damper plate, may be removed from the smoke shelf and adjacent mend you use an Greenfire freestanding model and install as a hearth damper frame if necessary to accommodate a chimney liner. Provided that mounted unit.
  • Page 18: Control Panel In Surround Panel

    Using four (4) T-20 screws up through the side panels into the top (see Figure 32). Figure 33: Installed Surround Panel. Figure 32: Assembled Surround Panel. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 19: Plated Door Installation

    Clean all plated surfaces before starting the stove. Refer to "Clean- wire and install ing Plated Surfaces in Routine Cleaning and Maintenance in the Owner's thermostat wires here. Manual. Figure 38: Thermostat wire placement. Figure 37: Inner side of door. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 20: Slider / Damper Set

    (see Figure 41). The best settings are a reading of approxi- mately 0.1" to 0.12" of water column on the high fire setting. Some fuels may require higher or lower settings. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 21: Troubleshooting

    Blocked Hose Barb on Exhaust Channel - Use a paper clip to clean out Hose Barb or remove the Vacuum Hose from the Vacuum Switch and blow into the hose to remove blockage. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 22 Check to see if the stove needs a more complete cleaning. Turn the Heat Level up slightly (poor quality pellets will require slightly higher settings). Did the power go out? Contact your local Dealer for service. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 23: Wiring Diagram

    Black White Thermostat Yellow Auger Motor 5 Amp Fuse Convection Blower Black Yellow White Blue Brown White Brown Purple Purple Grey Grey Orange High Limit Orange Temperature Switch 200 °F Connect Thermostat Here Greenfire Pellet Stove and Insert Technical Manual...
  • Page 24: Parts List

    Control Panel W/Decal GFI55 GF55-026 Heyco Strain Releif 32) GFI55-910 Faceplate Regular GFI55 GF55-027 Sholder Bolt, Roll, Nut GF55/GFI55 2 Set 33) GFI55-912 Faceplate Oversize GFI55 11) GF55-028 Glass Side GF55/GFI55 34) GF55-921 Door Overlay Brush Nickel GF55 / GFI55...
  • Page 25: Pellet Stove Components

    PARTS LIST PELLET STOVE COMPONENTS Greenfire Pellet Stove and Insert Technical Manual...
  • Page 26: Gf55 Freestanding Pellet Stove

    PARTS LIST GF55 FREESTANDING PELLET STOVE Greenfire Pellet Stove and Insert Technical Manual...
  • Page 27: Gfi55 Pellet Insert

    PARTS LIST GFI55 PELLET INSERT Greenfire Pellet Stove and Insert Technical Manual...
  • Page 28: Warranty

    #, type of unit, problem, and part or parts requested. A copy of the bill of sale/ proof of purchase must also accompany any submitted claims, without this information the warranty will be invalid. To the Distributor: Sign and verify that work and information are correct. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 29: Exclusions And Limitations

    17. Damage to plated surfaces caused by fi ngerprints, scratches, melted items, or other external scores and residues left on the plated surfaces from the use of abrasive cleaners or polishes is not covered in this warranty. 18. The Limited Warranty does not cover tarnish, discoloration or wear on the plated surfaces. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 30 Retain all receipts for both service and/or parts which may have been replaced. Lack of service/ maintenance is the largest contributor to malfunction of an appliance and is not covered under the terms of this warranty. Greenfire Pellet Stove and Insert Technical Manual...
  • Page 31 NOTES ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ Greenfire Pellet Stove and Insert Technical Manual...
  • Page 32 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Greenfire is a trademark of FPI Fireplace Products International Ltd. © Copyright 2015, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
