BALLY S6000 MONTE CARLO - QUICK SET-UP GUIDE
1)
If this is a new set up, begin with setting up the progressive Cham II board. Make sure the
Mikohn Cham II Eprom is installed on the board as often times it is removed by the casino for security
reasons. If this is a pre-running machine and you have allowed your rechargeable battery to die on your
Cham II board then proceed to Step 2. If your Cham II is functioning properly and showing your correct
jackpot amount in the display window then proceed to Step 5 below.
2)
Make sure the display is hooked up and then power up the Mikohn box. Set up the on-board
options using the toggle switch and buttons with the display powered on. Use the following settings:
Menu = SYST
Test = OFF
Birth = OFF
Save to = RAMD
Show load = YES
Show C1 = YES
Symbol = NONE
Sound = Disable
Menu = ADDR
GRADDR = 4
ID ADDR = 64
RTE ADDR = OFF
MACH ADDR = 2
Advertisement
Table of Contents
Related Manuals for Bally MONTE CARLO S6000
Summary of Contents for Bally MONTE CARLO S6000
- Page 1 BALLY S6000 MONTE CARLO - QUICK SET-UP GUIDE If this is a new set up, begin with setting up the progressive Cham II board. Make sure the Mikohn Cham II Eprom is installed on the board as often times it is removed by the casino for security reasons.
- Page 2 Menu = DISP JP Limit = NO #displays = 1 JP Group = SA0 Mfile = 4 ODSpeed = 10 Font1 = FLIP18 Size = 60 You now need to program the parameters on your Cham II. If you want us to set up the Cham II board and charge (re-charge) the battery for you, ship the unit along with a $40 payment for services and return shipping expense.
- Page 3 Remove the main computer board and test the battery with your volt meter. If it is below 3.1 volts it needs to be replaced. A new battery should read 3.6 volts or higher. Note that batteries on Bally S6000 boards require extreme heat to remove properly. We have our station set at 415 degrees for proper removal.
- Page 4 If not already placed, install the personality chips U18 and U20 chips on the board. Remove the "mains" U28 and U43 chips. Temporarily install the U28 and U43 Clear chips in their positions. Place the board back into the machine. Press and continue to hold the "Test" and "Pseudo Coin" buttons on the board and power on.
- Page 5 If you do not have coin mechanics, and you are hand pay only: Parameter Setting 78lo 5000 1000...
