TMG -SDT36 Product Manual

36-in skid steer trencher
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT MANUAL
36-IN SKID STEER TRENCHER
MODEL: TMG-SDT36
Please read the product manual completely before assembly Check
against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your
requests
WWW.TMGINDUSTRIAL.COM
Toll Free:1-877-761-2819

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMG-SDT36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TMG TMG-SDT36

Summary of Contents for TMG TMG-SDT36

  • Page 1 PRODUCT MANUAL 36-IN SKID STEER TRENCHER MODEL: TMG-SDT36 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TO THE OWNER..........................2/22 SAFETY PRECAUTIONS........................3/22 TRENCHER ASSEMBLIES........................7/22 OPERATION INSTRUCTIONS......................10/22 MAINTENANCE INSTRUCTIONS.......................12/22 STORAGE INSTRUCTIONS........................13/22 SPECIFICATIONS..........................14/22 W W W. T M G I N D U S T R I A L . C O M P 1 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...

  • Page 3: To The Owner

    TO THE OWNER GENERAL COMMENTS Congratulations for having this trencher! Your trencher was carefully designed and manufactured to give you years of dependable service. Your trencher will require some minor maintenance(such as cleaning and lubricating) to keep it in top working condition. Be sure to observe all safety precautions and maintenance procedures as described in this manual.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS The trenchers are designed to be easy to use and maintain. They are operated by the skid steer auxiliary hydraulics. The trenchers mount to the toolbar or quick attach mechanism for easy mounting. BEFORE OPERATION 1. The operator must read the operation manual carefully before installation, operation or maintenance.
  • Page 5 SAFETY PRECAUTIONS These are common practices that may or may not be applicable to the products described in this manual. W W W. T M G I N D U S T R I A L . C O M P 4 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 6 SAFETY PRECAUTIONS W W W. T M G I N D U S T R I A L . C O M P 5 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 7 SAFETY PRECAUTIONS W W W. T M G I N D U S T R I A L . C O M P 6 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 8 TRENCHER ASSEMBLIE 1-1 TRENCHER ASSEMBLY W W W. T M G I N D U S T R I A L . C O M P 7 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...

  • Page 9: Trencher Assemblies

    TRENCHER ASSEMBLIES PART NO. PART DESCRIPTION QTYS NOTE 020736I-01 MOUNTING FRAME ASSEMBLY 020736I-02 PADDLE ASSEMBLY 020736I-03 CHAIN TENSION ASSEMBLY 020736I-04 CHAIN ASSEMBLY W W W . T M G I N D U S T R I A L . C O M P 8 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 10 TRENCHER ASSEMBLIES 1-2 MOUNTING FRAME ASSEMBLY W W W . T M G I N D U S T R I A L . C O M P 9 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 11 TRENCHER ASSEMBLIES PART NO. PART DESCRIPTION QTYS NOTE 020736I-01-01 ROTATION AUGER 020736I-01-02 BOLT M14x55 GB5783 020736I-01-03 FLAT WASHER D14 GB97.1 020736I-01-04 SPRING WASHER D14 GB93 020736I-01-05 NUT M16 020736I-01-06 SPRING WASHER D16 020736I-01-07 FLAT WASHER D16 020736I-01-08 CONNECTION BUSH 020736I-01-09 CHAIN WHEEL 020736I-01-10 GB2673...
  • Page 12 TRENCHER ASSEMBLIES PART NO. PART DESCRIPTION QTYS NOTE 020736I-01-17 REAR MOUNTING BRACKET 020736I-01-18 HEXAGON HEAD BOLT M16x60 GB5783 020736I-01-19 FLAT WASHER D16 020736I-01-20 SPRING WASHER D16 020736I-01-21 HEXAGON HEAD BOLT M16x50 020736I-01-22 MOTOR MOTOR USED SEALS 020736I-01-23 END THROUGH 020736I-01-24 END THROUGH 020736I-01-25 DISCHARGE OIL PIPE...
  • Page 13 TRENCHER ASSEMBLIES 1-3 MOUNTING FRAME ASSEMBLY W W W . T M G I N D U S T R I A L . C O M P 1 2 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 14 TRENCHER ASSEMBLIES PART NO. PART DESCRIPTION QTYS NOTE 020736I-02-01 BOLT M16x130 GB5783 020736I-02-02 SPRING WASHER D16 GB93 020736I-02-03 FLAT WASHER D16 GB97.1 020736I-02-04 CHAIN TENSION SET 020736I-02-05 BOLT M16x40 GB5783 020736I-02-06 NUT M16 GB6170 020736I-02-07 MOVABLE SET 020736I-02-08 HEXAGON SOCKET HEAD M20x130 GB70 020736I-02-09 NUT M20...
  • Page 15 TRENCHER ASSEMBLIES 1-4 SOIL BLADE ASSEMBLY W W W . T M G I N D U S T R I A L . C O M P 1 4 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 16 TRENCHER ASSEMBLIES PART NO. PART DESCRIPTION QTYS NOTE 020736I-03-01 BOLT M12x55 020736I-03-02 FLAT WASHER D12 020736I-03-02 SPRING WASHER D12 020736I-03-04 NUT M12 020736I-03-05 SOIL COLLECTION FRAME 020736I-03-06 BOLT M12x40 GB5783 020736I-03-07 TELESCOPIC INNER FRAME 020736I-03-08 BOLT M12x100 020736I-03-09 CONNECITONING ROD 020736I-03-10 FLAT WASHER D16 020736I-03-11...
  • Page 17 TRENCHER ASSEMBLIE 1-5 CHAIN ASSEMBLY W W W . T M G I N D U S T R I A L . C O M P 1 6 / 2 2 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 18 TRENCHER ASSEMBLIE PART NO. PART DESCRIPTION QTYS NOTE 020736I-04-01 CHAIN 58KNOTS 020736I-04-02 RIGHT ALLOY TOOTH 020736I-04-02 FLAT WASHER D12 GB97.1 020736I-04-04 BOLT M12x40 GB5783 020736I-04-05 LEFT COMMONG TOOTH 020736I-04-06 NUT M12 GB5783 020736I-04-07 SPRING WASHER D12 GB93 020736I-04-08 BOLT M12x35 GB5783 020736I-04-09 RIGHT COMMONG TOOTH...

  • Page 19: Operation Instructions

    OPERATION INSTRUCTIONS The trencher can dig a trench with 900mm depth and 200mm width. Attach the trencher to the toolbar or quick attach mechanism of your skid steer loader. RAISING OR LOWERING THE TRENCHER raise or lower the trencher by raising or lowering the skid steer loader arms through their appropriate skid steer controls.
  • Page 20 OPERATION INSTRUCTIONS AUGER HEIGHT The auger is fixed to the trencher mainframe and has no separate adjustment. To raise the auger, raise the trencher as previously described. This will raise the auger to leave the dirt or spoil closer to the trench. CHAIN TENSION ADJUSTMENT When trenching, the digging chain tension should be adjusted to let the chain is as loose as possible, without jumping off the sprocket or Idler wheel.

  • Page 21: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS 1. Always keep the clean hydraulic oil, keep the hose joint clean, if the hydraulic oil is mixed with dirt, it will possibly cause the whole operation system abnormally. 2. Daily check all hydraulic lines, make sure the connection of the hydraulic line good, the pipe without distortion, wear, cracking, no loose joint to leak.

  • Page 22: Storage Instructions

    STORAGE INSTRUCTIONS 1. Clean all the debris, all mud, dirt and grease. 2. Inspect the unit for bent, loose, cracked, damaged or missing parts, Order any parts required, and make the necessary repairs to avoid delays when starting next season. 3.

  • Page 23: Specifications

    SPECIFICATIONS MODEL TMG-SDT36 TOTAL LENGTH (MM) 1990 TOTAL WIDTH (MM) 1200 TOTAL HEIGHT (MM) TOTAL WEIGHT (KGS) @65°TRENCHIGN DEPTH (MM) TRENCHING WIDTH (MM) SYSTEM FLOW (L/MIN) 80-110 MAX. PRESSURE (MPA) W W W. T M G I N D U S T R I A L . C O M...
