101-1036: Mark 7® DecapSense APEX 10 /Evolution /
Revolution
Instruction Manual V 1.1
Read this manual completely. Understand all safety and operating instructions. Failure to
comply with the warnings and instructions may result in serious injury, illness or death.
DECAPSENSE EVOLUTION/REVOLUTION USER MANUAL VERSION 1.1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DecapSense APEX 10 and is the answer not in the manual?

Questions and answers

Related Manuals for Mark 7 DecapSense APEX 10

Summary of Contents for Mark 7 DecapSense APEX 10

  • Page 1 101-1036: Mark 7® DecapSense APEX 10 /Evolution / Revolution Instruction Manual V 1.1 Read this manual completely. Understand all safety and operating instructions. Failure to comply with the warnings and instructions may result in serious injury, illness or death. DECAPSENSE EVOLUTION/REVOLUTION USER MANUAL VERSION 1.1...
  • Page 2 Package Contents Please review these contents and inform us right away if you appear to be missing any of these items: Item No. Description DecapSense – APEX10/EVO/Rev 8-32 x 5/16” Socket Cap Screw Primer Offload Hose DecapSense Evolution/Revolution User Manual Version 1.1...
  • Page 3 Set-Up Procedures: Install sensor underneath station #2 using hardware included. 2X 8-32 x 5/16” Cap Screw 3/8” Clear Tube DecapSense Assembly Figure 1: DECAPSense® with Hose Installed Operating Instructions: 1. Locate DECAPSense underneath station #2. 2. Hook up the 3/8” Clear Tube to the bottom the DECAPsense to catch spent primers as they are decapped.
  • Page 4 4. As with all sensors the DecapSense can be enabled or disabled on the Sensors Tab screen. 5. During operation the optical sensor may become dirty and require cleaning. The following notification box MAY appear when cleaning is required: 6. Remove the case in station #2. Use an air can or compressed air and blast air down through the shell plate and thru the sensor.
  • Page 5 Troubleshooting Refer to the knowledge base section on our website under SUPPORT for troubleshooting articles relating to setup and operation. http://www.markvii-loading.com/knowledgebase Please contact us for technical support Phone: 1-888-462-7577 Hours: 9:00am-4:30pm, ET, M–F DECAPSENSE EVOLUTION/REVOLUTION USER MANUAL VERSION 1.1...

This manual is also suitable for:

Evolution apex 10Revolution apex 10101-1036
