Mark 7 PrimerSense 1050 Instruction Manual

Download this manual

101-1009: Mark 7® PrimerSense – 1050/RL1100

Instruction Manual V 1.1

Read this manual completely. Understand all safety and operating instructions. Failure to

comply with the warnings and instructions may result in serious injury, illness or death.

PRIMERSENSE – 1050/RL1100 INSTRUCTION MANUAL VERSION 1.1

Table of Contents

Need help?

Do you have a question about the PrimerSense 1050 and is the answer not in the manual?

Page 1 101-1009: Mark 7® PrimerSense – 1050/RL1100 Instruction Manual V 1.1 Read this manual completely. Understand all safety and operating instructions. Failure to comply with the warnings and instructions may result in serious injury, illness or death. PRIMERSENSE – 1050/RL1100 INSTRUCTION MANUAL VERSION 1.1...
Page 2 Package Contents Please review these contents and inform us right away if you appear to be missing any of these items: Item No. Description PrimerSense – 1050/RL1100 Thread Forming M2.26 X .91 T6 Drive Screw 8-32 Thread, 1-1/8" Long, Button Head Screw #8 Washer, 0.172"...
Page 3 Set-Up Procedures: Figure 1: New Style Left, Old Style Right 1. The PrimerSense mount works with both the new and old-style Dillon low primer alarms. • Mounting on the new style primer alarm requires the Torx screws that thread into existing holes inside (see below left).
Page 4 2. Insert the PrimerSense into I/O Port #1 shown below then enable on the sensors tab and perform a calibration before use. Figure 3: Port Layout Figure 4: Sensor Configuration Tab PrimerSense – 1050/RL1100 Instruction Manual Version 1.1...
Page 5 Troubleshooting Refer to the knowledge base section on our website under SUPPORT for troubleshooting articles relating to setup and operation. http://www.markvii-loading.com/knowledgebase Please contact us for technical support Phone: 1-888-462-7577 Hours: 9:00am-4:30pm, ET, M–F PRIMERSENSE – 1050/RL1100 INSTRUCTION MANUAL VERSION 1.1...
