  • Page 1 series USER’S MANUAL Analog Unit FEH527...
  • Page 2 FEH257 Describes the functions and the operations of SX-Programmer <Reference>, MICREX-SX series Expert. * In addition to the above manuals, the following Fuji Electric Co.,Ltd.site offers various manuals and technical documents associated with MICREX-SX series. URL http://www.fujielectric.com Notes 1. This manual may not be reproduced in whole or part in any form without prior written approval by the manufacturer.
  • Page 3 Safety Precautions Be sure to read the "Safety Precautions" thoroughly before using the module. Here, the safety precautions items are classified into "Warning" and "Caution". Warning : Incorrect handling of the device may result in death or serious injury. Caution : Incorrect handling of the device may result in minor injury or physical damage.
  • Page 4 Do not attempt to change system configurations (such as installing or removing expansion block) while the power is ON, otherwise, failure or erratic operation might occur. Do not attempt to repair the module by yourself, but contact your Fuji Electric agent, otherwise, fire, accident or failure might occur.
  • Page 5 Revision * The manual No. is printed at the bottom right of the cover of this manual. Printed on * Manual No. Revision contents Jan. 2017 FEH527 First edition...

  • Page 6: Table Of Contents

    Contents Contents Preface Safety Precautions Revision Contents Section 1 Overview 1-1 Product List ............................1-1 1-2 Features ............................1-1 1-2-1 Number of connectable units ........................1-1 1-2-2 Analog signal range setting function ......................1-1 1-2-3 Parameter setting function ..........................1-1 Section 2 Specifications 2-1 General Specifications ........................2-1 2-2 Functional/Performance Specifications ..................2-2 2-2-1 Specification list ............................2-2 2-2-2 Conversion characteristics ..........................2-6...

  • Page 7: Section 1 Overview

    Section 1 Overview 1-1 Product List The SPF series analog unit and temperature measurement unit include the following models. In this manual, these models are collectively called “analog unit.” Type Specification NA0AX06-MR Analog voltage/current input, 6 channels NA0AY02-MR Analog voltage/current output, 2 channels NA0AW06-MR Analog voltage/current input/output, Input 4 channels NA0AX06-TC...

  • Page 8: Section 2 Specifications

    Section 2 Specifications 2-1 General Specifications Item Specification Remark Physical Operating ambient 0 to +55°C IEC 61131-2 environmental temperature conditions Storage (transportation) -25 to +70°C temperature Relative humidity 20 to 95%RH, no condensation (Transport condition: 5 to 95%RH, no condensation) Pollution degree 2 (Note 1) Corrosion immunity...

  • Page 9: Functional/Performance Specifications

    Section 2 Specifications 2-2 Functional/Performance Specifications 2-2-1 Specification list (1) Analog input unit Item Specification Type NA0AX06-MR No. of input channels 6 channels Input impedance Voltage: 63.2 kW, Current: 250 W Maximum allowable input Voltage: ±15V, Current: ±30mA Input range -10 to +10V, -5 to +5V, 0 to 10V, 0 to 5V -20 to 20mA, -10 to 10mA, 0 to 20mA, 0 to 10mA (Collectively set for all channels by the jumper pin in the unit)
  • Page 10 Section 2 Specifications (2) Analog output unit Item Specification Type NA0AY02-MR No. of output channels 2 channels External load resistance Voltage output: 500 W to 1 MW, Current output: 0 to 500 W or less -10 to +10V, -5 to +5V, 0 to 10V, 0 to 5V Analog output range -20 to 20mA, -10 to 10mA, 0 to 20mA, 0 to 10mA (Collectively set for all channels by the jumper pin in the unit)
  • Page 11 Section 2 Specifications (3) Analog input/output unit Item Specification Type NA0AW06-MR No. of input channels 4 channels Input impedance Voltage: 63.2 kW, Current: 250 W Maximum allowable input Voltage: ±15V, Current: 30mA -10 to +10V, -5 to +5V, 0 to 10V, 0 to 5V Input range -20 to 20mA, -10 to 10mA, 0 to 20mA, 0 to 10mA (Collectively set for all channels by the jumper pin in the unit)
  • Page 12 Section 2 Specifications (4) Thermocouple input unit Item Specification Type NA0AX06-TC No. of input channels 6 channels Resolution 0.1°C or 1°C *1 Thermocouple type J, K, R, S, E, T, B, N (Collectively set for all channels by the jumper pin in the unit) Digital output value 12 bits: 0 to 4000 / -2000 to 2000, 14 bits: 0 to 16000 / -8000 to 8000 Temperature measurement range J: -200.0 to 1200.0°C...

  • Page 13: Conversion Characteristics

    Section 2 Specifications 2-2-2 Conversion characteristics (1) Analog input 1) 0 to 5V / 0 to 10mA (when set at UNIPOLAR) Digital output value (INT type) (4095) 16383 (4000) 16000 * The values in ( ) are the digital output values when “12 bits”...
  • Page 14 Section 2 Specifications 4) 0 to 10V / 0 to 20mA (when set at BIPOLAR) Digital otuput value (INT type) 8191 (2047) 8000 (2000) 0V/0mA Analog input voltage/current 10V/20mA * The values in ( ) are the digital output values when “12 bits”...
  • Page 15 Section 2 Specifications 7) -10 to 10V / -20 to 20mA (when set at UNIPOLAR) Digital output value (INT type) (4095) 16383 (4000) 16000 * The values in ( ) are the digital output values when “12 bits” is selected for the resolution. Analog input voltage/current -10V/-20mA...
  • Page 16 Section 2 Specifications (2) Analog output 1) 0 to 5V / 0 to 10mA (when set at UNIPOLAR) Analog output voltage/current 5V/10mA Digital input value (INT type) 16000 16383 2) 0 to 5V / 0 to 10mA (when set at BIPOLAR) Analog output voltage/current 5V/10mA...
  • Page 17 Section 2 Specifications 4) 0 to 10V / 0 to 20mA (when set at BIPOLAR) Analog output voltage/current 10V/20mA -8192 -8000 0V/0mA Digital input value (INT type) 8000 8191 5) -5 to 5V / -10 to 10mA (when set at UNIPOLAR) Analog output voltage/current 5V/10mA...
  • Page 18 Section 2 Specifications 7) -10 to 10V / -20 to 20mA (when set at UNIPOLAR) Analog output voltage/current 10V/20mA -8192 -8000 -10V/-20mA Digital input value (INT type) 8000 8191 8) -10 to 10V / -20 to 20mA (when set at BIPOLAR) Analog output voltage/current 10V/20mA...

  • Page 19: Names And Functions

    Section 2 Specifications 2-3 Names and Functions 2-3-1 Analog input unit (Type: NA0AX06-MR) (1) Names The jumper pins in the analog input unit are used to change the analog signal range and digital value range. Therefore, remove the upper cover and control board when setting the jumper pin. 2) Terminal block Expansion connector (OUT) Expansion connector (IN)
  • Page 20 Section 2 Specifications (2) Functions 1) Status indication LED Status indication LED Status Specification PWR of analog input unit ON (red) While 5V DC power is normally supplied. 2) Terminal block These are terminals for 24V DC power supply to operate the analog unit and analog input signal. * For the wiring method, refer to “2-4 Wiring.”...

  • Page 21: Analog Output Unit (Type: Na0Ay02-Mr)

    Section 2 Specifications 2-3-2 Analog output unit (Type: NA0AY02-MR) (1) Names The jumper pins in the analog output unit are used to change the analog signal range and digital value range. Therefore, remove the upper cover and control board when setting the jumper pin. 2) Terminal block Expansion connector (OUT) Expansion connector (IN)
  • Page 22 Section 2 Specifications (2) Functions 1) Status indication LED Status indication LED Status Specification PWR of analog output unit ON (red) While 5V DC power is normally supplied. 2) Terminal block These are terminals for 24V DC power supply to operate the analog unit and analog input signal. * For the wiring method, refer to “2-4 Wiring.”...

  • Page 23: Analog Input/Output Unit (Type: Na0Aw06-Mr)

    Section 2 Specifications 2-3-3 Analog input/output unit (Type: NA0AW06-MR) (1) Names The jumper pins in the analog input/output unit are used to change the analog signal range and digital value range. Therefore, remove the upper cover and control board when setting the jumper pin. 2) Terminal block Expansion connector (OUT) Expansion connector (IN)
  • Page 24 Section 2 Specifications (2) Functions 1) Status indication LED Status indication LED Status Specification PWR of analog input/output unit ON (red) While 5V DC power is normally supplied. 2) Terminal block These are terminals for 24V DC power supply to operate the analog unit and analog input signal. * For the wiring method, refer to “2-4 Wiring.”...
  • Page 25 Section 2 Specifications 6) JP3 and JP4: Analog input range selection Signal range JP3 setting JP2 setting 0 to 10V 0 to 20mA 0 to 5V 0 to 10mA -10 to 10V -20 to 20mA -5 to 5V -10 to 10mA 7) JP5 to 8: Input voltage/current selection This jumper pin is used to select voltage or current for each channel.

  • Page 26: Thermocouple Input Unit (Type: Na0Ax06-Tc)

    Section 2 Specifications 2-3-4 Thermocouple input unit (Type: NA0AX06-TC) (1) Names 2) Terminal block Expansion connector (IN) Expansion connector (OUT) Nameplate 1) Status indication LED 2) Terminal block (2) Functions 1) Status indication LED Status indication LED Status Specification PWR of thermocouple input unit ON (red) While 5V DC power is normally supplied.

  • Page 27: Wiring

    Section 2 Specifications 2-4 Wiring 2-4-1 Analog input (target type: NA0AX06-MR and NA0AW06-MR) NA0AX06-MR/NA0AW06-MR +15V 24V+ 24V DC External power supply CH0 Input (Voltage sou (Example of voltage input) CH1 Input (Current sou (Example of current input) Input (Voltage sou (Example of voltage input) Voltage/current selection Shielded twisted pair cable...

  • Page 28: Analog Output (Target Type: Na0Ay02-Mr And Na0W06-Mr)

    Section 2 Specifications 2-4-2 Analog output (target type: NA0AY02-MR and NA0W06-MR) NA0AY02-MR/NA0AW06-MR Output +15V 24V+ 24V DC External power supply Example of voltage output Voltage input Example of current output Current input Voltage/current selection Shielded twisted pair cable 2-21...

  • Page 29: Thermocouple Input (Target Type: Na0Ax06-Tc)

    Section 2 Specifications 2-4-3 Thermocouple input (target type: NA0AX06-TC) NA0AX06-TC 24V+ +24V DC External power supply TC0+ Thermocouple sensor TC1+ Thermocouple sensor TC5+ Thermocouple sensor Multiplexer J(K) extension cable 2-22...

  • Page 30: Dimensions

    Section 2 Specifications 2-5 Dimensions NA0AX06-MR (Analog input 6CH), NA0AY02-MR (Analog output 6CH), NA0AW06-MR (Analog input 4CH, Analog output 2CH), and NA0AX06-TC (Thermocouple input 6CH) have the same dimensions. Unit: mm 2-23...

  • Page 31: Section 3 Programming

    Section 3 Programming 3-1 Memory Assignment 3-1-1 Analog input unit * The unit No. registered in the system definition WXo.0 Channel 0 Digital output value (INT type) is entered in o. WXo.1 Channel 1 Digital output value (INT type) WXo.2 Channel 2 Digital output value (INT type) WXo.3 Channel 3 Digital output value (INT type)

  • Page 32: System Definition

    Section 3 Programming 3-2 System Definition 3-2-1 Registering units Connect the analog unit on the right of the basic unit or the unit that is connected on the right of the basic unit. <Example of system configuration> 24V OUT max. 400mA I2 I3 IN X Basic unit NA0AX06-MR OUT Y...

  • Page 33: Setting Parameters

    Section 3 Programming 3-2-2 Setting parameters (1) Analog input unit (Target type: NA0AX06-MR, NA0AW06-MR) Parameter Setting range Resolution 14 bits or 16 bits Moving average execution times 1 (No moving average) to 16 times <How to set parameters> 1) Right-click the analog unit registered in the system definition screen and left-click [Properties]. The “Module properties” dialog box opens.
  • Page 34 Section 3 Programming (2) Thermocouple input unit (Target type: NA0AX06-TC) For the thermocouple input unit, set the sensor type of the thermocouple, moving average execution times, sampling period, and unit. Parameter Setting range J: -200 to 1200°C K: -200 to 1200°C T: -190 to 380°C E: -190 to 1000°C Sensor type...
  • Page 35 Fuji Electric Co., Ltd. Gate City Ohsaki, East Tower, 11-2, Osaki 1-chome, Shinagawa-ku, Tokyo 141-0032, Japan E-mail: micrex-sx@fujielectric.com URL: http://www.fujielectric.com/ Materials covered in this document are subject to revision due to the modification of the product.
