Summary of Contents for Fuji Electric MONITOUCH TECHNOSHOT TS2060

Page 1 R e f e r e n c e M a n u a l [ 1 ]...
Page 2: Record Of Revisions
Record of Revisions Reference numbers are shown at the bottom left corner on the back cover of each manual. Printing Date Reference No. Revised Contents July, 2016 1204NE0 First edition September, 2016 1204NE0a Correction of errors August 2018 1204NE1 Second edition Added TS1000 Smart and VNC Server Partial modifications November, 2019...
Page 4 Preface Thank you for selecting MONITOUCH TECHNOSHOT (hereafter referred to as “TS”). For correct setup of the TS, you are requested to read through this manual to understand more about the product. For details on other operating procedures for the TS, refer to the following related manuals. Manual Name Contents Reference No.
Page 5 TS Types and Model Names The notations used in this manual and the corresponding models are as shown below. Notation Model TS2060i, TS2060, TS1100Si, TS1070Si, TS1070S TS2060i, TS1100Si, TS1070Si TS2060i TS2060i TS2060 TS2060 TS1000 Smart TS1100Si, TS1070Si, TS1070S TS1000S...
Page 6: Available Functions
Available Functions Note that functions available differ depending on the TS model. For details, refer to the related chapters. Functions Described in TS Reference Manual 1 (this manual) : Available : Conditionally available : Not available TS Reference Manual 1 TS1100Si TS2060i TS2060...
Page 7: System Setting
Functions Described in TS Reference Manual 2 : Available : Conditionally available : Not available TS Reference Manual 2 TS1100Si TS2060i TS2060 TS1070S Remarks TS1070Si Chapter Description 1 Image Display JPEG : 32k/64k colors only Network camera 2 Operation Log Operation log 3 Security Security...
Page 8 Notes on Safe Usage of MONITOUCH In this manual, you will find various notes categorized under the following levels with the signal words “DANGER” and “CAUTION”. Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. DANGER Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury and could CAUTION...
Page 9 CAUTION • Do not repair, disassemble, or modify the TS. Hakko Electronics Co., Ltd. is not responsible for any damages resulting from repair, disassembly, or modification of the unit that was performed by an unauthorized person. • Do not use sharp-pointed tools to press touch switches. Doing so may damage the display unit. •...
Page 10: Table Of Contents
Contents System System Settings 1.1.1 System Setting ..................................... 1-1 1.1.2 Unit Setting ......................................1-2 Edit Model Selection..................................1-2 Multi-language Setting ..................................1-4 Unit Setting ......................................1-6 1.1.3 Communication Setting .................................1-22 Hardware Setting ....................................1-22 Device Memory Map ..................................1-30 Ethernet Communication................................1-30 1.1.4 Common Setting ....................................1-31 Global Setting.....................................
Page 11 Multi-overlap 2.4.1 Creation Procedure ..................................2-18 2.4.2 Detailed Settings ....................................2-19 2.4.3 Show/Hide Settings ..................................2-21 Global Overlap 2.5.1 Creation Procedure ..................................2-26 2.5.2 Detailed Settings ....................................2-28 2.5.3 Show/Hide Settings ..................................2-30 2.5.4 Notes ........................................2-34 Switch Switch 3.1.1 Overview ........................................ 3-1 Basic Function of Switches ................................3-1 Lamps in Switches ....................................
Page 12 Character Display 5.2.1 Overview ......................................5-18 5.2.2 Detailed Settings ....................................5-19 Message Display 5.3.1 Overview ......................................5-26 5.3.2 Detailed Settings ....................................5-27 Table Data Display 5.4.1 Overview ......................................5-31 5.4.2 Table Data Settings ..................................5-31 5.4.3 Numerical Data Display Settings ..............................5-33 5.4.4 Character Display Settings ................................5-37 5.4.5 Message Display Settings ................................5-39 5.4.6...
Page 13 Trends Overview Historical Display....................................7-1 Real Time Display....................................7-1 Historical Display 7.2.1 Buffering Area ...................................... 7-2 Detailed Settings....................................7-3 Timing of Data Storage ..................................7-9 CSV Output ......................................7-9 Create Backup File .................................... 7-10 CSV Output & Creating Backup Files............................7-11 7.2.2 Graph Display .....................................7-12 Location of Setting ...................................
Page 14 8.3.2 Time Order Alarming ..................................8-47 Difference from Bit Order Alarming ............................8-47 Location of Settings ..................................8-47 Detailed Settings....................................8-48 Other Differences from Bit Order Alarming ........................... 8-49 8.3.3 Acknowledge Function ...................................8-51 Operation Overview..................................8-52 Location of Settings ..................................8-53 Display of Acknowledge Function Screen after Screen Change..................
Page 15 10 Calendar 10.1 Overview 10.2 Time Display 10.2.1 Overview ......................................10-3 10.2.2 Setting Examples ....................................10-4 Displaying the PLC Calendar ................................ 10-4 Displaying the Built-in TS Calendar ............................10-6 Display Using the Time Display Format Setting........................10-8 Displaying Seconds Data Stored in Device Memory in Timer Format ..............10-10 10.2.3 Detailed Settings ....................................
Page 16 13.2 Memory Card 13.2.1 Overview ......................................13-6 About the Memory Card Function ............................. 13-6 Applicable Media ....................................13-6 Procedures on TS ....................................13-7 13.2.2 Setting Example: Memory Card Settings ..........................13-8 13.2.3 Detailed Settings ....................................13-9 Memory Card...................................... 13-9 Display Area ..................................... 13-12 Memory Card Part Switches ..............................
Page 17 16 Print 16.1 Overview 16.1.1 Compatible Printers ..................................16-2 16.1.2 EPSON STYLUS PHOTO, STYLUS C86, and STYLUS C65 ....................16-3 16.1.3 PictBridge Printers ....................................16-6 16.1.4 PR201 and ESC-P Printers ................................16-10 16.1.5 CBM292/293 Printer ..................................16-13 16.1.6 Sato’s MR-400 Barcode Printer ..............................16-16 16.2 Hard Copy 16.2.1...
Page 18: System
System System Settings Process Cycle List of Internal Device Memory...
Page 20: System Settings
System Settings System Settings 1.1.1 System Setting System settings cover a variety of settings including those initially required for the TS unit to communicate with the PLC, unit settings, and screen program settings. This section only describes the settings important for initial setup. For details, refer to the relevant item.
Page 21: Unit Setting
1 System 1.1.2 Unit Setting This section explains the items in the [Unit Setting] group. For information on other settings, refer to “1.1.1 System Setting” page 1-1. Edit Model Selection Select the model of the TS for which you wish to configure a screen program. Location of setting: [System Setting] →...
Page 22 System Settings Specification Difference Between TS2060i and TS2060 Specifications TS2060i TS2060 Unit Specifications Screen size 5.7-inch Display device TFT color Resolution 320 × 240 dots Touch switch Analog resistive film type Power supply specifications DC power supply Function Screen program capacity (FROM) 10.5 MB 2.5 MB Backup memory (SRAM)
Page 23: Multi-Language Setting
1 System Multi-language Setting Select the language for display on the TS unit. Location of settings: [System Setting] → [Multi-language Setting]. For details, refer to “6 Language Changeover” in the TS Reference Manual 2. Item Description Local Mode Select the interface language for the Main Menu screen of MONITOUCH. Selectable languages vary with the [Font] setting.
Page 24 System Settings Supported Language List The following table lists the fonts and corresponding languages supported by the TS. Supported Language Supported Character Code Font Setting Bitmap font Japanese Japanese, English JIS level 1, level 2 + ANK code Japanese 32 Japanese, English JIS level 1 + ANK code English/Western Europe...
Page 25: Unit Setting
1 System Unit Setting The settings to be configured on the TS unit are described below. Select the functions to use and configure the required settings. Location of settings: [System Setting] → [Unit Setting] SRAM/Clock Configure the following settings when using SRAM or the built-in clock of the TS unit. Location of settings: [System Setting] →...
Page 26 System Settings SRAM Capacity and Area Size • The capacity of the internal SRAM is shown below: MONITOUCH Internal SRAM Built-in clock TS2060i 512 kB Checked TS2060/TS1000 Smart 128 kB • The allocation as well as the maximum capacity of the internal SRAM is shown below: TS2060i TS2060/TS1000 Smart 512 kB...
Page 27 1 System Non-volatile $L (word) and non-volatile $LD (double-word) • Difference The difference between “Word” and “Double-word” is whether only the specified address (word) is guaranteed or two words (double-word) from the address are guaranteed when a power failure occurs. •...
Page 28 System Settings Backlight Configure how the backlight is controlled by the TS unit. Item Description Action Always ON The backlight is always on. Auto 1 Backlight OFF conditions: The backlight is turned off when the time specified by [Backlight OFF Time] has elapsed from the instant when all the following conditions are met.
Page 29 1 System Item Description Backlight OFF Time 0~65535 (sec) This setting is only available when [Auto 1], [Auto 2] or [Auto 3] is selected for [Action]. Set the length of time that elapses before the backlight is turned off after the OFF conditions have been met.
Page 30 System Settings System/Mode Switch These settings relate to the operation of the [SYSTEM] switch and [MODE] (F1) switch in RUN mode. Item Description System Switch Prohibited Prohibit the display of the system menu. The menu is not displayed even if the [SYSTEM] switch is pressed. (TS2060 only) Mode Switch Prohibited Prohibit the [MODE] switch on the system menu (for displaying the Main Menu screen).
Page 31: General Settings
1 System Overlap Select the unit for overlap coordinates. This is used when displaying an overlap by an external command or macro command. Item Description Overlap Coordinates Line/Column X coordinate in 8 dots, Y coordinate in 20 dots (= one-byte) X coordinate in 4 dots, Y coordinate in 1 dot Snap Configure settings when outputting network camera images to a storage device.
Page 32 System Settings Item Description Read Data from Barcode in Used to set the unit of counting read data to be output to the I/F device memory for barcode setting. Words • Unselected Unit: bytes • Selected Unit: words (same as GD-80) Mode Operation: Make This is valid when [Action Area: Switch/Lamp] is selected for bit order alarming, page mode or direct mode.
Page 33 1 System Item Description Regard the origin of graphic Used to set the reference position when the graphic relay function is set for an overlap. relay on an overlap as the origin of a screen • Unselected Graphics are placed with respect to the origin of the overlap display part. Reference point Overlap Graphics library...
Page 34 PLC models, bit conversion of the DIO input device memory is required because the bit arrays are special. Check this box when using E-I/O or V-I/O with these PLCs. • Fuji Electric MICREX-F (other than I/O device memory for T-LINK) • Hitachi HIDIC-S10α (other than I/O device memory for JPCN-1) •...
Page 35 Used to set the action to be taken when the transfer source (transfer target) device is a double-word device. by BMOV Example: Fuji Electric MICREX-F series BD (data device) • Unselected: Only the lower-order word is transferred. $u100 = BD100 C:4 (BMOV)
Page 36 PLC-specific numeral conversion is performed. Applicable PLC models • Hitachi: All models • Yaskawa: Memobus (transfer mode 1) • Siemens: All models • OMRON: All models (transfer mode 2) • Fuji Electric: MICREX-F series and MICREX-F T-link • General-purpose PROFIBUS-DP 1-17...
Page 37 1 System Item Description Save the pitch setting of the Used to set [Char. Prop.] → [Set line spacing] in the switch and lamp settings window. texts of Switch/Lamp • Unselected The value specified for line spacing is cleared at the end of screen program editing. The setting is unselected for the next editing.
Page 38 System Settings Item Description Return switch prohibited Used to set the action taken when a switch with [Return] set for [Function] is used. when switching the screen by an external command • Unselected (default): It is possible to go back to the previously displayed screen even if it was switched by an external command.
Page 39 1 System Item Description Use Network Table/PLC Table This option sets whether or not to use Network Table/PLC Table CSV edit function and to allocate FROM to CSV edit function network tables and PLC tables. Use the system program Ver. 2.380 or later. •...
Page 40 System Settings TECHNOSHOT Setting (TS1000 Smart Only) Set the screen display method. A screen program converted from one for a QVGA (320 × 240 dots) unit can be displayed centered in VGA size (640 × 480 dots). Also, function switches can be displayed on the screen by enabling the soft function switch setting. Item Description Soft function switches are displayed on the right side of the screen.
Page 41: Communication Setting
1 System 1.1.3 Communication Setting This section explains the items in the [Hardware Setting] window. For information on other settings, refer to “1.1.1 System Setting” page 1-1. Hardware Setting Click to add/change Click to devices. add/change devices. Click to change the menu.
Page 42 System Settings PLC Settings and Other Devices (Left Menu) PLC settings menu Other devices menu Click to change the menu. Item Description Refer to PLC1 - 8 Configure settings for PLCs, temperature controllers, and inverters etc. TS2060 Connection Depending on the device connected, the available connection modes vary. Manual TS1000 Smart Connection Manual...
Page 43 1 System Read/Write Area • Read area The read area is where the PLC gives commands for display or operation to MONITOUCH. At least 3 words of consecutive device memory addresses are occupied. MONITOUCH always reads data from these 3 words to display and operate according to the commands.
Page 44 System Settings Read area “n” (sub command/data) 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 (1) Free (2) BZ0 [0 → 1] (leading edge) (3) BZ1 [0 → 1] (leading edge) (4) BZ2 [1] (level) (5) Calendar setting [0 →...
Page 45 1 System Read area “n + 1” (screen status command) 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 (1) Overlap 0 (2) Overlap 1 (3) Overlap 2 (4) Overlap 3 (5) Reserved for system (6) Global macro execution [0 →...
Page 46 System Settings Usage Example Step a: Screen change according to read area “n + 2” Step b: Screen change with an internal switch Step c: Screen change to the same screen number as step 1 according to read area “n + 2” In this case, however, the same value is stored in read area “n + 2”...
Page 47 1 System Write area “n” (same as data in read area “n”) 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 (1) Free (2) BZ0 (3) BZ1 (4) BZ2 (5) Calendar setting (6) Reserved for system Write Area “n”...
Page 48 System Settings Write area “n + 1” (screen status) (13) Screen forced switching This bit reflects the data in bit 14 of read area “n + 1”. (14) Data read refresh This bit reflects the data in bit 15 of read area “n + 1”. Example: a.
Page 49: Device Memory Map
1 System [GD-80 Compatible] Tab Window • GD-80 Compatible Read/Write Area This option is automatically checked when a GD-80/81S series screen program is converted into a TS screen program. The contents of [Read Area] and [Write Area] differ between the GD-80/81S series and TS. When this option is checked, the [Read Area] and [Write Area] contents will be the same as the GD-80/81S series.
Page 50: Common Setting
System Settings 1.1.4 Common Setting This section explains the items in the [Common Setting] group. For information on other settings, refer to “1.1.1 System Setting” page 1-1. Global Setting Global Function Switch Setting Function switches [F1] to [F5] can be used on all screens in RUN mode with common functions. On the TS1000 Smart, the [F1] to [F5] switches are available when soft function switches are enabled.
Page 51: Buffering Area Setting
1 System Buffering Area Setting Configure settings when using a sampling function (trend, alarm). For details, refer to “7.2.1 Buffering Area”, “8.2.1 Buffering Area”. Attribute Setting Configure settings when using the recipe function. For details, refer to “15 Recipes”. Other Configure settings when using each function.
Page 52: Process Cycle
Process Cycle Process Cycle The screen display speed during communication between the TS unit and the PLC depends on the number of parts (mainly the number of device memory addresses read from PLC) placed on the screen. When displaying more parts on the screen, the display speed and switch response may be slower. In such a case, it is possible to speed up the display process by differentiating between the data to be viewed in real time (high speed) and other parts (low speed).
Page 53: Processing Sequence In The Ts
1 System 1.2.2 Processing Sequence in the TS Processing in the TS unit is performed in the following order. • The TS analyzes screen data to be read from the PLC, and reads them in blocks. • All blocks corresponding to data set as high-speed are read in one cycle. •...
Page 54: One-Cycle Processing
Process Cycle 1.2.3 One-cycle Processing The device memory set for [System Setting] → [Hardware Setting] → [Read Area] is read first. Next, the data in the device memory set for the items on the screen is read and drawn. When operations of all the setting data have been performed, the screen display is completed.
Page 55: If Communication Is Slow
1 System 1.2.4 If Communication is Slow Try the following methods to speed up communication. Methods for Creating Screens Method Effect Consecutively allocate PLC device memory addresses that are used for the same The number of blocks decreases so the cycle time can be screen.
Page 56: List Of Internal Device Memory
List of Internal Device Memory List of Internal Device Memory Internal device memory is the device memory in the TS unit that is available to users. Since processing is done internally within the TS unit, communication speed can be made quicker by using for operations that do not require data communication with a PLC.
Page 57: System Device Memory Details
1 System 1.3.2 System Device Memory Details The details of the $s system device memory are shown below. Meaning of “Device Type” in the table • ← TS Data written to $s from MONITOUCH • → TS Definitions and settings written to $s by the user Table Description Device Type...
Page 58 List of Internal Device Memory Description Device Type Refer to V7 compatible Buffer 8 Specified number of buffers Buffer 8 Number of buffers Buffer 8 Executed number of buffers Buffer 9 Specified number of buffers Buffer 9 Number of buffers Buffer 9 Executed number of buffers ←...
Page 59 1 System Description Device Type Refer to PLC calendar status The calendar status of the PLC (with built-in calendar) is written. ← TS 0: Normal 1: Error (The calendar information could not be read correctly.) Setting for writing calendar data to PLC When $s100 = 1, writing calendar data to the PLC is permitted or prohibited.
Page 60 List of Internal Device Memory Description Device Type Refer to (Blank) Sampling buffer number → TS page 1-51 Overflow flag ← TS page 1-51 Buffer Word 0 Average Buffer Word 0 Maximum Buffer Word 0 Minimum Buffer Word 0 Total Buffer Word 1 Average...
Page 61 1 System Description Device Type Refer to Alarm function Auto operation time Alarm function Auto operation stop time ← TS Alarm function Program stop time Alarm function Number of stops Alarm Function Rate of operation (XX.X) (Blank) Alarm Function Normal Operation Bit ←...
Page 62 List of Internal Device Memory Description Device Type Refer to Ethernet Status (for built-in LAN port) TS2060 Connection Normal Manual ← TS Other than 0: Error number TS1000 Smart Connection Manual Ethernet Status (for Ethernet unit) ← TS Network table 0 status Network table 1 status Network table 2 status TS2060 Connection...
Page 63 1 System Description Device Type Refer to SRAM Memo pad save result 0: Normal 1: Data contains an error and is deleted. SRAM Internal device memory $L save result 0: Normal 1: Error SRAM Internal device memory $L last written device memory Stores the $L address of the last write operation when $s721 = 1 at power-up.
Page 64 List of Internal Device Memory Description Device Type Refer to V7 compatible PLC2 Port No. 32 Status PLC2 Port No. 33 Status PLC2 Port No. 34 Status TS2060 Connection Manual ← TS TS1000 Smart Connection Manual PLC2 Port No. 97 Status PLC2 Port No.
Page 65 1 System Description Device Type Refer to 1030 Built-in socket (drive: C) Storage device error state page 1-53 1031 Built-in socket (drive: C) Remaining space on storage device Stores the amount of free space on the storage device. (Unit: kbyte) 1032 ←...
Page 66 List of Internal Device Memory Description Device Type Refer to 1113 Buffer No. 0 Sampling error flag ← TS page 1-54 1114 Buffer No. 0 Sampling error forced storage flag → TS page 1-54 (Blank) 1120 - Buffer No. 1 (Equivalent to buffer No. 0 $s1100 to 1114) →...
Page 67 1 System Description Device Type Refer to 1400 Network table 100 status 1401 Network table 101 status 1402 Network table 102 status TS2060 Connection Manual ← TS TS1000 Smart Connection Manual 1553 Network table 253 status 1554 Network table 254 status 1555 Network table 255 status (Blank)
Page 68 List of Internal Device Memory Details • $s2 - 13, $s1617 - 1640 Stores the current overlap display status. n + 0 (Display status) Display status Overlap registration * 0: Hidden 1: Shown 0: None 1: Registered * For multi-overlap display, this bit is set to “1” only during display. However, the bit remains set to “1”...
Page 69 1 System • $s75 This address is used to activate or deactivate the buzzer which sounds when the top overlap display among multiple overlap displays is switched over. [0]: Buzzer ON [1]: Buzzer OFF • $s78 Stores the display format of data in the entry target. Output Code Entry Target Display Format...
Page 70 List of Internal Device Memory • $s107 The information of whether or not data is registered in each page of the memo pad (maximum 8 pages) is stored. $s107 Page 0 Page 1 Page 2 0: Data not registered 1: Data registered Page 3 Page 4 Page 5...
Page 71 1 System • $s180 - 435 Stores the result of the SET_BUFNO macro command execution. • $s468 - 485 Reads or writes memory card information (card number, card name, filename) to device memory “n”. Use the MOV macro command. Read: [n = $s468 (to 485)] is executed and device memory “n”...
Page 72 List of Internal Device Memory • $s814 - 818 Stores the IP address of the network table number corresponding to the value* set for $s818. If no network table exists, “0.0.0.0” is stored. Use the MOV (W) macro command to set the network table number. •...
Page 73 1 System • $s1066 Outputs the status of printing performed on the PictBridge printer. Value Description Cause and Remedy The PictBridge printer is not connected or it is in the normal state. Printing in progress using the PictBridge printer. Printer error (hardware related) The cable is not connected.
Page 74 List of Internal Device Memory • $s1560 Stores the global overlap display status. n + 0 (Display status) Overlap registration * Display status 0: None 1: Registered 0: Hidden 1: Shown * This bit is set to “1” only during display. However, the bit remains set to “1”...
Page 75 1 System 1-56...
Page 76: Overlap
Overlap Overview Normal Overlap Call-overlap Multi-overlap Global Overlap...
Page 78: Overview
Overview Overview 2.1.1 Overlap Displays Windows can be displayed on the screen. These overlaying windows are called “overlap” displays. Screen Line A Paint Process Line A Paint Process Screen Change Change Menu Counter Num. Error Error 000,000 Monitor Timer Display Detail 00 sec.
Page 79 2 Overlap When several overlap displays are shown at the same time, it is possible to move an overlap display that is partly behind another to the foreground by touching the screen. Line B Monitor Line B Monitor 1135 10.23 5548 1135 10.23...
Page 80: Overlap Display Formats
Overview 2.1.2 Overlap Display Formats Overlap displays comprise the following four formats. Overlap Refer to Normal overlap page 2-3, page 2-8 Call-overlap page 2-4, page 2-15 Multi-overlap page 2-5, page 2-18 Global overlap page 2-6, page 2-26 Normal Overlap This overlap display format is unique to each screen. An overlap display created for screen 1 cannot be displayed on other screens.
Page 81: Call-Overlap
2 Overlap Call-overlap This overlap display format calls and displays overlaps registered to the overlap library. Because overlap displays are called from the library, they can be shared between multiple screens. Screen 5 Screen 12 Screen 15 Line B Monitor Line D Monitor Line G Monitor 1135...
Page 82: Multi-Overlap
Overview Multi-overlap This overlap display format calls and displays overlaps registered to the overlap library. Because overlap displays are called from the library, they can be shared between multiple screens. Screen 5 Screen 12 Screen 15 Line B Monitor Line D Monitor Line G Monitor 1135 10.23...
Page 83: Global Overlap
2 Overlap Global Overlap This overlap display format calls and displays overlaps registered to the overlap library. Because overlap displays are called from the library, they can be shared between multiple screens. Any overlap library number from 0 to 9999 can be set with respect to overlap ID 3. A maximum of 4000 types of overlaps can be selected and displayed.
Page 84: Overlap Auxiliary Functions
Overview 2.1.3 Overlap Auxiliary Functions System Buttons The system button overlap auxiliary function operates in the following two ways. Overlap Movement Touch the top left corner (2 x 2 switch grid) of the overlap display to make the overlap frame blink. With the overlap frame blinking, touch a position on the screen once to move the overlap display to that position.
Page 85: Normal Overlap
2 Overlap Normal Overlap 2.2.1 Creation Procedure Use the following procedure to create a normal overlap. 1. Click [Parts] → [Overlap] → [Normal Overlap] and place an overlap. 2. Adjust the size of the overlap. 3. Select [Overlap Editing] → [ID 0] on the right-click menu. The overlap editing window is displayed. 4.
Page 86: Detailed Settings
Normal Overlap 2.2.2 Detailed Settings Status of Use Item Description Registration Status Check the registration status of overlap IDs 0 to 3. “- Editing -” is shown for the ID that is currently being edited. The overlap ID can also be changed to an unregistered ID. Control Device Selected Specify a device using one bit.
Page 87 2 Overlap Detail Item Description Auxiliary System buttons Select this checkbox to use system buttons. Refer to page 2-7. Function Input Cursor Movement Control This setting is required to use the “entry function” on an overlap display. Device For details, refer to page 6-34.
Page 88: Show/Hide Settings
Normal Overlap 2.2.3 Show/Hide Settings There are four methods for showing and hiding normal overlap displays. Method Error Detail Refer to Internal command Switch Function: Overlap Control page 2-11 Set Display No.: Unselected Macro OVLP_SHOW page 2-12 OVLP_POS External Command Control device memory 0 →...
Page 89 2 Overlap Macro A macro can be used to show and hide normal overlap displays. In this case, use the “OVLP_SHOW” command. The “OVLP_POS” command is used to specify the display position. For details, refer to the Macro Reference Manual. Setting 1.
Page 90 Normal Overlap Control Device Memory Setting 1. In the normal overlap settings menu, click [Status of Use] and configure the [Control Device] settings. 2. The overlap is shown when the [Control Device] bit is ON and hidden when the bit is OFF. Bit 0 of [Control Device]: 0 →...
Page 91 2 Overlap Read area “n + 1” The read area “n + 1” (screen status command) of [System Setting] → [Hardware Setting] → [Read/Write Area] is used. 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 [Read Area] n + 1 Overlap ID 2 0: Hide...
Page 92: Call-Overlap
Call-overlap Call-overlap 2.3.1 Creation Procedure 1. Creating from an Overlap Library 1) Display an [Overlap Library Edit] tab window by clicking [Home] → [Registration Item] → [Overlap Library]. 2) Click [Parts] or [Home] → [Overlap] → [Normal Overlap] and place an overlap. 3) Adjust the size of the overlap.
Page 93: Detailed Settings
2 Overlap 2.3.2 Detailed Settings Operation Select Item Description Registration Status Check the registration status of overlap IDs 0 to 3. “- Editing -” is shown for the ID that is currently being edited. The overlap ID can also be changed to an unregistered ID. Overlap Setting Call Overlap library number...
Page 94: Show/Hide Settings
Call-overlap 2.3.3 Show/Hide Settings There are four methods for showing and hiding call-overlap displays. Method Error Detail Refer to Internal command Switch Function: Overlap Control page 2-16 Set Display No.: Unselected Macro OVLP_SHOW page 2-12 OVLP_POS External Command Control device memory 0 →...
Page 95: Multi-Overlap
2 Overlap Multi-overlap 2.4.1 Creation Procedure 1. Creating from an Overlap Library 1) Display an [Overlap Library Edit] tab by clicking [Home] → [Registration Item] → [Overlap Library]. 2) Click [Parts] or [Home] → [Overlap] → [Normal Overlap] and place an overlap display. 3) Adjust the size of the overlap.
Page 96: Detailed Settings
Multi-overlap 2.4.2 Detailed Settings Operation Select Item Description Registration Status Check the registration status of overlap IDs 0 to 3. “- Editing -” is shown for the ID that is currently being edited. The overlap ID can also be changed to an unregistered ID. Overlap Setting Multi Control Settings...
Page 97 2 Overlap • Control Device Item Description Control Device Selected Specify a device using one bit. Showing and hiding is performed according to the value of the bit. 1 (level): Show 0 (level): Hide Unselected Bits 0 to 2 of read area “n + 1” are used. Information Output Device Store and set the following information using a maximum of 4 words.
Page 98: Show/Hide Settings
Multi-overlap 2.4.3 Show/Hide Settings There are four methods for showing and hiding multi-overlap displays. Method Error Detail Refer to Internal command Switch Show Function: Overlap Control page 2-21 Set Display No.: Selected Hide Function: Overlap Control Control Operation: Set Display No.: Unselected Macro SET_MOVLP...
Page 99 2 Overlap 3. Set the function to use. Function Overlap Control Overlap ID Specify the same ID as the [Overlap ID] of the multi-overlap. Show Set Display No. Selected Overlap Library No. Set the overlap library number of the overlap for display. Display Position Set the X and Y coordinates.
Page 100 Multi-overlap Control Device Memory Setting 1. In the multi-overlap settings menu, click [Operation Select] and configure the [Control Device] and [Information Output Device] settings under [Control Settings]. 2. Set the library number of the overlap for display to the [Device for Overlap Library No. to Display]. When specifying the display position, also set the X and Y coordinates.
Page 101 2 Overlap Read Area “n + 1” Setting 1. In the multi-overlap settings window, click [Operation Select]. Under [Control Settings], specify [Display Method: Control Device] and then configure the [Information Output Device] settings. 2. Set the library number of the overlap for display to [Device for Overlap Library No. to Display]. When specifying the display position, also set the X and Y coordinates.
Page 102 Multi-overlap E.g.: Read area “D0” Specify the overlap to display with [Device for Overlap Library No. to Display]. Bit 2 of read area “D1”: 0 → 1 Do you want to save the setting? D0100 D0100 D0001 Overlap library No. 3 Line B Monitor Line B Monitor 1135...
Page 103: Global Overlap
2 Overlap Global Overlap 2.5.1 Creation Procedure 1. Creating from an Overlap Library 1) Display an [Overlap Library Edit] tab window by clicking [Home] → [Registration Item] → [Overlap Library]. 2) Click [Parts] or [Home] → [Overlap] → [Normal Overlap] and place an overlap display. 3) Adjust the size of the overlap.
Page 104 Global Overlap 2. Global Overlaps 1) Click [System Setting] → [Global Setting] → [Global Overlap Setting]. 2) Select the [Use Overlap] checkbox. (Fixed to ID 3) 3) Select a display method under [Designate]. Item Description Designate Switch Use switches for showing and hiding. Refer to page 2-30.
Page 105: Detailed Settings
2 Overlap 2.5.2 Detailed Settings Display Method Selection • Switch Item Description Switch Control showing and hiding of the overlap using the switch function. Information Output Device Store the overlap library number. Show: 0 to 9999 Hide: −1 (FFFFHex) Input Cursor Movement This setting is required to use the “entry function”...
Page 106 Global Overlap Item Description Information Output Device Store and set the following information using a maximum of 4 words. Device for Overlap Library Information Output Device Stores the overlap library number. TS → No. to Display Show: 0 to 9999 Hide: −1 (FFFFHex) Display Position...
Page 107: Show/Hide Settings
2 Overlap 2.5.3 Show/Hide Settings There are four methods for showing and hiding global overlap displays. Method Error Detail Refer to Internal command Switch Function: Overlap Control page 2-30 Set Display No.: Selected Macro SET_MOVLP page 2-31 OVLP_SHOW OVLP_POS External Command Control device memory 0: Hide page 2-32...
Page 108 Global Overlap Macro A macro can be used to show and hide global overlap displays. Use the “SET_MOVLP” and “OVLP_SHOW” commands. The “OVLP_POS” command is used to specify the display position. For details, refer to the Macro Reference Manual. Setting 1.
Page 109 2 Overlap Control Device Memory Setting 1. In the global overlap settings menu, configure the [Control Device] settings. One word is occupied. 2. Set the library number of the overlap for display to the [Device for Overlap Library No. to Display]. When specifying the display position, also set the X and Y coordinates.
Page 110 Global Overlap Read Area “n + 1” 1. Set the library number of the overlap for display to the [Device for Overlap Library No. to Display] in the [Global Overlap Setting] window. When specifying the display position, also set the X and Y coordinates. Store the overlap library number.
Page 111: Notes
2 Overlap 2.5.4 Notes • Global overlaps are redisplayed when the display language is changed. • Global overlap displays cannot be set for component parts nor called upon from component parts. 2-34...
Page 112: Switch
Switch Switch Scroll Bars Slider Switch...
Page 114: Overview
Switch Switch 3.1.1 Overview Basic Function of Switches • Switches can send ON/OFF information to specific bits in PLC or internal device memory. device memory Turns ON. M0 to 15 M16 to 31 M32 to 47 For example settings, refer to “Setting the PLC bit to ON.”...
Page 115 3 Switch • Turning a device memory bit ON and showing an overlap display at the same time device memory Turns ON. ON information M0 to 15 M16 to 31 M32 to 47 Overlap Overlap Display Overlap • When a switch is pressed, ON/OFF information or a value can be sent for multiple bits or words at the same time to a PLC device memory or internal device memory.
Page 116: Lamps In Switches
Switch Lamps in Switches • There are switches available with lamps that light up (ON color) when the switch is pressed and turn off (OFF color) when released. Switch Switch Switch • Lamp activation can be instructed from an external device memory. Switch device memory M0 to 15...
Page 117: Setting Examples
3 Switch 3.1.2 Setting Examples Setting the PLC bit to ON. Set PLC device memory M26 to ON while the switch is pressed and OFF after the switch is released. device memory Turns ON. M0 to 15 M16 to 31 M32 to 47 1.
Page 118: Changing Screens
Switch Changing Screens Change to screen No. 1 when the switch is pressed. Screen 1 Press button Screen No. 0 Screen No. 1 Screen 1 1. Click [Parts] → [Switch] and place a switch on the screen. 2. Double-click on the switch to display the settings window. Configure the following settings for [Function] and then click [Finish].
Page 119: Detailed Settings
3 Switch 3.1.3 Detailed Settings Style Item Description No. of Patterns Set the number of times the display of the switch lamp can be changed. (2 to 128) Area Setting Select from catalogs Select the part design. After selecting the part, select the part color. A transparent switch can also be selected. Select from image files Select a bitmap file.
Page 120 Switch Char. Prop. Item Description [OFF] [ON] - [P128] When [Style] → [Other Settings] → [Draw Mode] is [XOR]: Only [OFF] can be selected. Specify the text to be displayed. Pattern No. When [Style] → [Other Settings] → [Draw Mode] is [REP]: (0 to 127) Specify the text to be displayed on each pattern.
Page 121: Output Device
3 Switch Output Device Item Description Output Setting Select this checkbox to execute the specified output operation for the set output device when the switch is pressed. Number of Outputs A maximum of 16 types of output operations can be executed at once when the switch is (1 to 16) pressed.
Page 122 Switch Notes on [Momentary] and [Momentary W] operation Processing differs depending on the type of PLC device memory specified for output (whether bits are writable or not). For information on PLC device memory types, refer to the relevant PLC manual. •...
Page 123 3 Switch Word operation Item Description Operation Operation Device Specify the device memory address for operation. Setting Operation Mode Transfer Perform the specified arithmetic operation with [Operation Device] and [Operand Device] and write the result to the device memory set for [Address to Output Operation Result].
Page 124 Switch Function Item Description Function Select the function to assign to the switch, that is, how the switch should work when pressed. Standard Standard Set the bit of the specified device memory ON/OFF. *1 *2 Screen Change-over Change to the specified screen number (0 to 9999). Hard Copy Print the currently displayed screen image.
Page 125 3 Switch Macro Item Description Macro to Edit ON Macro Register a macro command to be executed once when the switch is pressed. OFF Macro Register a macro command to be executed once when the switch is released. Edit Start the macro editor. Register a macro command to be executed. Delete Delete the macro command.
Page 126 Switch Delay Item Description ON delay Select this checkbox to specify a delay for when the switch is turned ON. ON after a lapse of preset time The switch is activated for the function as specified for [Output Device], [Function], (Setting Time: 1 to 300 ×...
Page 127 3 Switch Interlock Item Description Use interlock Select this checkbox to enable the interlock function for the switch. Condition Setting Click a condition number to configure a condition that must be satisfied for the interlock to activate. Bit device Set the interlock bit address. Bit device “ON”: switch operation is allowed When [Bit device] is OFF, switch operation is prohibited.
Page 128 Switch Example of operation when the switch is OFF When the switch is ON: When the switch is OFF: Switch settings window Device to Output: Output Action: Momentary Use interlock Condition 1 Press Bit device: Release Bit device “ON”: switch operation is allowed Condition satisfied...
Page 129: Message Box
3 Switch Message Box Item Description Use message call function Select this checkbox to automatically display a message dialog box when the switch is pressed. When [OK] is pressed, the switch is activated for the function as specified for [Device to Output], [Function], and [Macro].
Page 130 Switch N-State Lamp The number of patterns specified in the [Style] settings is displayed. Item Description Use N-state lamp Select this checkbox to use the N-state lamp function. Specify bit device memory or word device memory for each pattern. Condition Setting Set the conditions for operating a lamp.
Page 131 3 Switch Show/Hide Item Description Show Display the numerical data display on the screen. Hide Do not display the numerical data display on the screen. Show/hide according to the Bit device Show the part if the specified bit device memory is ON and hide the part if it is condition OFF.
Page 132 Switch Detail Item Description Coordinates Start X/Start Y Set the display position of the switch using X and Y coordinates. Width/Height Set the size of the switch by specifying width and height. Others Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 133: Basic Function Of Switches
3 Switch 3.1.4 Basic Function of Switches List of Functions If the [Display All] checkbox is selected next to [Function] in the switch settings, all of the switch functions are displayed for selection. When nothing is listed in the “Linked Part” column of the table, the switch activates alone with the set function. When one or more functions are listed in the “Linked Part”...
Page 134 Switch Entry Name Description Linked Part Refer to Character Input Enter text onto switches. Entry page 6-1 (DELETE key available for Write Write the entry data to the device memory. alarm usage) Clear Clear the entry data. Toggle Sign Invert the entered sign (for numerical input). Space Enter a one-byte space (for character input).
Page 135 3 Switch Sample Name Description Linked Part Refer to Zooming in Zoom in on a graph. Trend Trend Trend sampling page 7-1 Zooming out Zoom out of a graph. Alarm Graph Return Return to the latest sampling data. Trend page 8-1 Trend sampling Data sampling Alarm...
Page 136: Digital Switch
Switch Digital Switch Name Description Linked Part Refer to Digital Switch + Increment the selected digit by one. Numerical Display page 3-25 Digital Switch − Decrement the selected digit by one. Digital Switch Sign Inverse the sign of the numerical data display. Inversion JPEG Name...
Page 137: Remote Desktop
3 Switch Remote Desktop Name Description Linked Part Refer to Remote Desktop Show or hide the remote desktop window of the connected server Remote Desktop Show/Hide (computer) at the specified coordinates. Connect Establish connection with a server (computer) to enable display of the remote desktop window.
Page 138: Switch Function Examples
Switch Switch Function Examples Digital Switch Usage example Switch [Function: Digital Switch +] Numerical display [Function: Digital Switch] Switch [Function: Digital Switch −] • Switch - Function Item Description Digital Switch + Target digits (1 to 17) The selected digit is incremented by one. Digital Switch −...
Page 139 3 Switch Storage Removal (Stopping Access to a Storage Device) The switch lamp status changes as shown in the following table. Information on the switch status is stored at $s500 in the system device memory. Lamp Storage Removal Storage Access Status Prohibited Normal access Blinking ON/OFF...
Page 140: Flowchart
Switch 3.1.5 Flowchart When the Switch is ON (Pressed) Switch ON Interlock Not satisfied Interlock condition Satisfied ON delay No buzzer Buzzer Normal switch ON delay Buzzer No ON delay Error buzzer ON Delay cancel Delay finished Delay finished Interlock Interlock condition Satisfied...
Page 141 3 Switch ON delay ON delay Double-touch ON delay ON delay Switch frame blink First-touch buzzer timer up Second touch Buzzer ON Switch OFF ON delay timer up Delay finished Delay cancel Delay finished Delay cancel Message dialog box ON delay + message dialog box ON delay ON delay Buzzer ON...
Page 142: Output Action
Switch Output action Output operation Multi-output Output device memory No. 0 Output operation execution Output device memory Output operation execution Output device memory No. + 1 Output operation finished ON repeat ON repeat Repeat buzzer Buzzer ON ON repeat macro ON macro ON function repeat...
Page 143 3 Switch When the Switch is OFF (Released) Set, reset, alternate Release the switch. OFF delay Switch ON OFF delay timer up Delay finished Delay cancel Switch OFF External Lamp Internal Lamp OFF graphic OFF macro Ending Momentary, momentary W Release the switch.
Page 144: Coordinate Output
Switch 3.1.6 Coordinate Output The current touch switch information is output to $s900 to 902 of the system device memory. This information is useful when linking to an image processing device. X: 160 Y: 140 • $s900 Touch switch status 0: Switch OFF 1: Switch ON Not used...
Page 145: Notes
3 Switch 3.1.7 Notes Do not use switches where they could cause injury to people or damage machinery. Moreover, do not use switches as emergency switches. Placement Minimum Switch Size and Maximum Number of Switches • Minimum size: 2 dots × 2 dots (For safety reasons, however, a size of at least 18 dots × 14 dots is recommended.) •...
Page 146: Scroll Bars
Scroll Bars Scroll Bars 3.2.1 Overview Scroll bars can be used to display portions of messages or JPEG images that lie off screen. Scroll the screen by moving the slide switch or pressing the desired position on the rail. Position to press and data write timing •...
Page 147: Setting Examples
3 Switch 3.2.2 Setting Examples Scroll bars can be added to screens that display JPEG images. * For details on JPEG display settings, refer to the TS Reference Manual 2. 1. Click [Parts] → [Catalog] to display the catalog window. Configure the following settings and drag and drop a vertical scroll bar onto the screen.
Page 148 Scroll Bars 3. Click [Detail] → [Detail Settings], link [ID] to the ID of the JPEG display, and then click [Finish]. 4. Drag and drop a horizontal scroll bar onto the screen from the catalog window in the same manner as step 1. Drag and drop 5.
Page 149 3 Switch 6. Click [Detail] → [Detail Settings], link [ID] to the ID of the JPEG display, and then click [Finish]. This completes the necessary settings. 3-36...
Page 150: Detailed Settings
Scroll Bars 3.2.3 Detailed Settings Style Item Description Edit Parts Select the parts to edit (rail/slide). Area Setting Select from catalogs Select the part design of each pattern. After selecting the part, select the part color. Select from image files Select a bitmap file.
Page 151 3 Switch Show/Hide Item Description Show Display the numerical data display on the screen. Hide Do not display the numerical data display on the screen. Show/hide according to the Bit device Show the part if the specified bit device memory is ON and hide the part if it is condition OFF.
Page 152: Notes
Scroll Bars 3.2.4 Notes • Maximum number per screen (including switches and slide switches) - TS2060: - TS1000S: 1024 • Scrolling is performed in pixel units. • If multiple scroll bars are placed that have the same ID and are not linked to other items, the scroll bar in the foreground takes effect.
Page 153: Slider Switch
3 Switch Slider Switch Slider switches are used in conjunction with numeric data entry. For details on slider switches, refer to “6.1 Numerical Data Entry”. 3-40...
Page 154: Lamp
Lamp...
Page 156: Overview
Overview Overview • The displayed patterns of lamps are switched in response to data changes in the lamp device memory. There are lamps called “bit lamps” that are switched according to bit setting (ON) and resetting (OFF) and “word lamps” that are switched according to the values placed in device addresses.
Page 157 4 Lamp • A single lamp can change between a maximum of 128 patterns. This can be done using consecutive device memory addresses or by using any desired addresses (N-state lamp). Pattern 0 Pattern 1 Pattern 2 Pattern 3 Pattern 4 Pattern 5 (OFF) (ON)
Page 158: Setting Examples
Setting Examples Setting Examples Using Bit Lamps When the M19 bit of the PLC device memory is ON, the lamp turns on, and when the M19 bit is OFF the lamp turns off. Lamp device memory: M19 PLC device memory LAMP M 0 to 15 M16 to 31...
Page 159: Using Lamps With Conditions (N-State Lamp)
4 Lamp Using Lamps with Conditions (N-State Lamp) Set a lamp that lights up when the M0, M10, and M20 bits of PLC device memory all turn ON. Condition 1: M0 (ON) Condition 2: M10 (ON) Condition 3: M20 (ON) PLC device memory LAMP M 0~15...
Page 160: Creating A Three-Pattern Lamp (N-State Lamp)
Setting Examples Creating a Three-Pattern Lamp (N-State Lamp) Set a lamp that shows the ON pattern when the M0 bit of the PLC device memory turns ON and the P3 pattern when the D100 value is between “1” and “50”. PLC device memory M 0~15 M16~31...
Page 161: Placing 128 Pattern Lamps
4 Lamp Placing 128 Pattern Lamps Set a 128 pattern lamp, like the one shown in the figure below. Pattern 0 Pattern 1 Pattern 2 Pattern 3 Pattern 4 Pattern 5 (OFF) (ON) (P3) (P4) (P5) (P6) Operation Operation Temperature Temperature Water Tank alarm...
Page 162 Setting Examples - Word lamp Lamp device memory: D100 3. Configure the [Char. Prop.] settings as shown below. Change between the [OFF] to [P128] tab and [0] to [127] tab to register text for each pattern and then click [Finish]. - Bit lamp - Word lamp This completes the necessary settings.
Page 163 4 Lamp Display example • Bit lamp M4 is set to ON. M000-015 M000-015 M016-031 M016-031 M112-127 M112-127 Status monitor screen Status monitor screen Operation Water stop pressure drop When M0 to 126 is set to “OFF” in the PLC Set M4 in the PLC device memory to ON.
Page 164: Detailed Settings
Detailed Settings Detailed Settings Style Item Description No. of Patterns Set the number of patterns that the lamp can display. (2 - 128) Area Setting Select from catalogs Select the part design. After selecting the part, select the part color. Select from image files Select a bitmap file.
Page 165 4 Lamp Notes on the transparency function The transparency function is used to create parts that are only displayed when ON or parts only consisting of characters. The following shows how parts with transparency placed on the screen are displayed. Part only displayed when Hide Only characters displayed...
Page 166 Detailed Settings Char. Prop. Item Description [OFF] [ON] - [P128] When [Style] → [Other Settings] → [Draw Mode] is [XOR]: Only [OFF] can be selected. Specify the text to be displayed. Pattern No. When [Style] → [Other Settings] → [Draw Mode] is [REP]: (0 - 127) Specify the text to be displayed on each pattern.
Page 167 4 Lamp Function Item Description Function Set the type of operation to be performed by the lamp. Standard Standard Use as a standalone part without any dependencies on other parts. Display All Select this checkbox to display all of the available lamp functions. The following function is added when the [Display All] checkbox is selected.
Page 168 Detailed Settings N-State Lamp The number of patterns specified in the [Style] settings is displayed. Item Description Use N-state lamp Select this checkbox to use the N-state lamp function. Specify bit device memory or word device memory for each pattern. Condition Setting Set the conditions for operating a lamp.
Page 169 4 Lamp Show/Hide Item Description Show Display the numerical data display on the screen. Hide Do not display the numerical data display on the screen. Show/hide according to the Bit device Show the part if the specified bit device memory is ON and hide the part if it is condition OFF.
Page 170: Draw Mode
Draw Mode Draw Mode Shape: 2D, group: square2 Text When setting text on a lamp, the same text is displayed for both OFF and ON statuses. Set text on the [OFF] tab of [Char. Prop.]. Color • OFF frame color/ON color/OFF color Set the lamp color via [Style] in the lamp settings window.
Page 171 4 Lamp Display example [OFF color: Yellow] [ON color: Red] [Frame color: White] The frame color displayed when the lamp is ON Bla Blu R Mag Gre C OFF color (yellow) A Bla Blu R Mag Gre C Green C Purple = ON frame color (setting) Blu Bla Mag R...
Page 172 Draw Mode Shape: 2D, group: square2 Text When placing text on a lamp part in “REP” draw mode, the following two modes are available. • When displaying different text when the lamp is ON and OFF: OFF text Set text on the [OFF] tab of [Char. Prop.]. ON text Set text on the [ON] tab of [Char.
Page 173: Notes
4 Lamp Notes Number of lamps Maximum number per screen • TS2060: • TS1000S: 1024 Placing multiple lamp parts When placing two or more lamp parts on one screen, do not allow them to overlap each other. If overlaying is unavoidable, take the following points into consideration when creating the screen. M0=0 M0=0 M1=0...
Page 174: Data Display
Data Display Numerical Display Character Display Message Display Table Data Display Notes...
Page 176: Overview
Numerical Display Numerical Display 5.1.1 Overview • Numerical data read from the PLC is displayed in real time on the screen in any of the following formats: DEC (w/o sign), DEC (with sign −), DEC (with sign +−), HEX (hexadecimal), OCT (octal), BIN (binary) and Real Number Type (decimal floating-point).
Page 177 5 Data Display • Device memory for offset value designation A single numerical display part can be used to show different data by switching the device memory address assigned to the part. This can help to reduce the number of screens or parts used and facilitate screen maintenance. Example: Displaying scheduled production volume, non-defective count, and defective count for a machine selected from No.
Page 178 Numerical Display • Specifying attributes using device memory The attributes (number of digits, decimal point, display type, or text color) of numerical display parts are easily changeable while MONITOUCH is in RUN mode. Example: Numerical data display D100 (no transparency) Change the decimal place from 0 to 1, text color from black to red, and background color from white to yellow.
Page 179: Setting Examples
5 Data Display 5.1.2 Setting Examples Monitoring PLC Device Memory This example explains monitoring of a PLC device memory D100. The numerical data display is shown in red when the value is less than “100” and yellow when the value exceeds “1000”. 1.
Page 180: Detailed Settings
Numerical Display 5.1.3 Detailed Settings Contents Item Description Device to Device Specify the device memory address to use for numerical data display. Display (base device memory) Use offset value Set the device memory address and the code used for storing an offset value with respect to *1 *2 designation device the value in the base device memory.
Page 181 5 Data Display The device memory for offset value designation is read every cycle, regardless of the item processing cycle. Screen updates depend on the setting of the [Redraw the screen] checkbox in [Screen Setting] → [Screen Setting] → [Show/Hide Item] → [Redraw the screen]. •...
Page 182 Numerical Display Specifying attributes using device memory When a [Designate by device] checkbox in [Contents] → [Detail Settings] or a [Designate by device] checkbox in [Char. Prop.] → [Detail Settings] is selected, the corresponding attribute can be changed by specifying a value using a device memory address.
Page 183 5 Data Display Item Description Char. Prop. Char. Color Set the color for text. Text color 31.5 Bits 0 to 6: Color Bit 7 : Blinking (0: No, 1: Yes) Text color 15 14 13 12 11 10 9 0 to 127 colors Blinking 0: No 1: Yes...
Page 184 Numerical Display Style Item Description Area Setting Select from catalogs Select the part design. After selecting the part, select the part color. Select from image files Select a bitmap file.
Page 185 5 Data Display Function Item Description Function Set the type of operation performed by the numerical data display. Standard Num. Display device memory values on the numerical data display in real time. Display Entry Target Used in conjunction with the entry function. For details, refer to “6.1 Numerical Data Entry”.
Page 186 Numerical Display Char. Prop. Item Description Alignment Set the text alignment. Center Flush Left Flush Right Value to Display on Preview This item is available when the [Display for the editor] checkbox is selected on the [View] → [Display Environment] → [Display] tab. Set the value to display using the editor.
Page 187: Operation/Alarm
5 Data Display Operation/Alarm Item Description Alarm Select this checkbox to display data in a different color when it exceeds or falls short of a specific range. When “Entry Target” is selected for [Function], the range of values that can be entered using a keypad can be set.
Page 188 Numerical Display Operations Example: Data read from PLC is “789”. • When “BCD” is selected for [Input Type] and negative numbers are displayed (Negative numbers do not exist in the BCD format.) Select either [DEC (with sign −)] or [DEC (with sign +−)] for [Contents] → [Display Type]. [offset value] (data) [×]...
Page 189 5 Data Display Scaling • If data in the PLC device memory multiplied by the maximum value specified for [Range after Scaling] is greater than a double-word, it cannot be displayed correctly. • Example: Numerical data display When data in the PLC device memory address D100 is “2000” with a range of 0 to 4000 specified for [Range before Scaling] and a range of 0 to 100 specified for [Range after Scaling], “50”...
Page 190 Numerical Display Show/Hide Item Description Show Display the numerical data display on the screen. Hide Do not display the numerical data display on the screen. Show/hide according to the Bit device Show the part if the specified bit device memory is ON and hide the part if it is condition OFF.
Page 191: Real Numbers (Floating Point Numbers)
5 Data Display 5.1.4 Real Numbers (Floating Point Numbers) MONITOUCH can handle real numbers specified by the IEEE 754 standard (32-bit single precision real number format). Overview IEEE 754 standard (32-bit single precision real number format) 32 bits are defined in the following format. The above format expresses decimal floating-point data as shown below.
Page 192 Numerical Display MONITOUCH display range −9.999999 × 10 ≤ n ≤ −1.000000 × 10 1.000000 × 10 ≤ n ≤ 9.999999 × 10 -9.999999 10 -1.000000 10 1.000000 10 9.999999 10 -3.402823 -1.401298 1.401298 3.402823 A: Overflow display (- - - -) B: 0 C: -0 Decimal Floating-point Data Example...
Page 193: Character Display
5 Data Display Character Display 5.2.1 Overview • Data read from the PLC is displayed in the form of characters on the MONITOUCH screen in real time. ANK codes are assigned to one-byte characters and Shift-JIS codes are assigned to two-byte characters. PLC device memory ABCDE ABCDE...
Page 194 Character Display 5.2.2 Detailed Settings Contents Item Description Device to Device Specify the device memory address to use for character display. Display (base device memory) Use offset value Set the device memory address and the code used for storing an offset value with respect to *2 *3 designation device the value in the base device memory.
Page 195 5 Data Display Specifying attributes using device memory When a [Designate by device] checkbox in [Contents] → [Detail Settings] or a [Designate by device] checkbox in [Char. Prop.] → [Detail Settings] is selected, the corresponding attribute can be changed by specifying a value using a device memory address.
Page 196 Character Display Notes on changing attributes using device memory • The update timing depends on the setting of [Detail] → [Process Cycle] of each part. • For a display part provided with a frame, the frame size does not change regardless of the setting of [No. of Bytes]. For this reason, the maximum number of bytes in the screen program must be set in advance.
Page 197 5 Data Display Function Item Description Function Set the function of the character display. Standard Char. Display Display device memory values on the character display in real time. Entry Target Used in conjunction with the entry function. For details, refer to “6.2 Character Input”.
Page 198 Character Display Char. Prop. Item Description Alignment Set the text alignment. Center Flush Left Flush Right Text to Display on Preview This item is available when the [Display for the editor] checkbox is selected on the [View] → [Display Environment] → [Display] tab. Set the text to display using the editor.
Page 199 5 Data Display Show/Hide Item Description Show Display the numerical data display on the screen. Hide Do not display the numerical data display on the screen. Show/hide according to the Bit device Show the part if the specified bit device memory is ON and hide the part if it is condition OFF.
Page 200 Character Display Detail Item Description Overlap Overlap ID When the [Function] for a character display is set to “Entry Target” and the [Display the keyboard] (0 - 2) checkbox is selected, specify the overlap ID for displaying the keyboard. Coordinates Start X/Start Y Set the display position of the character display using X and Y coordinates.
Page 201 5 Data Display Message Display 5.3.1 Overview • Use the message edit screen to register messages for display on the screen in advance. When a message registration number is specified for a device memory address, the corresponding message is displayed on the screen in real time. Message editing No.
Page 202: Message Display
Message Display 5.3.2 Detailed Settings Device Memory Item Description Device One word is used for device memory specification. The message that corresponds to data contained at the specified device memory address is displayed on the screen. * Specify a message number using its absolute address (range: 0 to 32767). Message Edit Click [Open] to display the [Message Edit] window.
Page 203 5 Data Display Char. Prop. Item Description Alignment Set the text alignment. Center Flush Left Flush Right Message No. to Display on Preview This item is available when the [Display for the editor] checkbox is selected on the [View] → [Display Environment] → [Display] tab. Set the message to display using the editor.
Page 204 Message Display Show/Hide Item Description Show Display the numerical data display on the screen. Hide Do not display the numerical data display on the screen. Show/hide according to the Bit device Show the part if the specified bit device memory is ON and hide the part if it is condition OFF.
Page 205 5 Data Display Detail Item Description Coordinates Start X/Start Y Set the display position of the message display using X and Y coordinates. Others Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”. Set the ID. (0 - 255) 5-30...
Page 206: Overview
Table Data Display Table Data Display 5.4.1 Overview • Sets of data can be displayed in tabular format with ease. • Select from number display, character display, message display, or text for the data display part. • The properties of multiple data display parts can be changed at once. •...
Page 207 5 Data Display Style Item Description Area Setting Select from catalogs Select the part design. Detail Item Description Input Cursor Movement Control Select this checkbox when using the item selection function. Device For details on the item selection function, refer to “6.3.1 Item Select Function”.
Page 208: Numerical Data Display Settings
Table Data Display 5.4.3 Numerical Data Display Settings Each data cell can be selected to display a settings window for the corresponding cell. This section explains the case when [Num. Display] is selected for [Select Type]. Select Type Item Description Num.
Page 209 5 Data Display Incremental Direction Select Example: 12345 12345 12345 12345 Device memory: D200 12345 12345 12345 12345 [Incremental Direction] checkbox: selected (Down) 12345 12345 12345 12345 12345 12345 12345 12345 12345 12345 12345 12345 The device memory addresses of the selected data display cells change as shown below.
Page 210 Table Data Display Char. Prop. Item Description Value to Display on Preview This item is available when the [Display for the editor] checkbox is selected on the [View] → [Display Environment] → [Display] tab. Set the value to display using the editor. Char.
Page 211: Operation/Alarm
5 Data Display Operation/Alarm Item Description Alarm Select this checkbox to display data in a different color when it exceeds or falls short of a specific range. When “Entry Target” is selected for [Function], the range of values that can be entered using a keypad can be set.
Page 212: Character Display Settings
Table Data Display 5.4.4 Character Display Settings Each data cell can be selected to display a settings window for the corresponding cell. This section explains the case when [Char. Display] is selected for [Select Type]. Select Type Item Description Num. Display Select [Char.
Page 213 5 Data Display Char. Prop. Item Description Text to Display on Preview This item is available when the [Display for the editor] checkbox is selected on the [View] → [Display Environment] → [Display] tab. Set the text to display using the editor. Char.
Page 214: Message Display Settings
Table Data Display 5.4.5 Message Display Settings Each data cell can be selected to display a settings window for the corresponding cell. This section explains the case when [Message Display] is selected for [Select Type]. Select Type Item Description Num. Display Select [Message Display].
Page 215: Text Settings
5 Data Display 5.4.6 Text Settings Each data cell can be selected to display a settings window for the corresponding cell. This section explains the case when [Text] is selected for [Select Type]. Select Type Item Description Num. Display Select [Text]. Char.Display Message Display Text...
Page 216: Notes
Notes Notes 5.5.1 Transparency There is a limitation on the use of the [Transparent] setting. Item Max. Number of Parts Description TS2060 131,072 dots in total (= 262,144 bytes ... 64 k/32 k colors) (= 131,072 bytes ... 128 colors/monochrome) TS1000S 524,288 dots (same for 64 k/32 k/128 colors) If this limitation is exceeded, the transparency setting does not work correctly.
Page 217 5 Data Display Placing Table Data (with Switches) When [Text] is selected for the cell in the first column and first row of the table data, the entire first row is assigned the switch function. Consequently, any switch part placed on the first row will not be recognized correctly because it is the same as placing a switch on a switch.
Page 218: Entry
Entry Numerical Data Entry Character Input Convenient Functions...
Page 220: Numerical Data Entry
Numerical Data Entry Numerical Data Entry 6.1.1 Overview Numerical data can be entered using keypads and slider switches and then written to specified device memory addresses. If the target data display is a numerical data display when entering data using a keypad, enter numerical data. Keypad •...
Page 221: Setting Examples
6 Entry 6.1.2 Setting Examples Placing an Entry Target and Keypad on the Screen There are two methods for placing these parts: placement using an entry target or placement using a keypad. Each procedure is described below using an example. 9 9 9 9 1 2 5 1250...
Page 222 Numerical Data Entry Placement Using a Keypad 1. Click [Parts] → [Entry ] → [Keypad] and place a keypad on the screen. 2. Display the settings window for the keypad, click the [Place Entry Target], and place an entry target. 3.
Page 223: Showing The Keypad Only When Necessary
6 Entry Showing the Keypad Only When Necessary This procedure is described below using an example. (The keypad disappears after entry.) 1653 1653 1. Click [Parts] → [Data Display ] → [Num. Display] and place a numerical data display on the screen. 2.
Page 224: Placing An Entry Display (Value Entry)
Numerical Data Entry Placing an Entry Display (Value Entry) This procedure is described below using an example. 9 9 9 9 Input 1 2 5 1250 1. Double-click the keypad placed on the screen to display the settings window. 2. Select the [Entry Display Part (Num. Display)] checkbox in [Style] → [Additional Parts List]. The selected parts are displayed in the preview window.
Page 225: Specifying An Entry Range
6 Entry Specifying an Entry Range This procedure is described below using an example. Example: Entry range: 0 to 9999 Maximum 9 9 9 9 Minimum 1 2 5 1250 1. Display the numerical data display settings window, click [Operation/Alarm] → [Alarm], and set “0” for the minimum value and “9999”...
Page 226: Slider Switch
Numerical Data Entry Slider Switch This procedure is described below using an example. 30.5 Move the slider switch while holding it down and release it to write the data change. 1. Click [Parts] → [Others] → [Slider Switch] and place a slider switch on the screen. 2.
Page 227: Detailed Settings
6 Entry 6.1.3 Detailed Settings Keypad Operation Select Item Description Entry Target Data Display Enter data with respect to an entry target placed on the screen or an overlap. Control Device This device memory controls entry. (PLC → TS) For details, refer to page 6-9.
Page 228 Numerical Data Entry Control device memory Control device memory controls entry. Consecutive addresses are used. The method of control differs depending on the setting of [Operation Select] → [Cursor Moved by]. • [Cursor Moved by]: UP/DW Switch Device Memory Description Entry area designation Entry area selection 1: Enabled, 0: Disabled...
Page 229 6 Entry • [Cursor Moved by]: Control Device Device Memory Description Cursor movement order numbers 0 to 255 Entry area designation Entry target data selection 0: Data display (numerical display, character display) 1: Table data display part Write enabled* 1: Enabled, 0: Disabled * The [Enable/disable the entry key (Bit 15)] checkbox must be selected.
Page 230 Numerical Data Entry Style Item Description Adjust Position Change the layout of the keypad and other added parts. Select from catalogs Change the keypad part. Additional Parts List * Select [For Keypad]. Use this list to add or remove entry-related parts. * The following switches can be used on keypads.
Page 231 6 Entry This setting is available when the [Allow to use Insert/DELETE keys when entering values] checkbox is selected in [System Setting] → [Unit Setting] → [General Setting]. This allows insertion by moving the cursor with the [LFT] and [RGT] function switches and deletion using the delete and backspace switches.
Page 232 Numerical Data Entry Detail Item Description Graphic The text placed on the graphic library can be regarded as entry text. Change between multiple graphic libraries using a switch that has [Function] set to “Graphic Library”. Coordinates Set the placement position of the keypad. Others Information Output Device This is the device memory that stores the entry state.
Page 233 6 Entry Information output device memory This is the device memory that stores the entry mode state. Consecutive addresses are used. Processing differs depending on the setting of [Detail] → [Output row/column numbers in table data display to information output device]. •...
Page 234 Numerical Data Entry • [Output row/column numbers in table data display to information output device]: Selected Device Memory Description Cursor movement order numbers 0 to 255 Entry area Entry target data selection 1: Table data display part, 0: Data display part Entry operation 1: Enabled, 0: Disabled Write status...
Page 235: Entry Target
6 Entry Entry Target This section only explains the essential entry settings. Numerical Data Display Contents Item Description Device Set the device memory for writing. Function Item Description Function Set the entry target. Cursor movement order Set the cursor movement order. The cursor can be moved with the [UP] and [DW] switches or using a control device memory.
Page 236 Numerical Data Entry Operation/Alarm Item Description Alarm Set the entry range. Data can be entered within the range of the minimum and maximum values. If data that exceeds the specified range is entered using an external command (other than a keypad), the entry target is displayed in the specified color.
Page 237: General Settings
6 Entry Table Data Display General settings Location of settings: Double-click on the table data display • Detail Item Description Input Cursor Movement Perform cursor movement control. For details, refer to “6.3.1 Item Select Function” page 6-33. Control Device Order INC When the table data display contains multiple table data display parts for which [Function] is set to “Entry Target”, this determines the order of precedence of each table data display part.
Page 238 Numerical Data Entry • Contents Item Description Device Set the device memory for writing. • Function Item Description Function Set the entry target. • Operation/Alarm Item Description Alarm Set the entry range. Data can be entered within the range of the minimum and maximum values. If data that exceeds the specified range is entered using an external command (other than a keypad), the entry target is displayed in the specified color.
Page 239: Slider Switch
6 Entry Slider Switch Style Item Description Area Setting Set the part design. Output Setting Item Description Device Set the device memory for writing data. Data Length Set data length for the device memory. (1-Word/2-Word) Direction Set the sliding direction. Determine the number of Select this checkbox to automatically define the number of divisions for the rail according to the size and divisions according to the...
Page 240: Character Input
Character Input Character Input 6.2.1 Overview A keyboard (or USB keyboard) or barcode reader can be used to enter text data (ASCII code data) to be written to the specified device memory address. If the target data display is a character display when entering data using a keyboard, enter text data. Keyboard •...
Page 241: Barcode Reader
6 Entry Password A password entry screen can be created using a character display. Judgment result Enter “1999”. D300 = 0 • Device memory: D300 Enter “1231”. D300 = 1 • Function: Password Input (Fixed) - No. 0: 1999 Enter “2000”. D300 = −1 - No.
Page 242: Setting Examples
Character Input 6.2.2 Setting Examples Placing an Entry Target and Keyboard on the Screen There are two methods for placing these parts: placement using an entry target or placement using a keyboard. Each procedure is described below using an example. TEST Entry Target Input...
Page 243 6 Entry Placement Using a Keyboard 1. Click [Parts] → [Entry ] → [Keyboard] and place a keyboard on the screen. A keyboard can also be placed after selecting a design from [Catalog]. 2. Display the settings window for the keyboard, click the [Place Entry Target], and place an entry target. 3.
Page 244: Showing The Keyboard Only When Necessary
Character Input Showing the Keyboard Only When Necessary This procedure is described below using an example. (The keyboard disappears after entry.) TEST TEST Entry Target P CLR ↑ Q W E : BS ↓ SP ENTER 1. Click [Parts] → [Data Display ] →...
Page 245: Usb Keyboard Entry
6 Entry USB Keyboard Entry Text can be entered with respect to the entry target using a USB keyboard connected to the USB-A port. Only one USB keyboard can be connected. 1564 T-L-00A T-L-00B 1653 R-L-00A 1. Click [Parts] → [Data Display ] →...
Page 246: Password Input
Character Input Password Input This procedure is described below using an example. Judgment result Enter “1999”. D300 = 0 • Device: D300 Enter “1231”. D300 = 1 • Function: Password Input (Fixed) - No. 0: 1999 Enter “2000”. - No. 1: 1231 D300 = −1 - No.
Page 247 6 Entry 4. Set the device memory for outputting the password judgment result with [Contents] → [Device]. E.g. D300. This completes the necessary settings. The password judgment result is stored in D300. - Password matches: When the password is accepted, No. 0 to 3 is stored. - Password does not match: −1 (FFFF H) is stored.
Page 248: Detailed Settings
Character Input 6.2.3 Detailed Settings Keyboard Operation Select / Detail These are the same as for the keypad. For details, refer to “Operation Select” page 6-8.“Detail” page 6-13 Style Item Description Adjust Position Change the layout of the keyboard and other added parts. Select from catalogs Change the keyboard part.
Page 249 6 Entry Part Function Description Switch Multi-char. Input Changeover the text for each pattern with the [Char. Switching (+)] and [Char. Switching (−)] switches. Text on switches changeover according to the conversion modes of 1-byte/2-byte and caps lock. Switching (Entry Mode Change) Switching (1-byte/2-byte Char.
Page 250: Entry Target
Character Input Entry Target This section only explains the essential entry settings. Character Display Contents Item Description Device Set the device memory for writing. No. of Bytes Specify the number of bytes (number of characters). Function Item Description Function Set the entry target. Cursor movement order Set the cursor movement order.
Page 251 6 Entry Table Data Display General settings Location of settings: Double-click on the table data display • Detail Item Description Input Cursor Movement Perform cursor movement control. For details, refer to “6.3.1 Item Select Function” page 6-33. Control Device Order INC When the table data display contains multiple table data display parts for which [Function] is set to “Entry Target”, this determines the order of precedence of each table data display part.
Page 252: Convenient Functions
Convenient Functions Convenient Functions 6.3.1 Item Select Function Overview The cursor can be moved to a specific entry target. This is called the “item select function.” There are two methods for moving the cursor: using a switch or using an external command from the device memory specified for [Input Cursor Movement Control Device] (page 6-34).
Page 253: Item Select With [Input Cursor Movement Control Device]
6 Entry Item Select with [Input Cursor Movement Control Device] Set a [Input Cursor Movement Control Device] at the position of the placed entry target. The cursor can be moved to the specific entry target by setting the relevant [Input Cursor Movement Control Device] bit either ON or OFF. Cursor movement Maximum 9 9 9 9...
Page 254 Convenient Functions When the entry target is a table data display Assignment depends on the number of columns of the table data display part. • Table with 1 to 16 columns For a table with 1 to 16 columns, one word is used for each line. The total number of words used is the same as the number of lines.
Page 255: Data Block Area
6 Entry 6.3.2 Data Block Area Overview If the screen display area is not sufficient, you can switch over the entry targets displayed on the screen. Register the data for these entry targets to be switched as data blocks. Entry Screens Entry Screens Max.
Page 256: Setting Procedure
Convenient Functions 6.3.3 Switching over Characters Displayed on Entry Keys Overview If the screen display area is not sufficient, you can switch over characters displayed on the entry keys. Register the characters to be switched as graphic libraries. Graphic Library Group No.
Page 257 6 Entry Graphic Library Configuration 1. Click [Home] → [Registration Item] → [Graphic Library] to display the [Graphic Library Edit] tab window. 2. Click [View] → [Display Environment], and select the [Others] tab window. 3. Select the [Base Screen Dsp.] checkbox and set the screen number where the switches are placed. The switches on that screen are displayed on the [Graphic Library Edit] tab window.
Page 258 Convenient Functions Switch (Character Change Key) Configuration This section describes how to create a switch for switching over the created graphics. Configure the [Function] settings. Item Description Entry Graphic Library Specify the graphic library number on which the characters are registered. Set the same ID as specified for the entry keys.
Page 259: Type: Direct
6 Entry 6.3.4 Type: Direct Overview Select [Type: Direct] to externally control the data format, number of digits, number of decimal places, etc. Setting Procedure 1. Click [Parts] → [Entry] → [Keypad] or [Keyboard] and place an entry part. 2. Configure settings on the settings window of the entry part as shown below. •...
Page 260: Control Device
Convenient Functions Control Device Device Memory Description Clear Display format Write format 0: DEC 1: BCD Display format Specify the display format for the entered data. Bit Number Display format DEC (w/o sign) DEC (with sign −) DEC (with sign +−) Text Write format Specify the format for writing data to [Information Output Device] “n + 2”...
Page 261: Entry Procedure
6 Entry Information Output Device Device Memory Description Entry operation Display format Write format 0: Disabled 0: DEC 1: Enabled 1: BCD Write status 0: Not written 1: Write completed Display format Data specified in [Control Device] “n” (page 6-41) is written. Write format Entry operation This bit is valid when multiple entry mode parts are placed on the screen.
Page 262 Trends Overview Historical Display Real Time Display...
Page 264: Overview
Overview Overview There are two types of trend sampling: historical display (logging server) and real time display. Historical Display • The values of device memory addresses registered to the buffering area can be saved as history data. Data acquisition can be performed at a fixed cycle or using a trigger bit (0 →...
Page 265: Historical Display
7 Trends Historical Display 7.2.1 Buffering Area • The area for saving acquired data which is to be used for historical display is called the buffering area. Including alarm history data, a maximum of 12 buffering area numbers can be registered. Logging is performed at a fixed cycle or by using a trigger bit (0 →...
Page 266: Detailed Settings
Historical Display Detailed Settings Location of settings: [System Setting] → [Buffering Area Setting] List View List View Item Description Add Alarm Create a new buffering area number for registering alarm history data. A maximum of 12 buffering area numbers can be registered including area numbers for trend sampling parts. Add Trend Create a new buffering area number for registering trend history data.
Page 267: Basic Settings
7 Trends Basic Settings Item Description Sampling Set the sampling method. Bit Synchronization Perform sampling when the [Trigger Bit] device memory changes from 0 to 1. Location of settings:“Control Device Setting” page 7-6 1 : ON 0 : OFF Constant Sampling Perform sampling at the interval specified at [Acquisition Intervals].
Page 268 Historical Display Data Output Settings Primary Storage Target Configure the settings for storing to SRAM (DRAM). Item Description Device Type Set the save destination for sampled data. SRAM Back up history data when power to the unit is OFF (on battery power) and when changing between RUN and Local mode.
Page 269: Control Device Setting
7 Trends Control Device Setting Item Description Sampling Control Device Common Setting Device memory addresses are allocated for each buffering area number consecutively from read area “n + 3”. Sampling Control Device = Read area Buff. area No. 3 Buff. area No. 2 Buff.
Page 270 Historical Display CSV Format Setting Specify the CSV file format on this tab window, when specifying [Storage] as the [Secondary storage target] or when outputting data to a CSV file using macro commands. Item Description Date Display Select the format for dates. Display month/date with zero suppress Select this checkbox to display the month and date with zero suppression.
Page 271 7 Trends • CSV file for titles CSV filename SMHxxxx.CSV (xxxx= 0000 to 0011: Buffering area number) CSV file size Max. 239 KB Number of title rows and Unlimited columns Storage location “SAMPLE” folder inside the access folder (Access folder) SD card DAT0000 BITMAP...
Page 272: Timing Of Data Storage
Historical Display Timing of Data Storage Primary Storage Destination: DRAM/SRAM Sampled data is stored constantly during sampling. Secondary Storage Destination: Storage Device/Memory Card Data in the primary storage destination will be output to the secondary storage destination at the times shown below: •...
Page 273: Create Backup File
7 Trends Create Backup File Data in the primary storage destination is output to the secondary storage destination as a BIN file, and data in the file is copied to the storage device as backup. Timing of Saving • When the power is turned on •...
Page 274: Csv Output & Creating Backup Files
Historical Display CSV Output & Creating Backup Files When [CSV Output] is selected, “SMPxxxx.CSV” is created from “SMPxxxx.BIN” in the “SAMPLE” folder. Consequently, when [Create Backup File] is also selected, “SMPxxxx.BIN” and “SMPxxxx.CSV” are both saved in the backup folder. (The same operation as when macro commands “SMPL_BAK”...
Page 275: Graph Display
7 Trends 7.2.2 Graph Display • History data saved to the buffering area can be displayed as a line graph or rectangular waves. • A maximum of 16 graph lines can be displayed in one graph area. History data • Each graph line can be shown or hidden. Showing or hiding graphs can be easily changed as necessary, according to operating conditions.
Page 276: Detailed Settings
Historical Display Detailed Settings Operation Select Item Description Display Mode Select [Historical Display]. Display Method Select [Graph]. Contents 7-13...
Page 277: Reference Line
7 Trends Graph Item Description Shape Set the graph shape. Line/Rectangular Display Mode Sequential Draw the graph in the direction of movement. Pen Recorder Display a pen recorder type graph. Newest data is always on the right. [Direction]: RGT, [Display Mode]: Sequential [Direction]: RGT, [Display Mode]: Pen Recorder Newest data Newest data...
Page 278: Graph Setting
Historical Display When device memory is specified for the minimum and maximum scale values and the values in the device memory is changed in RUN mode, the change will be updated to the graph when the graph is displayed or when the “TREND_REFRESH” macro command is executed.
Page 279 7 Trends Item Description Device Displays the sampling device memory. The device memory can be changed in the settings of the buffering area number set in the [Data Acquisition] settings. Input Format Select the format for display on the screen. DEC-/BCD, Actual Number DEC-/BCD This is determined by the setting at [System Setting] →...
Page 280 Historical Display Style Item Description Adjust Position Change the layout of parts. Select from catalogs Change the trend sampling parts. Add Parts Add new parts. New parts are added to the [Addition Parts List]. • The additional parts are listed below. Function Description Roll Up...
Page 281: Scale Display
7 Trends Scale Display Item Description Axis Color Select the color of the major and minor tick marks, and axis lines of the scale. This setting is common to all left, right, bottom, and top sides. Back Color Display Minor scale Set the length of the minor tick marks of the scale.
Page 282 Historical Display Detail Item Description Show/hide graph data Set the device memory used to show/hide graph line numbers 0 to 15. * Device These bits control whether each graph is shown or hidden. (word designation) 1: Show 0: Hide Graph number 3 Graph number 15 Graph number 2 Graph number 1...
Page 283: Notes
7 Trends Notes Relationship Between Area and Plot Points The TS automatically calculates the plot point pitches for drawing graph lines as follows: Formula: Point pitch (dots) = X size (dots) ÷ ([Points to Display] − 1) Area Plot Point Pitch X size Minimum plot point pitch: 1 dot Number of display points = Maximum number of points (11)
Page 284: Data Display
Historical Display 7.2.3 Data Display • History data saved to the buffering area can be displayed as numerical data or character data. • A maximum of 16 entries of data can be displayed in a single display area. History data •...
Page 285: Detailed Settings
7 Trends Detailed Settings Operation Select Item Description Display Mode Select [Historical Display]. Display Method Select [Data]. Data Acquisition Item Description Set registered buffering area number. The registration details are shown below. Edit Edit the buffering area. For details, refer to “Detailed Settings”...
Page 286: Data Setting
Historical Display Data Setting Item Description Use Windows fonts Display history data using a Windows font. Register all text to display via [Windows Font Registration]. Number of Columns Set the number of data entries to display. Max. 16 Specify which word the data corresponds to in the number of data to acquire specified for the logging Target Device No.
Page 287 7 Trends Item Description Char. Color Set the text properties. Back Color Bold Shadow Italic Transparent Character Size Zero Suppress Set the display method for numerical values that do not satisfy the specified digits condition. Selected: Do not display zeros in front of the value Unselected: Display zeros in front of the value Char.
Page 288: Alarm Operation
Historical Display Alarm/Operation Item Description Alarm If a value is outside the range of the maximum and minimum values, the color for display can be changed. Operation Perform an operation on the value of the device memory. Scaling Data (Range before Scaling) that the PLC has read is converted into the set range (Range after Scaling) that is set.
Page 289: Sample Print
7 Trends Sample Print Overview History data saved to the buffering area can be printed. PictBridge Printed result Buffering area No. 1 No. 2 07-20 16:15:43 07-20 16:15:43 07-20 16:15:51 07-20 16:15:51 07-20 16:15:52 07-20 16:15:52 07-20 16:21:12 07-20 16:21:12 07-20 16:21:54 07-20 16:21:54 07-20 16:21:55...
Page 290 Historical Display Registration example [Print Message] Message GNo. 2 : No. 0 [Zero Suppress] unselected [Flush Left] Message GNo. 2 editing Printed result Logging ---LINE1--- ---LINE2--- count Time No. 1 No. 2 No. 3 No. 4 06-04 13:14:20 1234 4562 1111 Title 06-04 13:34:20...
Page 291: Real Time Display
7 Trends Real Time Display • Values in consecutive device memory addresses can be expressed on a line graph. Subsidiary lines can be drawn for easier recognition of data changes. Example: Graph display of data in addresses D100 to D110 D102 D103 D104 D105 D106 D107 D108...
Page 292: Location Of Settings
Real Time Display 7.3.1 Location of Settings Click [Parts] → [Trend] and place a graph on the screen. For details on the display method, refer to “7.3.4 Display Method” page 7-38. 7.3.2 Detailed Settings Operation Select Item Description Display Mode Select [Real Time Display].
Page 293 7 Trends Graph Item Description Shape Set the graph shape. Line/Rectangular Direction Set the direction of graph lines. • RGT (right) • LFT (left) • UP (upward) • DW (downward) Graph X: Time axis origin Y: Trend data Reference line Item Description Reference Line...
Page 294 Real Time Display Graph Setting Item Description Set the number of plot points along the horizontal axis. Points to Display - 320 × 240 dots: 3 to 320 - 800 × 480 dots: 3 to 800 Control Device 0 → 1: Redraw Points to Display 0 →...
Page 295 7 Trends Item Description Item to Display Change the items displayed in the [Detail Settings] area. Number of display points Direction: RGT Number of plotted points: 6 Graph area Plot Point Pitch Graph origin Number of display points = Maximum number of points (11) If a value larger than the X size (dots) of the graph area is specified for [Points to Display], the graph will not be drawn correctly.
Page 296 Real Time Display Scale Display Item Description Axis Color Select the color of the major and minor tick marks, and axis lines of the scale. This setting is common to all left, right, bottom, and top sides. Back Color Display Minor scale Set the length of the minor tick marks of the scale.
Page 297: Plot Point Pitch
7 Trends Detail Item Description Coordinates Set a display position and size. Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”. High Speed/Low Speed/Refresh Overlap Select this checkbox to display multiple graphs asynchronously or 17 or more lines in one graph area. For details, refer to “7.3.5 Asynchronous Display of Multiple Trend Graphs”...
Page 298 Real Time Display Type Equal pitch Plot points are automatically set at an equal pitch. MONITOUCH calculates a pitch between plot points as shown below. (MONITOUCH adjusts the data so that no remainder will result.) Formula: Point pitch (dots) = X size of graph (dots) ÷ ([Points to Display] - 1) X size: 300 dots Graph origin: 0 Plot point pitch: 30 dots...
Page 299 7 Trends Device Memory Allocation The allocation of device memory addresses differs depending on the [Points to Display] setting and the data length of each graph. Equal pitch Point data is stored consecutively from the set device memory address. Device memory address setting: n Data length: word Data length: double word n + 0...
Page 300 Real Time Display Specify the scale range, specify the number of dots Point data and pitch data (dot or scale value) from the set device memory address are stored one after the other. A device for pitch data is allocated following the device memory for each point. Device memory address setting: n Data length: word Data length: double word...
Page 301: Display Method
7 Trends 7.3.4 Display Method This section explains the display method using an example of graph control device memory D1000. 1. Check the graph control device (e.g. D1000). Location of setting: [Trend] settings → [Graph Setting] → [Control Device] 0 to 1024: Points to Display 0 →...
Page 302: Asynchronous Display Of Multiple Trend Graphs
Real Time Display 7.3.5 Asynchronous Display of Multiple Trend Graphs All the trend lines in the graph area are drawn at the same points and at the same timing because trend graphs have one word of control device memory. To draw multiple trend lines at different timings, two or more graphs must be overlaid and linked, thereby assigning priorities to respective control device memory.
Page 303 7 Trends 4. In the [Trend] settings window of the other graph, set D140 to [Graph Setting] → [Control Device]. 5. Set “High Speed” for [Detail] → [Process Cycle] and “0” for [Overlap] (child trend graph). 6. Place the parent trend graph under the child trend graph to overlap the two graphs. This completes the necessary settings.
Page 304 Real Time Display Display Method This section explains how to draw two trend graphs based on the example in “Setting Procedure” page 7-39. 1. Set D120 to 9H (number of plotted points). The parent trend graph is drawn with up to 9 plot points. 2.
Page 305 7 Trends 7-42...
Page 306: Alarm
Alarm Overview Historical Display Real Time Display...
Page 308: Overview
Overview Overview There are two methods for displaying alarms: historical display and real time display. Historical Display • The states of device memory registered to the buffering area can be saved as alarm history. History data can be output to a CSV file on a storage device by turning the relevant bit ON for checking on a PC.
Page 309: Real Time Display
8 Alarm • Parameter display When an alarm occurs, the data (parameters) associated with the alarm can be saved/displayed together with an alarm message. Logging the history of such alarm-relevant parameters will make it easier to locate and investigate the causes of alarms.
Page 310: Historical Display
Historical Display Historical Display 8.2.1 Buffering Area • The area for saving acquired data which is to be used for historical display is called the buffering area. Including those for trend history data, a maximum of 12 buffering area numbers can be registered. Buffering area Method: Alarm tracking...
Page 311: Detailed Settings
8 Alarm Detailed Settings Location of settings: [System Setting] → [Buffering Area Setting] List View List View Item Description Add Alarm Create a new buffering area number for registering alarm history data. A maximum of 12 buffering area numbers can be registered including area numbers for trend sampling parts. This section describes the setting procedure for this item.
Page 312 Historical Display Basic Settings Item Description Sampling Set the sampling method. Alarm Logging Data is sampled at the ON/OFF edge of each bit. Applicable sampling mode: Alarm logging Time Order Alarming A message is displayed at the ON edge of each bit. When the bit is reset (OFF), the message disappears. This function uses the buffering area temporarily to show the messages in chronological order or reverse chronological order.
Page 313 8 Alarm Data Output Settings Primary Storage Target Configure the settings for storing to SRAM (DRAM). Item Description Device Type Set the save destination for sampled data. SRAM Back up history data when power to the unit is OFF (on battery power) and when changing between RUN and Local mode.
Page 314 Historical Display Control Device Setting Item Description Sampling Control Device Common Setting Device memory addresses are allocated for each buffering area number consecutively from read area “n + 3”. Sampling Control Device = Read area Buff. area No. 3 Buff. area No. 2 Buff.
Page 315 8 Alarm CSV Format Setting Specify the CSV file format on this tab window, when specifying [Storage] as the [Secondary storage target] or when outputting data to a CSV file using macro commands. Item Description Set the display format for the time information that is attached to alarm messages. Output Time •...
Page 316 Historical Display By default, only the buffering area number is output and there are no titles. To add titles to data, save a CSV file with titles in the “SAMPLE” folder on the storage device in advance. Title • CSV file for titles CSV filename SMHxxxx.CSV (xxxx= 0000 to 0011: Buffering area number) CSV file size...
Page 317 8 Alarm Others Item Description Monitoring Intervals Set the monitoring frequency of alarm bits. 0 to 65535 (0 means every cycle) Units: Seconds or 100 milliseconds Check this box when using the acknowledge function. Use Acknowledge function (Refer to “8.3.3 Acknowledge Function” page 8-51.) Check this box when using the alarm acknowledge function.
Page 318: Timing Of Data Storage
Historical Display Timing of Data Storage Primary Storage Destination: DRAM/SRAM Sampled data is stored constantly during sampling. Secondary Storage Destination: Storage Device/Memory Card Data in the primary storage destination will be output to the secondary storage destination at the times shown below: •...
Page 319: Create Backup File
8 Alarm Create Backup File Data in the primary storage destination is output to the secondary storage destination as a BIN file, and data in the file is copied to the storage device as backup. Timing of Saving • When the power is turned on •...
Page 320: Csv Output & Creating Backup Files
Historical Display CSV Output & Creating Backup Files When [CSV Output] is selected, “SMPxxxx.CSV” is created from “SMPxxxx.BIN” in the “SAMPLE” folder. Consequently, when [Create Backup File] is also selected, “SMPxxxx.BIN” and “SMPxxxx.CSV” are both saved in the backup folder. (The same operation as when macro commands “SMPL_BAK”...
Page 321: Alarm Tracking
8 Alarm 8.2.2 Alarm Tracking Place an alarm tracking part to check alarm history saved to the buffering area on MONITOUCH. An alarm tracking part can be placed by clicking [Parts] → [Alarm]. Detailed Settings Operation Select Item Description Display Mode Select [Alarm Tracking].
Page 322 Historical Display Contents Item Description Time to Display Set the display format for the time that is displayed with messages. Time information attached to an error message varies depending on the format selected. For [Time Lag Display], [Total Time of Occurrence Display] and [Time of Occurrence Display], the time is displayed in units of hours.
Page 323: Monitoring Alarm
8 Alarm Monitoring Alarm Item Description Buffering Area No. Set registered buffering area number. The registration details are shown below. Edit Edit the buffering area. For details, refer to “8.2.1 Buffering Area” page 8-3. Character Properties Item Description Apply the same settings as Select this checkbox to use a Windows font for alarm messages.
Page 324 Historical Display Auxiliary Screen Item Description Enable screen switching The screen can be changed by tapping a displayed alarm message. Screen No. Set a screen number from 0 to 9999. Refer Check the registered screens. About the auxiliary screen function Tap the message on the alarm part to changeover the screen.
Page 325 8 Alarm Style Item Description Additional Parts List Displays a list of alarm-related parts. Selected: Displayed on MONITOUCH. Unselected: Not displayed on MONITOUCH. Parts can be added to the list using the [Add Parts] button. Roll Up Scroll the display up by one page. Roll Down Scroll the display down by one page.
Page 326 Historical Display Show/Hide Set the show and hide settings of alarm parts. For details, refer to “14 Item Show/Hide Function”. Detail Item Description Primary Cause Add a (*) mark to the primary cause Select this checkbox to mark alarm messages which are primary causes with Judgment asterisks.
Page 327: Alarm Logging
8 Alarm 8.2.3 Alarm Logging • Depending on the ON/OFF state of the relevant bit, the corresponding error message and time information are stored in the buffering area and are displayed as historical data on the screen. Alarm Logging Tank A temperature rise <ON>...
Page 328: Detailed Settings
Historical Display Detailed Settings Operation Select Item Description Display Mode Select [Alarm Logging]. Display Order Set the display order of alarm messages. Ascending Order: Display in the order of old errors → new errors. Descending Order: Display in the order of new errors → old errors. Contents Item Description...
Page 329 8 Alarm Item Description Display Item Activate Status Display Select this checkbox to display the bit ON/OFF status on the display area. Unselected: 07-20 11:32:10 A tank temperature rise 07-20 11:33:15 A tank temperature rise 07-20 11:40:25 C tank temperature drop 07-20 11:50:13 C tank temperature drop Selected:...
Page 330 Historical Display Item Description Status Display Display on char. display Select this checkbox to display the alarm status on a character display part placed outside of part the display area of the alarm part. The following settings are available when selected. [Display ON/OFF/CHK] selected: When the bit is ON, “<ON>”...
Page 331 8 Alarm Message Item Description Specify messages separate Select this checkbox to individually specify messages from the item. from those in buffering area When selected, the start message can be specified. settings Character Properties Item Description Apply the same settings as Select this checkbox to use a Windows font for alarm messages.
Page 332 Historical Display Style Item Description Additional Parts List Displays a list of alarm-related parts. Selected: Displayed on MONITOUCH. Unselected: Not displayed on MONITOUCH. Parts can be added to the list using the [Add Parts] button. Roll Up Scroll the display up by one page. Roll Down Scroll the display down by one page.
Page 333 8 Alarm Show/Hide Set the show and hide settings of alarm parts. For details, refer to “14 Item Show/Hide Function”. Detail Item Description Print Print command device Configure when using the sample print function. For details, refer to “Sample Print” page 8-27.
Page 334: Sample Print
Historical Display Sample Print Alarm logging data can be printed. All the data in the buffer is printed. Printed result Tank A temperature rise Tank A temperature rise occurred <ON> 07-20 16:15:43 07-20 16:15:43 Tank C temperature drop Tank C temperature drop occurred <ON>...
Page 335: Real-Time Printing
8 Alarm Location of Settings [System Setting] → [Unit Setting] → [General Setting] → [Print Alarm Logging Data in the Displayed Format] Selected: Print in the same format as shown on the screen Unselected: Print all ON/OFF operations Real-Time Printing Each time a bit status changes, the changed content only can be printed.
Page 336: Parameter Display Function
Historical Display 8.2.4 Parameter Display Function When an alarm occurs, the data (parameters) associated with the alarm can be saved/displayed together with an alarm message. Logging the history of such alarm-relevant parameters will make it easier to locate and investigate the causes of alarms.
Page 337: Parameter Table
8 Alarm Parameter Table A parameter table can be registered for each alarm device memory address. Item Description Parameter No. (0 to 7) Create parameters with the [Add] button. Up to 8 parameters can be registered per alarm device memory address. Add a new parameter.
Page 338: Editing Messages
Historical Display Editing Messages Register parameter numbers into alarm messages. %PxS 0 to 7 Specify parameter numbers registered in the [Parameter Table] window. Limitations • When the parameter settings have been made with Windows fonts, parameter symbols (%PxS) are displayed instead of the relevant parameter.
Page 339: Alarm Acknowledge Function
8 Alarm 8.2.5 Alarm Acknowledge Function • In addition to alarm messages and time of occurrence/reset, an alarm tracking part can also display the time that an alarm was acknowledged by placing an “acknowledge” switch. Acknowledged and unacknowledged messages can also be differentiated by color.
Page 340 Historical Display Alarm Part Contents Add acknowledgement status Select this box. (acknowledge function) Select [Occurrence/Confirmation Time] for [Occurrence/Cancellation/Confirmation Time]. Time to Display *1 [Time to Display] setting [Occurrence/Confirmation Time] Time of Occurrence Acknowledged time 09/ 2/ 2 08:30:45 09/ 2/ 2 11:34:00 #2 Roller error #1 Sensor error...
Page 341: Operation Example
8 Alarm Style Acknowledge This switch acknowledges a currently selected unacknowledged alarm message. Acknowledge All This switch acknowledges all unacknowledged alarm messages. Operation Example When the acknowledge function is used, there are four display statuses for messages and times. In this example, the following colors are selected for each status. A: An alarm is occurring but not acknowledged yet: black B: An alarm is reset but not acknowledged yet:...
Page 342: Limitations
Historical Display Limitations • The maximum alarm acknowledgement time is 65,535 seconds (approximately 18 hours) from the time of occurrence. If the acknowledge switch is pressed after 65,535 seconds or more elapse, the displayed acknowledgement time is the time of occurrence plus 65,535 seconds. •...
Page 343: Real Time Display
8 Alarm Real Time Display 8.3.1 Bit Order Alarming • This is a function for displaying or erasing messages on the screen by setting or resetting bits. When multiple bits are set, messages are displayed in order of precedence (refer to page 8-39).
Page 344: Location Of Settings
Real Time Display • Also, it is possible to use a screen for alarm sub-display. (Refer to “Sub-Display Function” page 8-44.) Bring up a screen set to the message Messages are displayed when (example: Line B data). corresponding bits in the PLC device memory are ON.
Page 345: Detailed Settings
8 Alarm Detailed Settings Operation Select Item Description Display Mode Select [Bit Order Alarming]. Message Item Description Specify the command device memory address used to display a registered message on the screen. Device Top Device memory addresses are automatically allocated to the messages by bit for the number specified by [Number of Monitoring Alarms] (see below) from the specified top address.
Page 346 Real Time Display *1 Precedence in displaying messages Precedence is assigned to the messages displayed by bit order alarming. Based on the device memory bits assigned, the smaller the bit number, the higher the precedence given; the larger the bit number, the lower its precedence. When messages are displayed on the screen, those of higher precedence are displayed first.
Page 347: Auxiliary Screen
8 Alarm Auxiliary Screen Item Description Use sub-display function Select this checkbox to set a supplemental display for one bit order alarming message. Display Type Sub-Display: Select this option when you want to configure a supplemental display for a bit order alarming message.
Page 348 Real Time Display Style Item Description Additional Parts List Displays a list of alarm-related parts. Selected: Displayed on MONITOUCH. Unselected: Not displayed on MONITOUCH. Parts can be added to the list using the [Add Parts] button. Roll Up Scroll the display up by one page. Roll Down Scroll the display down by one page.
Page 349 8 Alarm Detail Item Description Use relay information output device Choose whether or not to output data of the message displayed or selected for bit order alarming to the PLC. If outputting data, select the checkbox, and specify a top device memory address. Relay information output device (top address “n”) Addresses are allocated as shown below.
Page 350 Real Time Display Item Description Others Choose from [Display Area], [Switch] or [Lamp] for specifying the place where the message should be Operation Area displayed on the screen when the corresponding bit is set or reset. Display Area: Shows messages on display area parts placed on the screen. Switch: Shows messages on switch parts placed on the screen.
Page 351: Sub-Display Function
8 Alarm Sub-Display Function This function is used to display detailed explanations for bit order alarming messages (which are displayed by setting bits). Sub-Display • Alarm sub-displays must be used together with bit order alarming. Text or graphics can be called up from a bit order alarming message. For example, this function can be used to display a diagram indicating where an alarm is occurring.
Page 352: Screen Call
Real Time Display Screen Call • Register content to be displayed for an alarm message to a separate screen in advance. When an alarm message is selected, the separately configured screen is displayed. This function is called the “screen call” function.
Page 353 8 Alarm Notes • The sub-display function is available when [Operation Area] is set to either [Display Area] or [Switch] in the [Detail] settings on the alarm part settings window. • Switch function of display area parts When an alarm message is shown in a display area part through the screen call function, the display area part is automatically furnished with the switch function.
Page 354: Time Order Alarming
Real Time Display 8.3.2 Time Order Alarming This is a function for displaying or clearing messages on the screen by setting or resetting bits. Difference from Bit Order Alarming Message Display With bit order alarming, messages are displayed in order of precedence when multiple bits are set. With time order alarming, messages are displayed in order of occurrence (from oldest or newest) (refer to page 8-48) when...
Page 355 8 Alarm Detailed Settings Settings which differ from those of bit order alarming only are described. Operation Select Item Description Display Mode Select [Time Order Alarming]. Display Order Set the display order of alarm messages. Ascending Order: Display in the order of old errors → new errors. Descending Order: Display in the order of new errors →...
Page 356: Other Differences From Bit Order Alarming
Real Time Display Monitoring Alarm Item Description Buffering Area No. Set registered buffering area number. The registration details are shown below. Edit Edit the buffering area. For details, refer to “8.2.1 Buffering Area” page 8-3. Other Differences from Bit Order Alarming Error Bit When assigning registered messages to bits in PLC device memory, the top address as well as the number of bits used must be set as described below.
Page 357 8 Alarm Time Order Alarming The device memory address is determined according to the specified buffering area number and the [Monitoring Device] setting in the [Buffering Area Setting] window. • When [Use Read Area] is selected: The address following the sampling control device memory is used as the start device memory. Buffer used: Up to No.
Page 358: Acknowledge Function
Real Time Display 8.3.3 Acknowledge Function • By using an acknowledge bit for time order alarming or bit order alarming, it is possible to indicate whether an alarm message has been acknowledged or not in different colors when an error has occurred. * However, note that, in the case of bit order alarming, acknowledged information will be cleared when the screen display is changed.
Page 359: Operation Overview
8 Alarm Operation Overview When the acknowledge function is used, switch or lamp parts are used as message display areas. One switch or lamp part can display one message line. There are four message display statuses. A: No error B: Error occurred C: Error is not reset and acknowledgment bit is ON D: Error is reset and acknowledgment is bit ON Different colors of switches or lamps configured with four patterns (OFF, ON, P3, and P4 colors), are used to denote these...
Page 360: Location Of Settings
Real Time Display Location of Settings Alarm Part Detail Operation Area Select either [Switch] or [Lamp]. Contents Add acknowledgement status Select this box. (acknowledge function) Acknowledgment Bit Error messages can be displayed in different colors according to their status by setting this bit (ON) while errors are displayed.
Page 361 8 Alarm *1 About [Time to Retrieve] [Time to Retrieve] is the duration that a message is displayed after it is reset. For errors that were already reset when the acknowledgment bit is set (ON), the duration is from the time that the acknowledgment bit was set. For errors that were not reset yet when the acknowledgment bit is set (ON), the duration is from the time that the error is actually reset.
Page 362 Real Time Display Style Item Description Additional Parts List Displays a list of alarm-related parts. Selected: Displayed on MONITOUCH. Unselected: Not displayed on MONITOUCH. Parts can be added to the list using the [Add Parts] button. Display real-time display messages on a switch. Mode (Switch) Display real-time display messages on a lamp.
Page 363: Display Of Acknowledge Function Screen After Screen Change
8 Alarm Display of Acknowledge Function Screen after Screen Change If a currently displayed acknowledge function screen in time order alarming is changed over to a different screen and then displayed again, the error information on the acknowledge function screen remains the same as that before the screen change.
Page 364: Graph Display
Graph Display Bar Graph Pie Graph Closed Area Graphs Panel Meter Statistic Bar Graph Statistic Pie Graph...
Page 366: Bar Graph
Bar Graph Bar Graph 9.1.1 Overview • Data in a device memory address can be expressed on a bar graph. 100% 7000 For setting examples, refer to “Displaying Current Values (Standard Display)” page 9-2. • When data in a device memory address exceeds or falls short of the range specified, the graph color can be changed. This helps the operator to recognize the situation easily and correctly.
Page 367: Setting Examples
9 Graph Display 9.1.2 Setting Examples Displaying Current Values (Standard Display) The current value of a device memory address within the range of the minimum and maximum values can be displayed (standard display). 100% 7000 1. Click [Parts] → [Graph] → [Bar Graph] and place a bar graph on the screen. 2.
Page 368 Bar Graph 3. Configure the following settings for [Style] and then click [Finish]. To change the graph color depending on the value, proceed to step 4. 4. Configure the [Alarm] settings to change the graph color depending on the value. In this case, color settings set for [Style] are disabled.
Page 369: Displaying Deviation From A Reference Value To The Current Value (Deviation Display)
9 Graph Display Displaying Deviation from a Reference Value to the Current Value (Deviation Display) A reference point can be set and then data from the reference point to the specified device memory address can be expressed on a graph. Reference point 1.
Page 370 Bar Graph 3. Configure the following settings for [Style] and then click [Finish]. To change the graph color depending on the value, proceed to step 4. 4. Configure the [Alarm] settings to change the graph color depending on the value. In this case, color settings set for [Style] are disabled.
Page 371: Detailed Settings
9 Graph Display 9.1.3 Detailed Settings Displayed Information Item Description Device Specify the device memory address to monitor as a graph. Input Type Select the data format of device memory values. (DEC- / BCD, Real Number) The selection here also applies to the values of [Target Value], [Standard Value], [Range], and [Alarm].
Page 372 Bar Graph Style Item Description Select from catalogs Type Set the part design. Color Set the part color. Select from image files Load a bitmap file. Data Color When [Standard] is selected for [Type]: Set the graph color from the minimum value to the device memory value. When [Deviation] is selected for [Type]: Set the graph color from the reference value to the device memory value.
Page 373 9 Graph Display Alarm • Type: Standard • Type: Deviation Item Description Use alarm display Change the colors of the graph according to the device memory value. When [Standard] is selected for Set the ranges for alarm display and each corresponding color. [Type]: Upper Limit2/Upper Value/Area within the...
Page 374 Bar Graph Examples of graphs with alarm settings When [Standard] is selected for [Type] Lower Within Upper limit range limit Area color color color color [Direction] set to RGT • With marks • Single color use • Separate color use Current Lower limit Upper limit...
Page 375 9 Graph Display Detail Item Description Coordinates Start X/Start Y Specify the placement coordinates. (Coordinates at top left of part) Width/Height Specify the width and height of the part. Others Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 376: Pie Graph
Pie Graph Pie Graph 9.2.1 Overview • Data in the specified device memory address can be expressed clockwise on a pie graph. For setting examples, refer to “Displaying Current Values (Standard Display)” page 9-12. • When data in a device memory exceeds or falls short of the range specified, the graph color can be changed. This helps the operator to recognize the situation easily and correctly.
Page 377: Setting Examples
9 Graph Display 9.2.2 Setting Examples Displaying Current Values (Standard Display) The current value of a device memory within the range of the minimum and maximum values can be displayed (standard display). 1. Click [Parts] → [Graph] → [Pie Graph] and place a pie graph on the screen. 2.
Page 378 Pie Graph 3. Configure the following settings for [Style] and then click [Finish]. To change the graph color depending on the value, proceed to step 4. 4. Configure the [Alarm] settings to change the graph color depending on the value. In this case, color settings set for [Style] are disabled.
Page 379: Displaying Deviation From A Reference Value To The Current Value (Deviation Display)
9 Graph Display Displaying Deviation from a Reference Value to the Current Value (Deviation Display) A reference point can be set and then data from the reference point to the specified device memory address can be expressed on a graph. Reference point 1.
Page 380 Pie Graph 3. Configure the following settings for [Style] and then click [Finish]. To change the graph color depending on the value, proceed to step 4. 4. Configure the [Alarm] settings to change the graph color depending on the value. In this case, color settings set for [Style] are disabled.
Page 381: Detailed Settings
9 Graph Display 9.2.3 Detailed Settings Displayed Information Item Description Device Specify the device memory address to monitor as a graph. Input Type Select the data format of device memory values. (DEC- / BCD, Real Number) The selection here also applies to the values of [Target Value], [Standard Value], [Range], and [Alarm].
Page 382 Pie Graph Style Item Description Select from catalogs Type Set the part design. Color Set the part color. Select from image files Load an image file. Data Color When [Standard] is selected for [Type]: Set the graph color from the minimum value to the device memory value. When [Deviation] is selected for [Type]: Set the graph color from the reference value to the device memory value.
Page 383 9 Graph Display Alarm • Type: Standard • Type: Deviation Item Description Use alarm display Change the colors of the graph according to the device memory value. The color settings are implemented in the area settings. When [Standard] is selected for Set the range for alarm display and each corresponding color.
Page 384 Pie Graph Examples of graphs with alarm settings When [Standard] is selected for [Type] Lower Within Upper Area limit range limit color color color color • With marks • Single color use Current value Current value Current value Upper limit Lower limit Upper Lower limit...
Page 385 9 Graph Display Detail Item Description Start X/Start Y Specify the placement coordinates. (Coordinates at top left of part) Coordinates Width/Height Specify the width and height of the part. Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 386: Closed Area Graphs
Closed Area Graphs Closed Area Graphs 9.3.1 Overview • Changes to data in a closed area, such as a tank, can be expressed on a closed area graph. 1234 For setting examples, refer to “Displaying Current Values” page 9-22. • When data in a device memory exceeds or falls short of the range specified, the graph color can be changed. For setting examples, refer to “Displaying Current Values”...
Page 387: Setting Examples
9 Graph Display 9.3.2 Setting Examples Displaying Current Values The current value of a device memory within the range of the minimum and maximum values can be displayed. 1. Click [Parts] → [Graph] → [Closed Area Graph] and place a closed area graph on the screen. 2.
Page 388 Closed Area Graphs 3. Configure the following settings for [Style] and then click [Finish]. To change the graph color depending on the value, proceed to step 4. 4. Configure the [Alarm] settings to change the graph color depending on the value. In this case, color settings set for [Style] are disabled.
Page 389: Detailed Settings
9 Graph Display 9.3.3 Detailed Settings Displayed Information Item Description Device Specify the device memory address to monitor as a graph. Input Type Select the data format of device memory values. (DEC- / BCD, Real The selection here also applies to the values of [Display Range] and [Alarm]. Current Number) * When [DEC-/BCD] is selected, the setting at [Code: DEC/BCD] under [Communication Setting] in...
Page 390 Closed Area Graphs Alarm Item Description Use alarm display Change the colors of the graph according to the device memory value. The color settings are implemented in the area settings. Upper Limit/Area within the Set the range for alarm display and each corresponding color. Area Setting Range/Lower Limit Display Setting...
Page 391 9 Graph Display Detail Item Description Start X/Start Y Specify the placement coordinates. (Coordinates at top left of part) Coordinates Width/Height Specify the width and height of the part. Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 392: Panel Meter
Panel Meter Panel Meter 9.4.1 Overview • Data in a device memory can be expressed in the form of an analog meter. The indicator can be selected to move in either the clockwise or counterclockwise direction. For setting examples, refer to “Displaying Current Values”...
Page 393: Setting Examples
9 Graph Display 9.4.2 Setting Examples Displaying Current Values The current value of a device memory within the range of the minimum and maximum values can be displayed. 1. Click [Parts] → [Graph] → [Panel Meter] and place a panel meter on the screen. 2.
Page 394 Panel Meter 3. Configure the following settings for [Style] and then click [Finish]. • Set the meter shape and color on the [Design] → [Meter] tab. • Set the indicator shape and color on the [Design] → [Indicator] tab. • Set the scale shape and color on the [Design] → [Scale] tab. To change the panel meter color depending on the value, proceed to step 4.
Page 395 9 Graph Display - When [Area] is selected for [Alarm Setting] → [Alarm Color Target] Set the color of the meter area and the range. (Up to 16 divisions) In this case, color settings set on the [Meter] tab in the [Style] settings are disabled. This completes the necessary settings.
Page 396: Detailed Settings
Panel Meter 9.4.3 Detailed Settings Contents Item Description Device Specify the device memory address to monitor. Input Type Select the data format of device memory values. (DEC- / BCD, Real Number) The selection here also applies to the values of [Range] and [Alarm]. * When [DEC-/BCD] is selected, the setting at [Code: DEC/BCD] under [Communication Current Value...
Page 397 9 Graph Display Style Item Description Select from catalogs Type Set the part design. Color Set the part color. Select from image files Load a bitmap file. Design Meter Set the color and size of the meter. For details, refer to “Meter”...
Page 398 Panel Meter Meter Item Description Full, Quarter, Half Select the shape of the meter. Color Set the color of the meter. Meter Target Value Set the color of the line displayed for the target value. Target Value * If [Alarm] is configured, this is disabled. Frame Display a frame around Select this checkbox to display a frame around the...
Page 399 9 Graph Display Indicator Item Description Color Set the indicator color. * If [Alarm Color Target] is set to [Indicator] in the [Alarm] settings, this is disabled. 9-34...
Page 400 Panel Meter Scaling Item Description Display the scale Select this checkbox to display a scale on the panel meter. Select from image files Select this checkbox to use an image file as the scale. Select Select an image file to display as the scale. Size Setting Width Change the width of the image file.
Page 401 9 Graph Display Item Description Direction Outside Display tick marks on the outside of the primary axis. Inside Display tick marks on the inside of the primary axis. Major Divisions Set the number of divisions on the major Example: Major scale divisions: 8 scale (1 - 255) scale across the entire scale.
Page 402: Alarm
Panel Meter Alarm Alarm color target: indicator Item Description Use alarm display Select this checkbox to use the alarm function. Alarm Alarm Color Indicator The indicator color is displayed using three alarm colors according to the upper and Setting Target lower limit values.
Page 403 9 Graph Display Alarm color target: area Item Description Use alarm display Select this checkbox to use the alarm function. Alarm Alarm Color Indicator The indicator color is displayed using three alarm colors according to the upper and lower Setting Target limit values.
Page 404: Num. Display
Panel Meter Num. Display A panel meter can be set with a numerical data display to show the current value. Item Description Use a numerical data display Select this checkbox to display a numerical data display within the panel meter. Contents Specify the display format, number of digits, and number of decimal places for the numerical data display.
Page 405 9 Graph Display Style Item Description Area Setting Select from catalogs Select the design of the numerical data display part to use from the parts catalog. Type Select the design of the numerical data display part. Color Set the color of the numerical data display part. Select from image files Select the design of the numerical data display part from an image file.
Page 406 Panel Meter Char. prop. Item Description Color Set the text color. Background Set the background color of the numerical data display area. Style Set the text style. Text Size Set the text size. * This setting changes to point specification when using a Windows font. Rotation + Set the orientation of text.
Page 407: Detail
9 Graph Display Detail Item Description Start X/Start Y Specify the placement coordinates. (Coordinates at top left of part) Coordinates Width/Height Specify the width and height of the part. Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 408: Using Image Files For The Background And Scale
Panel Meter 9.4.4 Using Image Files for the Background and Scale An image file created by the user can be used for the part design (background and scale). Style Background Scale Item Description Background Select from images files Select a bitmap file from the desired folder. The selected bitmap file is stored at “.\MONITOUCH\User\Parts”.
Page 409: Setting Procedure
9 Graph Display Setting procedure This section explains the procedure for importing a bitmap file into the panel meter. Scaling Background of the panel meter * Black (code 0, 0, 0) areas in the bitmap image automatically becomes transparent on MONITOUCH.
Page 410 Panel Meter 3. Select the [Style] → [Meter] → [Detail Settings] in the settings window to enlarge or reduce the size using the [Outer Radius] and [Inner Radius] values. Graph area 4. Import a bitmap image of the scale. Select the [Style] → [Scale] → [Display the scale] → [Select an image file] checkbox in the settings window and click the [Select] button to select an image file (e.g.
Page 411 9 Graph Display Restrictions • The maximum panel meter size is width × height = 65936 dots. • The order of drawing is shown below. Drawing is performed in ascending order. Panel meter structure 4. Indicator 1. Part area * 2.
Page 412: Statistic Bar Graph
Statistic Bar Graph Statistic Bar Graph 9.5.1 Overview • Percentages of data contained in consecutive device memory addresses can be expressed on a graph. One statistic bar graph can be divided into a maximum of eight sections. For setting examples, refer to “Displaying a Bar Graph of the Ratio of D100 to D104 Values”...
Page 413: Setting Examples
9 Graph Display 9.5.2 Setting Examples Displaying a Bar Graph of the Ratio of D100 to D104 Values The following example shows how to display the ratio between the values of five device memory addresses on a bar graph. D104 3500 D100 D103...
Page 414 Statistic Bar Graph Displaying a Numerical Data Display of the Ratio of D100 to D104 Values The following example shows how to display the ratio between the device memory addresses displayed on the statistic bar graph on a numerical data display. D104 Ratio display D103...
Page 415 9 Graph Display 3. The settings window for the numerical data display is displayed. Select [Statistic Graph % Display] for [Function] and specify a value for [Statistic Graph No.]. Click [Finish] to close the settings window of the numerical data display. 4.
Page 416: Detailed Settings
Statistic Bar Graph 9.5.3 Detailed Settings Contents Item Description Top Data Device Set the top device memory address to display on the statistic graph. The required device memory are automatically allocated to the statistic graph. * The data format relies on the setting at [Code: DEC/BCD] under [Communication Setting] in the [PLC Properties] window accessible via [System Setting] →...
Page 417 9 Graph Display Detail Item Description Start X/Start Y Specify the placement coordinates. (Coordinates at top left of part) Coordinates Width/Height Specify the width and height of the part. Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 418: Statistic Pie Graph
Statistic Pie Graph Statistic Pie Graph 9.6.1 Overview • Percentages of data contained in consecutive device memory addresses can be expressed on a graph. One statistic pie graph can be divided into a maximum of eight sections. For setting examples, refer to “Displaying a Pie Graph of the Ratio of D100 to D103 Values”...
Page 419: Setting Examples
9 Graph Display 9.6.2 Setting Examples Displaying a Pie Graph of the Ratio of D100 to D103 Values The following example shows how to display the ratio between the values of four device memory addresses on a pie graph. D103 2500 D100 D100...
Page 420 Statistic Pie Graph Displaying a Numerical Data Display of the Ratio of D100 to D103 Values The following example shows how to display the ratio between the device memory addresses displayed on the statistic pie graph on a numerical data display. D103 Ratio display D100...
Page 421 9 Graph Display 3. The settings window for the numerical data display is displayed. Select [Statistic Graph % Display] for [Function] and specify a value for [Statistic Graph No.]. Click [Finish] to close the settings window of the numerical data display. 4.
Page 422 Statistic Pie Graph 9.6.3 Detailed Settings Contents Item Description Top Data Device Set the top device memory address to display on the statistic graph. The required device memory are automatically allocated to the statistic graph. * The data format relies on the setting at [Code: DEC/BCD] under [Communication Setting] in the [PLC Properties] window accessible via [System Setting] →...
Page 423 9 Graph Display Detail Item Description Start X/Start Y Specify the placement coordinates. (Coordinates at top left of part) Coordinates Width/Height Specify the width and height of the part. Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 424: Calendar
10 Calendar 10.1 Overview 10.2 Time Display 10.3 Calendar 10.4 Calendar Data Correction...
Page 426: Overview
10.1 Overview 10.1 Overview • The calendar part is used to show the year, month, day, hour, minute, second, and day of the week on the screen. 2021/4/21 10:15:20 • Range of calendar display Model Display Range When Power is Turned On First Time after Purchase TS2060 2016/4/1, 9:00:00 2006/1/1 to 2105/12/31...
Page 427 10 Calendar SRAM/Clock Setting Always set this option when using the built-in calendar in the TS unit. • Select [System Setting] → [Unit Setting] → [SRAM/Clock] and select the [Use SRAM Calendar] checkbox. • Always install a backup battery. For details on batteries, refer to the TS2060 Hardware Specifications or the TS1000 Smart Hardware Specifications. In the case of PLC2 to PLC8, calendar correction is performed by the execution of macro commands “PLC_CLND”...
Page 428: Time Display
10.2 Time Display 10.2 Time Display 10.2.1 Overview • Displays the PLC clock. 2016/ 4/21 10:15:20 2016/ 4/21 10:15:20 For setting examples, refer to “Displaying the PLC Calendar” page 10-4. • Displays the TS unit clock. Built-in TS calendar 2016/ 4/21 10:15:20 Show 2016/ 4/21 10:15:20...
Page 429: Setting Examples
10 Calendar 10.2.2 Setting Examples Displaying the PLC Calendar Display the PLC’s built-in calendar on the TS unit. 2016/ 4/21 10:15:20 2016/ 4/21 10:15:20 1. Click [System Setting] → [Hardware Setting] → [Read/Write Area]. 2. Set the PLC to use at [PLC Selection] under [Calendar Setting]. 10-4...
Page 430 10.2 Time Display 3. Click [System Setting] → [Unit Setting] → [SRAM/Clock] and deselect the [Use SRAM Calendar] checkbox. 4. Click [Parts] → [Time Display] → [Time Display] and place a time display part. 5. Double-click on the time display part to display the settings window. Configure the [Contents] settings as shown below.
Page 431: Displaying The Built-In Ts Calendar
10 Calendar Displaying the Built-in TS Calendar The following example shows how to display the built-in TS calendar. Built-in TS calendar 2016/ 4/21 10:15:20 Show 2016/ 4/21 10:15:20 1. Click [System Setting] → [Unit Setting] → [SRAM/Clock] and select the [Use SRAM Calendar] checkbox. 2.
Page 432 10.2 Time Display 3. Double-click on the time display part to display the settings window. Configure the [Contents] settings as shown below. • Select [Type] → [Display the system calendar]. • Specify the format of the date and time under [Display Format]. This completes the necessary settings.
Page 433: Display Using The Time Display Format Setting
10 Calendar Display Using the Time Display Format Setting D100 D101 2016/ 4/21 10:15:20 D102 D103 D104 D105 1. Click [Parts] → [Time Display] → [Time Display] and place a time display part. 2. Double-click on the time display part to display the settings window. Configure the [Contents] settings as shown below.
Page 434 10.2 Time Display 3. Specify the format of the data to read with [Time Display Format Setting]. Example 1: Read Word Count: 6 Data Unit: Word Code Type: BCD 0000: Year 0001: Month 0002: Day 0003: Hour 0004: Minute 0005: Sec D100 D101 2016/ 4/21 10:15:20...
Page 435: Displaying Seconds Data Stored In Device Memory In Timer Format
10 Calendar Displaying Seconds Data Stored in Device Memory in Timer Format The following example shows how to display the seconds data stored in device memory in timer format on a TS unit. 1:20:50 4250 1. Click [Parts] → [Time Display] → [Time Display] and place a time display part. 2.
Page 436: Detailed Settings
10.2 Time Display 10.2.3 Detailed Settings Contents Item Description Use data from the PLC calendar, TS calendar, or calendar device memory. The Display the system calendar display format can be set freely and the character size enlarged or reduced easily. Type Display the value of the Use a user-formatted calendar.
Page 437: Calendar
10 Calendar Time display format setting Item Description Select this checkbox if [Data Display] → [Type] → [Display the value of the designated device] is Specify Format selected and [Display Mode] is set to [Time Display]. Read Word Count Data for the number of words to be read starting at [Device Designation] are read as the calendar (1 - 6) data.
Page 438 10.2 Time Display Character Properties Item Description Color Set the text color and area background color. Style Set the text style. Set the text size. Character Size This setting changes to point specification when using a Windows font, Gothic font, or stroke font. 1-byte / 2-byte Select one-byte or two-byte display.
Page 439: Detailed Settings
10 Calendar 10.3 Calendar 10.3.1 Detailed Settings Style Item Description Type Set the part design. Select from catalogs Color Area Setting Set the part color. Select from image files Load a bitmap file. Contents Item Description Set the items to display on the calendar. The year in Western calendar format and the hour (0 to 24) are displayed.
Page 440 10.3 Calendar Character Properties When [Batch edit date/time] is selected The character properties of the year, month, day, hour, minute, and second can be set at once. Item Description Color Set the text color and area background color. Style Set the text style. Set the text size.
Page 441 10 Calendar When [Edit Date/Time Individually] is selected The character properties of the year, month, day, hour, minute, and second can be set individually. Item Description Color Set the text color and area background color. Style Set the text style. Set the orientation of text.
Page 442 10.3 Calendar Detail Item Description Specify the placement coordinates. Start X/Start Y (Coordinates at top left of part) Coordinates Width/Height Specify the width and height of the part. Others Set the ID. Notes • Calendar parts consist of “hour, minute, and second” parts and “year, month, and day” parts as well as two-level displays. Additionally, there are parts for punctuation marks like “:”...
Page 443: Calendar Data Correction
10 Calendar 10.4 Calendar Data Correction Calendar data that no longer displays the actual time can be corrected. The setting method varies depending on the part selected. Check the table of correction fields on “Overview” page 10-1 and correct the data as needed. 10.4.1 Correcting in the Control Area PLC with Calendar Function 1.
Page 444: Correcting Using A Macro
10.4 Calendar Data Correction 10.4.2 Correcting Using a Macro The calendar data in PLC 1 can be corrected by executing the macro command “SYS (SET_CLND)”. 1. According to the macro format, set data for “year, month, day, hour, minute, and second” correctly at the relevant device memory.
Page 445 10 Calendar 10-20...
Page 446: Graphics
11 Graphics 11.1 Graphics...
Page 448: Overview
11.1 Graphics 11.1 Graphics 11.1.1 Overview A variety of pre-registered graphics can be displayed on the screen or changed based on bit activation and the graphic number. The graphic display method differs depending on the [Operation Select] setting. • Switch Switches can be used to display or change between graphics and text registered in the graphic library.
Page 449 11 Graphics • Device (Bit Designation) The graphics or text registered in the graphic library can be shown or hidden according to bit activation. There are two display types. - Type: 1-Graphic When the bit is set to ON, the corresponding graphic is shown, and when the bit is set to OFF, the graphic is hidden. When bit 1 of D200 is activated ...
Page 450: Detailed Settings
11.1 Graphics 11.1.2 Detailed Settings Operation Select: Switch Graphic Select Item Description Min. Graphic Set the graphic with the lowest number among those to be displayed on the screen. Max. Graphic Set the graphic with the highest number among those to be displayed on the screen. Initial Graphic Set the initial graphic to show when the screen is displayed.
Page 451 11 Graphics Display area The size of the display area must be changed to accommodate the graphic for display. The position of the “OFF” mark (offset mark) of the graphic library corresponds to the upper left corner of the display area part on the screen.
Page 452: Operation Select: Device (No. Designation)
11.1 Graphics Operation Select: Device (No. Designation) Graphic Select Item Description Device Designation Specify the device memory addresses used for specifying a graphic number. Consecutive device memory addresses are used when a parameter is specified. Device Memory Description Remarks Graphic No. n + 1 Parameter 1 Only with parameter specification.
Page 453 11 Graphics Example of using parameters The table below shows device memory assignment and contents when the following settings are configured. Graphics Graphics library Device Memory Description Remarks D300 Device Device memory for graphic number specification D301 Parameter 1 Device memory for Center X [Valid parameter No.] is set to “2”...
Page 454 11.1 Graphics Display area • When [Display Graphic] is set to [Display area] The offset position of the graphic library corresponds to the upper left corner of the display area part. Take this position into consideration when determining the size of the display area part. Refer to page 11-4.
Page 455: Operation Select: Device (Bit Designation)
11 Graphics Operation Select: Device (Bit Designation) Graphic Select Item Description No. of Bits to Monitor Set the total number of bits used for displaying graphics. 1 - 512 Device Designation Set the device memory used for displaying graphics. Consecutive bits are used for the number of monitored bits.
Page 456 11.1 Graphics Display example: [Device Designation]: D200, [Type]: 1-Graphic, [Start Graphic]: GNo. 1, No. 4, [No. of Bits to Monitor]: 20, [Valid parameter No.]: 4 D200 For graphic relay operation (16 relays) Total of 20 = [No. of Bits to Monitor] D201 For graphic relay operation (4 relays) D202...
Page 457 11 Graphics Style Item Description Display Graphic Select the area for displaying graphics. Display area/Base screen Adjust Position Displays the window for adjusting the placement position of each part. Part size can also be changed. Select from catalogs Set the part design from the catalog. Display area •...
Page 458 11.1 Graphics • Transparency Select the [Transparent] checkbox for the display area part to add transparency to the display area part properties. Select this checkbox to avoid a situation where graphics under the display area part are hidden. - Example with transparent setting •...
Page 459: Graphic Display Color
11 Graphics 11.1.3 Graphic Display Color Display Modes When graphics are displayed on the screen, there are two types of display modes. • XOR: Graphic colors are XORed with the colors of the base screen. • REP: Original graphic colors are shown. Whether XOR or REP is used for the display state is determined by the mode and parameter settings.
Page 460 11.1 Graphics XOR Display Transparency (Pattern Transparency) Because animation on a graphic display is always XORed, it is impossible to display the same colors on the screen as initially set for the background color (other than black). Additionally, because the XORed color is affected by the base color, when animation is performed on multiple background colors, the color changes whenever the background does.
Page 461: Pattern Editing
11 Graphics Pattern editing • Set the color not to show on the screen for the [Transparent Color Setting] in the [Pattern Edit] window. • Only one transparent color can be set per pattern. • For a pattern like the one below, the perimeter color (red) is set as the transparent color. Consequently, when this pattern is displayed on the screen, the red area becomes transparent and the background color is displayed.
Page 462: Graphic Library (Parameter Settings)
11.1 Graphics 11.1.4 Graphic Library (Parameter Settings) Configure parameter settings to move, transform, and change graphics registered at [Home] → [Registration Item] → [Graphic Library]. Parameter Targets and Settings The following drawing items can be set using parameters. Graphics Item Specified by Parameter Refer to Straight line Start point, end point...
Page 463 11 Graphics Pattern • Start point The start point is the top left corner of the pattern, as shown below. Parameter No. 1 Parameter No. 2 • Pattern No. Set the parameters for the numbers to change the picture by specifying a number. Pattern Pattern No.
Page 464 11.1 Graphics Parameter Settings Set parameters in the graphic editing window of each graphic. Item Description Operation Select whether to overwrite the previous state or erase the previous state before drawing anew. Replace Overwrite the previous state. The previous state will remain. Animation Always draw the latest state.
Page 465 11 Graphics Item Description Incremental + Specify the input parameter value using relative coordinates in the positive direction. Input When specifying coordinates The following shows how the graphic moves in the positive direction when a positive value is specified to the device memory and in the negative direction when a negative value is specified to the device memory where the placement position of the graphic is [0, 0].
Page 466: Message
12 Message 12.1 Message Mode 12.2 Displaying Comments...
Page 468: Message Mode
12.1 Message Mode 12.1 Message Mode 12.1.1 Overview This function displays messages on the screen by specifying the line number of a message previously registered in the message registration area (message editing) or by grouping these messages into blocks and specifying the block number(s). The message mode has four kinds of display configurations as shown below.
Page 469 12 Message How to Specify Block Numbers If [Operation Select] is set to [Page Block] or [Direct Block] in the message mode, specify the [Page Block] or [Direct Block] number to which the message to display is registered. A [Operation Select]: Page block Register the message that was previously registered in the message editing area as [Page Block].
Page 470 12.1 Message Mode How to Specify Message Numbers If [Operation Select] is set to [Page Message] or [Direct Message] in the message mode, always specify the number of the message to display. C [Operation Select]: Page message Specify the line number of the top message to display. Several lines of the message, of the number specified, are continuously displayed within the display area on the screen.
Page 471: Setting Examples
12 Message 12.1.2 Setting Examples Displaying Messages (Page Blocks) Register a message to a page block and display the message by changing the block number using a switch. Message group No. 3 Page block No. 0 Control panel side emergency stop No.
Page 472 12.1 Message Mode 3. Click [Contents] and configure the settings as shown below. Click [Edit] to register a message for display. 4. Click [Edit] in the [Page Block Edit] window to display the [Message Edit] window. 5. Register the following message and then close the [Message Edit] window. 12-5...
Page 473 12 Message 6. Register the message registered in the [Message Edit] window to page block number 0 as shown below. 7. In the same manner, register the message again to page block number 1 as shown below and click [Registration Complete].
Page 474: Detailed Settings
12.1 Message Mode 12.1.3 Detailed Settings Operation Select Item Description Message Editing Method Select the display method for message mode. Page Block Page blocks are displayed on the screen. There are two methods for changing the display: switches and device memory addresses Direct Block Direct blocks are displayed on the screen.
Page 475 12 Message Displayed information [Operation Select]: Page block/direct block Item Description Display Switching Method Select how to call up blocks. Switch: Change the block number to display using a switch placed on the screen. Device: Directly specify the block number using [Block No. Setting Device] (described later) to display the corresponding block.
Page 476 12.1 Message Mode Char. Prop. Item Description Color Set the message color. Background Set the background color. Style Set the message style. Character Size Set the character enlargement factor value of the message. (when using bitmap fonts) (1 - 8) When [Switch] or [Lamp] is selected for [Others] →...
Page 477 12 Message Style Item Description Adjust Position Adjust the position and size of parts. Select from catalogs Select the part design. Additional Parts List Add and delete switch parts used in message mode. Each switch is used for page blocks or direct blocks. + Block Changes to the next message block.
Page 478 12.1 Message Mode Editing parts Select a part in the preview pane to change the part’s style settings. Item Description Parts Design Area Setting Select from catalogs Select the part design. After selecting the part, select the part color. Select an image file Select a bitmap file.
Page 479 12 Message Checking the display area size Whether messages are displayed as intended in display areas can be checked on the screen. With messages registered, click [View] → [Display Environment] → [Display] tab and select the [Display Message] checkbox. The registered messages are displayed on the screen. To adjust the size and other settings, perform adjustments via the [Adjust Position] button described in “Style”...
Page 480 12.1 Message Mode Show/Hide Item Description Show Display the message mode part on the screen. Hide Do not display the message mode part on the screen. Show/hide according to the Bit device Show the part if the specified bit device memory is ON and hide the part if it is condition OFF.
Page 481 12 Message Detail Item Description Coordinates Start X/Start Y Set the display position of the message mode part using X and Y coordinates. Width/Height Set the size of the message mode part by specifying width and height. Others Action Area Set the position to display the message on the screen.
Page 482: Registering Messages
12.1 Message Mode 12.1.4 Registering Messages There are two ways of registering messages. • [Message] settings window → [Contents] → [Edit] * When [Operation Select] is set to [Page Block] or [Direct Block], the [Message Edit] window cannot be displayed using this method.
Page 483: Registering
12 Message 12.1.5 Registering Page Blocks There are two ways of registering page blocks. • [Message] settings window → [Contents] → [Edit] • [Home] → [Registration Item] → [Page Block] → (specify block number) 12-16...
Page 484: Registering Direct Blocks
12.1 Message Mode 12.1.6 Registering Direct Blocks There are two ways of registering direct blocks. • [Message] settings window → [Contents] → [Edit] • [Home] → [Registration Item] → [Direct Block] → (specify block number) 12-17...
Page 485: Displaying Comments
12 Message 12.2 Displaying Comments 12.2.1 Overview Register comments in advance and display them using bit designation or number designation. A maximum of 32,767 comments can be registered. Character properties, such as color or size, can be set for each comment. One comment can include multiple lines.
Page 486 12.2 Displaying Comments Number Designation Set the comment number to the assigned device memory address and display the comment. For setting examples, refer to “Displaying Comments (Number Designation)” page 12-20. Comment editing Error 1 No.1 Error 2 No.2 Error 3 No.3 Solution: Perform XX.
Page 487: Setting Examples
12 Message 12.2.2 Setting Examples Displaying Comments (Number Designation) Register the comment to display in advance and specify the comment number to D100. Comment editing Error 1 No.1 Error 2 No.2 Error 3 No.3 Solution: Perform XX. Error 4 No.4 When D100 = 0 Set “3”...
Page 488 12.2 Displaying Comments 3. Click [Home] → [Registration Item] → [Comment] → [OK] with group number 0. 4. Register a comment as shown below. Press the [Alt] and [Enter] keys together to enter a new line. 5. Select the comment line for setting character properties, right-click, and click [Char. Prop.]. Set the following character properties and then close the [Comment Edit] window.
Page 489: Detailed Settings
12 Message 12.2.3 Detailed Settings Operation Select Item Description Comment Designation Select the comment display method. Bit Designation Select this option to display the comment using bit activation. No. Designation Select this option to display the comment by specifying the comment number. Device Designation Specify the command device memory address to use for displaying comments on the screen.
Page 490 12.2 Displaying Comments Style Item Description Area Select from catalogs Select the part design. After selecting the part, select the part color. Select an image file Select a bitmap file. Show/Hide Item Description Show Display the message mode part on the screen. Hide Do not display the message mode part on the screen.
Page 491 12 Message 12-24...
Page 492 12.2 Displaying Comments Detail Item Description Coordinates Start X/Start Y Set the display position of the comment display using X and Y coordinates. Width/Height Set the size of the comment display by specifying width and height. Others Process Cycle Set the process cycle. For details, refer to “1.2 Process Cycle”.
Page 493: Registering Comments
12 Message 12.2.4 Registering Comments There are two ways of registering comments. • [Comment] settings window → [Contents] → [Edit] * When [No. Designation] is selected, the window for comment registration will not be displayed in this way. * The cursor is displayed at the start line of the group that includes the line number specified for [Top Line No.]. •...
Page 494 12.2 Displaying Comments 12-27...
Page 495 12 Message 12-28...
Page 496: Others
13 Others 13.1 Data Block Area 13.2 Memory Card 13.3 Memo Pad...
Page 498: Data Block Area
13.1 Data Block Area 13.1 Data Block Area 13.1.1 Overview When there are several entry targets to be displayed on the screen and they cannot be displayed at one time, data blocks can be used. Place a data block area on the screen and register the necessary entry targets in the “data block.” The block number can be switched to display many entry targets.
Page 499: Operation Select
13 Others Operation Select Settings differ depending on the [Display Switching Method] setting in the [Operation Select] settings. Display Switching Method: Switch Item Description Display Switching Method Select [Switch] to change over the displayed data block area using switches. Switching Range Min.
Page 500: Style
13.1 Data Block Area Style Item Description Additional Parts List Displays a list of data block area-related parts. Selected: Displayed on MONITOUCH. Unselected: Not displayed on MONITOUCH. Parts can be added to the list using the [Add Parts] button. + Block Brings up the next data block area within the range of the specified maximum and minimum data block numbers.
Page 501: Detail
13 Others Detail Item Description Device Setting Block No. Output Select this checkbox to specify the device memory address for writing the currently Device displayed block number. Input Cursor Movement Select this checkbox to use the input cursor movement control device memory. Control Device For details on using the input cursor movement control device memory, refer to “Item...
Page 502: Data Blocks
13.1 Data Block Area 13.1.3 Data Blocks Numerical data displays and character displays must be placed on a data block to be displayed in a data block area. They cannot be placed on the base screen or in the overlap library. Location of Settings Start data block configuration by clicking [Home] →...
Page 503: Memory Card
13 Others 13.2 Memory Card 13.2.1 Overview About the Memory Card Function • Internal SRAM or a storage device can be used as external storage media to read data whenever necessary and save PLC data. The memory card emulation area of internal SRAM or a storage device is divided into a maximum of 16 files.
Page 504: Procedures On Ts
13.2 Memory Card Memory Card Editor (Under Development) By using Hakko Electronics’ memory card editor (M-CARD SFT), data stored in internal SRAM or a storage device can be read on a computer, and data edited or input on the computer can be written to internal SRAM or a storage device. Memory card editor Computer Record 0...
Page 505: Setting Example: Memory Card Settings
13 Others 13.2.2 Setting Example: Memory Card Settings When the [Memory Card Setting] window is set as shown below, the memory card area is divided and PLC device memory is allocated as illustrated below. Item File No. 0 File No. 1 Type Data File Data File...
Page 506: Detailed Settings
13.2 Memory Card 13.2.3 Detailed Settings Click [Parts] → [Others] → [Memory Card] and place a memory card part. Memory Card Data Definition Item Description Memory Card Setting Displays the [System Setting] → [Other] → [Memory Card Setting] window. No. 0 to 15 Displays the [Memory Card Setting] configurations.
Page 507 13 Others *1 Control device memory details A. n (Mode operation designation) 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 Record lock Record name edit prohibited File lock Filename edit prohibited File selection Card number/name edit prohibited Quick selection Format prohibited...
Page 508 13.2 Memory Card Character Properties Item Description Color Set the text color and area background color. Style Set the text style. Text Size Set the text size. Style Item Description Additional Parts List Displays a list of memory card-related parts. Selected: Displayed on MONITOUCH.
Page 509: Display Area
13 Others Show/Hide Set the show and hide settings of memory card items. For details, refer to “14 Item Show/Hide Function”. Detail Item Description Coordinates Start X, Start Y Specify the coordinates of the display area. Width, Height Set the size of the display area. Others Process Cycle Set the process cycle.
Page 510: Memory Card Part Switches
13.2 Memory Card Memory Card Part Switches List of Switches Switch Function Details of Operation File Selection When filenames in the memory card are displayed, this switch starts flashing. Pressing a filename while this switch is flashing selects that file. Record Selection This switch is valid when a file is chosen.
Page 511: Data Display Parts For Memory Card Part
13 Others Data Display Parts for Memory Card Part List of Data Display Parts Set [Function] to [Memory Card]. Function Details of Operation Memory Card No. Display Displays the card number currently being used. Memory Card File No. Display Displays the file number currently being used or selected. Memory Card Record No.
Page 512: Memory Card Setting
13.2 Memory Card 13.2.4 Memory Card Setting When using the memory card function, configure settings for file divisions and definition in the [Memory Card Setting] window. The memory card emulation area is formatted according to the settings, and the memory card function is enabled. Click [System Setting] →...
Page 513: I/F Device Memory
13 Others I/F Device Memory Regardless of the memory card function configurations, the newest data is written into “n” (CFM_STAT) and “n + 1” (CFM_ERRNo). Other device memory addresses are valid only when a memory card part is placed on the currently displayed screen. •...
Page 514 13.2 Memory Card • F. n + 5 (CFM_TRFIN) Statuses of formatting and data transfer between the TS (= SRAM area or SD card) and the PLC are stored. The contents are shown below: 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 Formatting (2) Error (1) Transferring from TS →...
Page 515: Editing Numbers And Names
13 Others 13.2.5 Editing Numbers and Names When using the memory card function, card numbers and filenames can be edited on screen. To enable editing, an entry mode part must be set. Place the entry keys in the overlap library or on the base screen. * The entry keys can be placed in one location for one memory card part.
Page 516 13.2 Memory Card Notes on Overlap Library Editing Entry mode part Select [Memory Card] for [Entry Target]. * Select the [Show [Data Block], [Memory Card], [Recipe Item] and [Direct] under [Entry Target]] checkbox in the [Detail] settings in advance. Entry display part Set as shown below: For card number editing Numerical data display part...
Page 517: Placing Entry Keys On The Base Screen
13 Others Notes on Screen Configuration Memory card mode Choose the ID which is set as a multi-overlap from [Overlap ID 0], [Overlap ID 1], or [Overlap ID 2]. Entry keys can be placed only in one location for one memory card part. (It is not possible to use the entry keys on both the base screen and an overlap display area for a memory card part.) Memory Card Part Switches...
Page 518: Memo Pad
13.3 Memo Pad 13.3 Memo Pad 13.3.1 Overview • Message board function The message board function is available for leaving daily messages in a workshop, etc. This is particularly useful for exchanging messages among operators working in shifts. • Pen input Message entry is made simple by writing on the screen directly with a special pen.
Page 519: Usage Example
13 Others 13.3.2 Usage Example Suppose that the following screen is created. Straight Delete Delete 1 pixel 2 pixels line Area Light Blue Violet Green Yellow blue 1. When the screen is first opened, the following settings are set as default. Pen size: 1 pixel Pen color: White...
Page 520: Detailed Settings
13.3 Memo Pad 13.3.3 Detailed Settings Style Item Description Additional Parts Pen Size (1 dot) Add a [Pen Size (1 dot)] switch. List Selects the pen thickness. Pen Size (2 × 2 dots) Add a [Pen Size (2 × 2 dots)] switch. Selects the pen thickness.
Page 521 13 Others Detail Item Description SRAM/Clock Setting Configure the settings to save memo pad data to the SRAM area. For details, refer to “13.3.4 Memo Pad Data Storage” page 13-25. Coordinate Set the Start X/Start Y (top left coordinates). Set the ID. 13-24...
Page 522: Memo Pad Data Storage
13.3 Memo Pad 13.3.4 Memo Pad Data Storage Memo pad data can be saved to the internal RAM, SRAM, or a storage device. Data saved to RAM is cleared when the TS is turned off or when the Main Menu screen is displayed. To retain data even when the power is turned off, save data to SRAM or a storage device.
Page 523: System Memory
13 Others Timing for Saving Data The memo pad data is saved to the memo pad area at the following timing. • When switching pages using the [Function: + Block, − Block] switches • When changing the screen • When switching from RUN mode to the Main Menu screen (only for SRAM) If data cannot be saved due to insufficient memory, the memo pad display area flashes and the unit beeps.
Page 524: Item Show/Hide Function
14 Item Show/Hide Function...
Page 526: Overview
14.1 Overview 14.1 Overview • The switch or numerical data display parts registered on the screen can be shown or hidden according to its operating status. The “show/hide” attribute can be set using methods including device memory bit activation in the PLC, bit/word designation, or commands.
Page 527: Setting Examples
14 Item Show/Hide Function 14.2 Setting Examples 14.2.1 Displaying Items when the Corresponding Bit Turns ON Screen Creation 1. Place a numerical data display and character display on the screen. 2. Configure the [Bit device] settings via [Show/Hide]. Unit Operation 1.
Page 528: Displaying Items Using Device Memory Values
14.2 Setting Examples 14.2.2 Displaying Items Using Device Memory Values Screen Creation 1. Place a switch. 2. Configure the [Word Device] settings via [Show/Hide]. Unit Operation 1. When D100 is set to “1234” via the PLC, switch A on the left is shown. D100 = D100 = 1234 D200 =...
Page 529: Displaying Items Using The Level Of The Security Function
14 Item Show/Hide Function 14.2.3 Displaying Items Using the Level of the Security Function Screen Creation 1. Place a switch that initiates operation. 2. Set the level of [Security Level] to “2” via [Show/Hide]. Lamp (no security level (always displayed) * Always turn on the security function.
Page 530: Detailed Settings
14.3 Detailed Settings 14.3 Detailed Settings Show/Hide Configure the [Show/Hide] settings for each item. Item Description Show Always show the item on the screen. Hide Always hide the item on the screen. Show/hide according to the condition Items are shown or hidden depending on the specified condition. Bit device The item is shown or hidden according to the activation at the address specified in a bit device memory.
Page 531: Timing Of Drawing (Device Memory Designation)
14 Item Show/Hide Function 14.4 Timing of Drawing (Device Memory Designation) When [Bit device] or [Word Device] is selected, the item will be shown or hidden according to the settings in the [Screen Setting] window. The entire screen is redrawn according to the timing of hiding/showing items. Screen Setting Click [Screen Setting] →...
Page 532: Blinking During Screen Redrawing
14.4 Timing of Drawing (Device Memory Designation) Blinking during Screen Redrawing When the screen is being redrawn, blinking may occur. To prevent such blinking, click [System Setting] → [Unit Setting] → [General Settings], and select [Perform Drawing in the Background]. 14-7...
Page 533: Checking Settings
14 Item Show/Hide Function 14.5 Checking Settings Use the following method to check the [Show/Hide] settings of items. Item List Display the [Item List] window from the [View] menu. Items with [Show/Hide] settings are shown in green, yellow or light blue. Uncolored items correspond to items for which [Show] is selected.
Page 534: Recipes
15 Recipes...
Page 536 15.1 Overview 15.1 Overview 15.1.1 Recipes In manufacturing, the conditions and data that are critical for making products are collectively referred to as a “recipe”. For example, when beverages are produced on the factory floor of a beverage manufacturer, the conditions for producing apple juice and orange juice differ with respect to ingredients and production processes for each type of beverage.
Page 537: Recipe Function
15 Recipes 15.1.2 Recipe Function Precise and easy management of recipes, as described in the previous section, on the factory floor is a requirement. Recipes comprise different information depending on product type and may undergo modification on the factory floor. Recipe data can be managed without stress by managers on the factory floor if data on a PLC can be substituted or changed according to circumstance.
Page 538: Setting Example
15.2 Setting Example 15.2 Setting Example This section explains the procedure for creating recipe files as follows and displaying them on the TS unit. Recipes DAT0000 RECIPE NORMAL TARGET PRODUCT1.CSV PRODUCT2.CSV PRODUCT3.CSV PRODUCT1.CSV PRODUCT4.CSV PRODUCT5.CSV D100 APPLE PRODUCT6.CSV D101 ORANGE D102 TEST GRAPE...
Page 539 15 Recipes 4. Click [Add] for [Group Folder Name to Store CSV File for Above-listed Data] and register the “TARGET” folder for saving CSV files. 5. Specify “D100” for [Transfer Device] under [Device Settings] in the [Detail] settings. 6. Click the [Finish] button to exit settings. Creating CSV Files 1.
Page 540 15.2 Setting Example MONITOUCH Operation 1. Insert an SD card into the SD card slot on the TS unit and display the screen with a recipe part. The folders and files in the “RECIPE” folder are displayed. 2. Tap “TARGET”. The files in the “TARGET” folder are displayed in a list. 3.
Page 541: Detailed Settings
15 Recipes 15.3 Detailed Settings 15.3.1 Recipe Part Contents Operation Area: Display Area Item Description Operation Area Display Area Display folder names, filenames, record names, and data on a display area part. Display the title and recipe data Set data to be displayed in the display area. Selected The folder name, filename, record name, title, and recipe data are displayed.
Page 542 15.3 Detailed Settings Item Description Display Order Display in ascending order Select the sort order for displaying the names of recipe folders and CSV files. Descending order Ascending Descending REC0002 AAA\ order order GROUP\ REC0001 TEST\ REC0000 Recipe folders are displayed at the top in ascending order, TEST\ REC0000...
Page 543 15 Recipes Operation Area: Switch Item Description Operation Area Switch Display folder names and filenames on switches. Data Display Number of Lines to Display Specify the number of switches to use. (1 to 24) Display Order Display in ascending order Select the sort order for displaying the names of recipe folders and CSV files.
Page 544 15.3 Detailed Settings CSV File Data Format The CSV file is a text file delimited with commas. Therefore, it can be edited using various software. However, since the text file does not contain any information about the numerical values, text, and DEC/HEX notation within the file, the TS unit cannot tell what each data is for when reading or writing data.
Page 545 15 Recipes Style Item Description Additional Parts List Displays a list of recipe-related parts. Selected: Displayed on MONITOUCH. Unselected: Not displayed on MONITOUCH. Parts can be added to the list using the [Add Parts] button. Transfer Card → PLC This switch is available when a record or a file has been chosen. This switch transfers the selected record or file data from the storage device to the specified [Transfer Device].
Page 546 15.3 Detailed Settings Item Description Additional Parts The specified [File Name] or the string stored in the address specified for [Device Designation] File Select List is automatically displayed on this switch. When the switch is pressed, the file indicated on the switch is selected and its contents are displayed on the screen.
Page 547 15 Recipes Item Description This switch is available when [Operation Area: Switch] is selected. Recipe Display Folder names, CSV filenames, and record names in the storage device are displayed on Display Order (0 to switches instead of display areas. When this switch is pressed, the folder, file, or record indicated on the switch is selected.
Page 548 15.3 Detailed Settings Detail Item Description Device Settings Command Device Specify the device memory for controlling the recipe part. Eleven words are occupied consecutively. For details, refer to “15.3.2 Command Device” page 15-14. Transfer Device Specify the device memory address for storing data to be transferred, or the destination address.
Page 549: Command Device
15 Recipes 15.3.2 Command Device This device memory is for controlling the recipe part. 11 words are occupied consecutively. Address Description For control (1) Record name edit (13) Not used (13) Not used (2) Filename edit (3) Title name edit (4) Recipe data edit (5) Data transfer (6) Folder lock...
Page 550 15.3 Detailed Settings Address Description Quick transfer When bit 14 or bit 15 is set to “1” with this bit ON, data is transferred on completion of record selection in MONITOUCH. (10) Transfer mode [0]: By record basis When records exist, a record is transferred. [1]: Entire CSV file The entire data of a file is transferred.
Page 551: Information Output Device
15 Recipes 15.3.3 Information Output Device This is the memory address that outputs the recipe function status. 29 words are occupied consecutively. Address Description Storage device status (1) Storage device error (2) Not used (always “0”) 0: Normal 1: Error n + 1 Error number When bit 0 of “n”...
Page 552: Attributes
15.4 Attributes 15.4 Attributes 15.4.1 Overview of Attributes The CSV file is a text file delimited with commas. Therefore, it can be edited using various software. However, since the text file does not contain any information about the numerical values, text, and DEC/HEX notation within the file, the TS unit cannot tell what each data is for when reading or writing data.
Page 553 15 Recipes Attribute Setting Item Description Determine the usage of the first line in the CSV file. Use Title • Unselected The first line in the CSV file is treated as “data.” CSV file Display on the screen 6000 6000 6100 6100 6200...
Page 554 15.4 Attributes Item Description Text Process Set the order of the first and second bytes within one word. LSB → MSB MSB → LSB 2nd byte 1st byte 1st byte 2nd byte No. of Bytes for Record This option is available when [Transfer Mode: Record Name + Data] is selected. (0 to 32) Set the number of bytes used for a record name.
Page 555 15 Recipes Creating Group Folders When naming CSV files , create a group folder for storing the CSV files. Use the same attribute setting for all the CSV files in the same group folder. Group folder names and CSV filenames must be within 8 one-byte numerals or uppercase alphabetic characters. Group folders Procedure 1.
Page 556: Default Setting
15.4 Attributes Default Setting One of the attribute icons has a red check mark on it. The marked attribute number is the “default setting.” The default setting is used in the following cases: • There is no attribute setting corresponding to the file “RECxxxx.csv”. Attributes Storage device MEMO...
Page 557: Csv File
15 Recipes 15.4.3 CSV File Filenames and Storage Destinations Depending on the CSV filename, the storage destination as well as file designation method varies. Create files according to their purpose. Filename Storage destination RECxxxx.CSV Access folder\RECIPE\ Refer to the chart below. 0000 ~ 9999 xxxxxxxx.CSV Access folder\RECIPE\ (group folder) \...
Page 558 15.4 Attributes Data in CSV Files Number of Transferable Words A maximum of 4096 words can be read and written at one time by the recipe function or when using a macro command. If you attempt to transfer data that exceeds this capacity, only the first 4096 words will be transferred and no more. Lines and Columns Depending on the attribute setting, the available numbers of columns and lines vary.
Page 559: Monitouch Operation
15 Recipes 15.4.4 MONITOUCH Operation Selection Folders and files can be selected by tapping the operation area. It is also possible to select a folder, file, or record by designating its name or number from the [Command Device]. Folder Selection If you double-tap a group folder name, the CSV filenames in the folder are displayed.
Page 560: Record Selection
15.4 Attributes Record Selection Tap a record to select it. • Display area TARGET PRODUCT1 TARGET PRODUCT1 PRO4 . . \ TEMP . . \ TEMP Edit Edit PRO1 PRO1 PRO2 PRO2 PRO3 PRO3 Change Change PRO4 PRO4 SD PLC SD PLC PRO5 PRO5...
Page 561: Record Transfer
15 Recipes Transfer Data can be transferred using a switch on the screen. It is also possible to designate a file or record using the [Command Device] and transfer data. Record Transfer Tap a transfer switch ([Card → PLC] or [PLC → Card]) with a record selected to transfer that record (1 line). •...
Page 562 15.4 Attributes Editing Names (Files, Records, Titles) Tap a filename, record name or title name (if set) with the [Edit] switch in the ON state to display a keyboard for editing. These names can be edited directly in the same way as data edit. Note that only characters can be input. TARGET PRODUCT1 PRO3...
Page 563 15 Recipes 15-28...
Page 564: Print
16 Print 16.1 Overview 16.2 Hard copy 16.3 Printing Data Sheets 16.4 Connecting to a Sato MR-400 Barcode Printer...
Page 566: Overview
16.1 Overview 16.1 Overview When the TS is operating in RUN mode, the displayed screen and the internal buffer information can be printed from a connected printer. • Hard copy Print the displayed screen. Copy copy PictBridge Copy For details, refer to “16.2 Hard Copy”...
Page 567: Compatible Printers
16 Print 16.1.1 Compatible Printers The following printers can be connected to the TS. TS2060 TS1000S Editor Setting Supported Models Connection Port Connection Port PictBridge PictBridge-compatible printer USB-B USB-B EPSON EPSON color inkjet printer STYLUS PHOTO STYLUS PHOTO EPSON EPSON color inkjet printer STYLUS C86 STYLUS C86 EPSON...
Page 568: Epson Stylus Photo, Stylus C86, And Stylus C65
16.1 Overview 16.1.2 EPSON STYLUS PHOTO, STYLUS C86, and STYLUS C65 MONITOUCH can be connected to EPSON printers that support Microsoft Windows (STYLUS PHOTO, STYLUS C86, and STYLUS C65). For information on connectable models, visit our website at www.monitouch.com. Connection Method USB-A connection •...
Page 569: Hardware Settings
16 Print Hardware Settings Configure settings at [System Setting] → [Hardware Setting] → [Printer]. Printer Model Item Description Model Select the printer to connect. EPSON STYLUS PHOTO, EPSON STYLUS C86, EPSON STYLUS C65 Target Port No. Select the port where the printer cable is to be connected. USB-A: Connect a printer using a commercially available USB cable.
Page 570: Printer Properties
16.1 Overview Printer Properties Item Description Always Output Status Bit When the TS receives a print command, “0 → 1” is output at the start of data (Yes/None) transmission and “1 → 0” is output at the end of transmission. However, if the print data is minimal, the signal may not be output.
Page 571: Pictbridge Printers
16 Print 16.1.3 PictBridge Printers A PictBridge-compatible printer can be connected. For information on compatible models, visit our website (www.monitouch.com). Connection USB-B port connection Connect the USB-B port of the TS unit to the USB-A port of the printer with a commercially available USB cable. Printer USB cable USB-miniB...
Page 572 16.1 Overview Printer properties Item Description Always Output Status Bit When the TS receives a print command, “0 → 1” is output at the start of data (Yes/None) transmission and “1 → 0” is output at the end of transmission. However, if the print data is minimal, the signal may not be output.
Page 573: Print Size
16 Print Print Size The print size varies depending on the item to be printed and the paper setting. Screen hard copy • The paper size is fixed to “A4”. • The print start position and print size cannot be changed. The actual margins, however, may differ from the one shown below depending on the printer used.
Page 574: Status Output
16.1 Overview Status Output The status of the connection between the TS unit and a PictBridge printer is output to the internal device memory $s1066. Value Description Cause and Remedy The PictBridge printer is not connected or it is in the normal state. Printing in process using the PictBridge printer.
Page 575: Pr201 And Esc-P Printers
16 Print 16.1.4 PR201 and ESC-P Printers The TS can connect to MS-DOS-compatible printers. • MS-DOS-compatible printer models in the PR201 series • MS-DOS-compatible printer models ESC/P24-J84, ESC/P-J84, and ESC/P Super For information on connectable models, visit our website at www.monitouch.com. Connection Method USB-A port connection •...
Page 576 16.1 Overview Hardware Settings Configure the [System Setting] → [Hardware Setting] → [Printer] settings. Printer model Item Description Model Select the control code of the target printer from the following options: • PR201 Monochrome • PR201 Color • ESC-P Monochrome •...
Page 577 16 Print Printer properties Item Description Always Output Status Bit The TS outputs [0 → 1] when starting to transfer data upon receiving a print command, (Yes/None) and outputs [1 → 0] upon finishing transfer. However, these signals may not be output if the print data is small.
Page 578: Cbm292/293 Printer
16.1 Overview 16.1.5 CBM292/293 Printer The TS can connect to CBM line thermal printers (Citizen). For information on connectable models, visit our website at www.monitouch.com. Connection Method USB-A port connection • Connect the USB-A port of the TS unit to the parallel port of the printer with a USB-parallel conversion cable (commercially available).
Page 579 16 Print Hardware Settings Configure the [System Setting] → [Hardware Setting] → [Printer] settings. Printer model Item Description Model Select CBM292/293. Select the port where the printer cable is connected. USB-A: Select this option when connecting to a parallel interface printer with a USB-parallel conversion cable Target Port No.
Page 580 16.1 Overview Printer properties Item Description Always Output Status Bit The TS outputs [0 → 1] when starting to transfer data upon receiving a print command, (Yes/None) and outputs [1 → 0] upon finishing transfer. However, these signals may not be output if the print data is small.
Page 581: Sato's Mr-400 Barcode Printer
16 Print 16.1.6 Sato’s MR-400 Barcode Printer The TS can connect to Sato’s barcode printer for printing barcodes. Read the instruction manual and command reference book for Sato’s MR-400 series barcode printer before using this function. • For details on configuration and printing, refer to “16.4 Connecting to a Sato MR-400 Barcode Printer”...
Page 582: Hard Copy
16.2 Hard Copy 16.2 Hard Copy 16.2.1 Overview The displayed screen can be printed using the switch function or a command from the PLC. Copy copy PictBridge Press a switch which is set with “Hard Copy” Copy for [Function]. Example: Read area “D0000” PictBridge D0001 Bit 10 of read area “n + 1”...
Page 583: Printing Procedure
16 Print Command from Read Area Bit 10 of [Read Area] “n + 1” is the screen hard copy bit. When this bit changes from “0” to “1”, a hard copy is printed. Printing procedure 1) Display the screen to be printed. 2) Set bit 10 of [Read Area] “n + 1”...
Page 584: Printing Data Sheets
16.3 Printing Data Sheets 16.3 Printing Data Sheets 16.3.1 Overview This section explains printing the data currently displayed on numerical data displays or character displays that are registered on a data sheet. This print function also enables real-time printing of device memory data that is not shown on the TS. Print Printer Setting the bit for “output data sheets”...
Page 585 16 Print Data sheet screen The print screen is formatted in “Data Sheet” in the TS screen program file. Items usable on data sheets vary depending on whether the expanded functions are used. • Without the expanded functions • With the expanded functions Line or box Statistic pie graph Line A...
Page 586: Detailed Settings
16.3 Printing Data Sheets 16.3.2 Detailed Settings Data Sheet Setting Configure settings from either [System Setting] → [Hardware Setting] → [Printer] → [Properties], or [Home] → [Registration Item] → [Data Sheet] → [Edit] → [Data Sheet Setting]. Use extension data sheet: unselected Item Description Print Data Sheet No.
Page 587 16 Print [Use Extension Data Sheet] Selected (PictBridge only) Item Description Print Data Sheet No. Setting Device Use this device memory when printing data sheets by read area commands (refer to page 16-23). Two words are used. Print start data sheet number (→ TS) Number of pages to be printed (→...
Page 588: Printing
16.3 Printing Data Sheets 16.3.3 Printing There are two methods for printing configured data sheets from the TS unit. Command from Read Area Bit 9 of [Read Area] “n + 1” is the data sheet output bit. When this bit changes from “0” to “1”, a data sheet is printed. Printing procedure 1) Set the data sheet number that is the top page to [Print Data Sheet No.
Page 589 16 Print Command with Macro Use the “STA_LIST” macro command to print data sheets. Device memory used Internal Device Memory PLC1 to PLC8 Device Memory Memory Card Constant : Setting enabled (indirect designation disabled) : Setting enabled (indirect designation enabled) Range Value Remarks...
Page 590: Connecting To A Sato Mr-400 Barcode Printer
16.4 Connecting to a Sato MR-400 Barcode Printer 16.4 Connecting to a Sato MR-400 Barcode Printer The TS can connect to Sato’s barcode printer for printing barcodes. Read the instruction manual and command reference book for Sato’s MR-400 series barcode printer before using this function.
Page 591 16 Print Printer properties Item Description Always Output Status Bit The TS outputs [0 → 1] when starting to transfer data upon receiving a print command, (Yes/None) and outputs [1 → 0] upon finishing transfer. However, these signals may not be output if the print data is small.
Page 592: Notes On Memory Cards
16.4 Connecting to a Sato MR-400 Barcode Printer 16.4.2 Notes on Memory Cards Memory Cards To use this function, a memory card is required for the MR400. For the memory card type and mounting procedure, refer to the instruction manual for the MR-400 series. Card Slot Number Setting and Memory Card Formatting To enable the use of memory cards, set the memory card slot number and format the memory card on the MR-400.
Page 593: Format Tables
16 Print 16.4.3 Format Tables Format Table Types There are two types of format tables. When the MR-400 commands are registered in this table, desired formats or data can be printed. MR-400 format table (registration setting) Set the print format. * The “format”...
Page 594 16.4 Connecting to a Sato MR-400 Barcode Printer Setting example To print in the following format: Field No. 1 Field No. 2 Field No. 3 1 2 3 4 5 1 2 3 4 5 6 • Description of escape sequence <A>...
Page 595 16 Print Notes on inputting <X22>, 12345 Escape sequence 1BX22, 12345 Escape sequence (HEX display) \1BX22, 12345 Format table The escape character (ESC) at the top of the escape sequence is expressed as “<>” on MR-400 and as “1B(H)” in hexadecimal notation.
Page 596 16.4 Connecting to a Sato MR-400 Barcode Printer Setting example (2) Printing data stored in a device memory in field No. 2 Select the [Device] checkbox of field No. 2. Press the [Detail] button to display the [Detail] window. • Select [Text] for [Type]. Item Description Device...
Page 597 16 Print • Select [Numerical Data] for [Type]. Item Description Device Print data in the specified device memory address in numerical form. * When [Numerical Data] is selected, binary data is converted into characters (JIS code). Example: When “0100 (BIN)” is set for D100, the characters 0100 (= “100”) are printed. Digits Specify the number of digits for the display type.
Page 598 16.4 Connecting to a Sato MR-400 Barcode Printer Barcode Type “CODE 39” CODE 39 has “*” at the beginning and the end of each barcode. When the format table is created, set “*” in the following two positions • [MR400 Format Table (Registration Setting)] settings Set the number of digits including “*”...
Page 599 16 Print • Select [Numerical Data] for [Type]. Item Description Add Start and End Codes Selected: “*” is not included in the data of [Device]. Unselected: “*” is included in the data of [Device]. 16-34...
Page 600: Printing
16.4 Connecting to a Sato MR-400 Barcode Printer 16.4.4 Printing There are two methods for printing from the TS unit with a Sato barcode printer connected. Macros The “MR_REG” macro command is available to write the setting data from format tables (registration setting or call setting) to the MR-400.
Page 601 16 Print MR400 Print Designation Device Printing can be executed using an external command. Item Description Control device memory 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 0: Standby 1: Printing * This is automatically reset when printing has been completed. Format table No.
Page 602: Barcode
17 Barcode...
Page 604: Overview
17.1 Overview 17.1 Overview The TS reads barcode data, converts the necessary data into ASCII code, and stores the result in the specified PLC device memory address. This allows various types of information to be transferred immediately using a barcode reader. Also, the TS can show the read barcode data on the screen.
Page 605: Setting Examples
17 Barcode 17.2 Setting Examples The following describes the procedure for reading “CODE 39” barcode data using a barcode reader and transferring the data as ACSII codes to PLC device memory D1001. I/F Device: D1000 D1001 4902580302474 Code No. : Barcode reader 4902580302474 The TS reads barcode data and transfers it to the PLC.
Page 606: Detailed Settings
17.3 Detailed Settings 17.3 Detailed Settings Location of settings: [System Setting] → [Hardware Setting] → “Barcode” Item Description Type Specify the type of barcode reader. JAN (UPC, EAN)/ITF (Interleaved 2 of 5)/CODABAR (NW-7)/CODE39/CODE128/ANY (2D barcode) Baud Rate Set the transmission speed.4800/9600/19200 BPS (serial connection) Data Length Set the number of bits for data.
Page 607 17 Barcode I/F Device I/F device memory allocation is shown below. Type: JAN/ITF/CODABAR/CODE39/CODE128 Device Memory Description Flag / amount of data read 1: Reading complete 0 to 256 bytes: Amount of data read 1: Communication error * All unused bits are reset to “0”. n + 1 - n + m Data read (ASCII) * “0”...
Page 608 17.3 Detailed Settings Read Bytes Setting The number bytes to be read depends on the setting for [Type] and [Read Bytes Setting]. Type Read Bytes Setting Number of Bytes Used None Variable for codes to be read, maximum of 254 bytes Fixed to the set number of words, 2 to 254 bytes CORDERBAR Selected...
Page 609 17 Barcode Storage Order Data is read in the following manner according to the [Storage Order] setting. Storage Order Description LSB → MSB Data is read in the order of LSB → MSB 2nd byte 1st byte MSB → LSB Data is read in the order of MSB →...
Page 610: Wiring
17.4 Wiring 17.4 Wiring 17.4.1 USB Connection Barcode readers connect to the USB-A port of the TS unit. Connect the barcode reader using the USB cable provided with the barcode reader. 17.4.2 Serial Connection Connector: CN1 (TS2060i + DUR-00) Name Name Dsub 9 (Male) * Use shielded twisted pair wiring...
Page 611: Notes
17 Barcode Connector: COM2 (TS1000 Smart) COM2 Name Name * Use shielded twisted pair wiring Dsub 9 (Female) 17.5 Notes • When connecting multiple USB devices to the TS, refer to the TS2060 Hardware Specifications or the TS1000 Smart Hardware Specifications for precautions when using a USB hub. 17-8...
Page 612 www.monitouch.com 890-1, Kamikashiwano-machi, Hakusan-shi, Ishikawa, 924-0035 Japan Tel +81-76-274-2144 E-mail support@hakko-elec.co.jp...

This manual is also suitable for:

Monitouch technoshot ts1000 smart Monitouch technoshot ts2060i Monitouch technoshot ts1100si Monitouch technoshot ts1070si Monitouch technoshot ts1070s
