- Page 1 User manual Control module NIBE SMO S40 UHB EN 2208-1 631965...
- Page 2 When there is new software to download, you can do it here (provided that SMO S40 is connected to myUplink). IN THE EVENT OF DISTURBANCES IN COMFORT If you experience a disturbance in comfort of any kind, there are various measures you can take yourself before contacting...
-
Page 3: Table Of Contents
The on/off button The display Navigation Menu types Menu system 4 myUplink Specification Connection Range of services 5 Maintenance of SMO S40 Regular checks Saving tips 6 Disturbances in comfort Info-menu Manage alarm Troubleshooting Add. heat only Contact information NIBE SMO S40... -
Page 4: Important Information
Own curve (curve slope) Accessories Serial number must always be given. Certification that the installation is carried out according to instructions in the accompanying installer manual and applicable regulations. Date ______________________________ Signed __________________________________________ Chapter 1 | Important information NIBE SMO S40... -
Page 5: Symbols
The serial number can be found on the left-hand side of the control module and on the "Product overview" home screen. Caution You need the product's (14 digit) serial number for servicing and support. NIBE SMO S40 Chapter 1 | Important information... -
Page 6: Control Module's Function
Up to eight NIBE heat pumps can be connected to a control system. With the control module’s smart and user-friendly techno-... -
Page 7: Control - Introduction
For hard switch off: press and hold the on/off button for 5 seconds. The status lamp To activate emergency mode when SMO S40 is switched off: press and hold the on/off button for 5 seconds. (Deac- The status lamp shows how well your system is operating. -
Page 8: Navigation
Navigation Your installer may have chosen other values that suit your system better. SMO S40 has a touchscreen where you simply navigate by pressing and dragging with your finger. SELECT Most options and functions are activated by lightly pressing on the display with your finger. - Page 9 Current temperature The drop-down menu shows the current status for SMO S40, Set temperature what is in operation and what SMO S40 is doing at the mo- Works to set temperature ment. The functions that are in operation are highlighted with a frame.
-
Page 10: Menu System
My system Menu 8 - USB This menu lights up when a USB memory is connected. You Connection can update the software here, for example. Chapter 3 | Control - Introduction NIBE SMO S40... -
Page 11: Myuplink
Installer Manual. Specification You need the following in order for myUplink to be able to communicate with your SMO S40: • wireless network or network cable •... -
Page 12: Maintenance Of Smo S40
This is done in menu 6 - "Scheduling". • If you select "Small" in menu 2.2 - "Hot water demand", less energy is used. Chapter 5 | Maintenance of SMO S40 NIBE SMO S40... -
Page 13: Disturbances In Comfort
• Large hot water consumption. that SMO S40 cannot remedy itself. On the display, you can see what type of alarm it is and reset it. – Wait until the hot water has heated up. Temporarily in- creased hot water capacity can be activated in the "Hot... -
Page 14: Add. Heat Only
Too low or no operating prioritisation of heat. – Contact your installer! EMERGENCY MODE You can activate the emergency mode both when SMO S40 • "Holiday" activated in menu 6 - "Scheduling". is running and when it is switched off. -
Page 15: Contact Information
Tel: +46 (0)433-27 3000 info@evan.ru info@nibe.se nibe-evan.ru nibe.se SWITZERLAND NIBE Wärmetechnik c/o ait Schweiz AG Industriepark, CH-6246 Altishofen Tel. +41 (0)58 252 21 00 info@nibe.ch nibe.ch For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information. - Page 16 WS release date: 2022-01-03 10:24 Publish date: 2022-03-16 14:49 This is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this publication.
