- Page 1 Operator’s Manual Safety, Assembly, Operating, and Maintenance Instructions Please Read and Save These Instructions For Safety, Read All Safety and Operation Beginning S/N: 175742 Instructions Prior to Operating Machine P/N 2000-40...
- Page 2 Foreword Thank you. . .for purchasing a Walker mower. Every effort has been made to provide you with the most reliable mower on the market, and we are sure you will be among our many satisfied custom ers. If for any reason this product does not perform to your expectations, please contact your local dealer.
-
Page 3: Table Of Contents
H24d Table of Contents General Information Operating Instructions Highlighted Information ........1 Control Identification, Location, and Function ........28 Glossary ...............1 Ignition Switch ............28 Identifying Number Locations ......1 Engine Throttle ............29 Engine Serial Number Location ......2 Body Latch ..............29 Servicing Of Engine and Drivetrain Compo- Forward Speed Control (FSC) ........29... - Page 4 Table of Contents H24d Maintenance Instructions Neutral-Park ............65 Straight Ground Tracking ........65 Maintenance Schedule Chart ......48 Blade Brake Action............65 Important Tips for Care of the PTO U-Joints ............65 Kohler Engine ............49 Safety Switch System ..........66 Fuel System ..............49 Forward Speed Control Friction Lock .......66 Starting/Stopping ............49...
-
Page 5: General Information
Walker Manufacturing recommends that any ser- material from the right side of the mower deck. vice requiring special training or tools be performed by an authorized Walker Mower dealer. There are ● STEERING LEVERS steer the tractor by several general practices to be aware of in the con trolling the two transaxles. -
Page 6: Engine Serial Number Location
If you have any diffi culty finding an authorized outlet or obtaining warranty service, please contact our Tractor Serial Number Location Service Depart ment for assistance: Walker Manufacturing Company 5925 E. Harmony Road Serial Number Fort Collins, CO 80528 1-970-221-5614 www.walker.com... -
Page 7: Specifications
Electric Radiator Cooling Fan with Reversible Self-Cleaning Action Coolant 50/50 Pre-Mix Antifreeze/Water Air Cleaner Remote Mounted Donaldson Radialseal (5") (Walker P/N 5090-8 Primary/5090-7 Safety Filter) ELECTRICAL SYSTEM Battery 12 Volt, 350 CCA (Interstate SP-40) Charging System Flywheel Alternator Charging Output... - Page 8 15 (103) Tailwheel 20 (137) DRIVE BELTS Engine PTO Walker P/N 2230 (Matched Set of 3) Ground Drive Walker P/N 2248-1 SEAT Full Spring Suspension with Dampening and Adjustments for Back Angle, Lumbar Support, and Operator Weight. Standard with Ad- justable/Retractable Armrests.
- Page 9 H24d Specifications DIMENSIONS (Tractor and Mower) Length in. (cm) Tractor Only 69 (175) Tractor Wheel Base 45 (115) Tractor with Tilted Deck 87.75 (223) (DR64-3) Tractor with 64" Rear Discharge 107.75 (274) Deck (DR64-3) Width in. (cm) Tractor Only (Outside Tire) 46.5 (118)
-
Page 10: Component Identification
Component Identification H24d COMPONENT IDENTIFICATION NOTE: Operator Controls are identified in the sec- tion Operating Instructions on page 28. Roll-Over Protection System (ROPS) Tilt-Up Latch Body Tilt-Up Latch Counterweight Springs and Protective Covers Deck Support Forward Speed Control (FSC) Friction... - Page 11 H24d Component Identification Fuel Gauge Utility Bed (Hinged for Dumping) Muffler Radiator Adjustable Footrest Radiator Fan Guard Tailpipe Left Hand Spread Axle Fuel Tank Fuel Pickup Coolant Drive Wheel (Tail Wheel) and Cap Line Recovery Tank Rear View and Left Side View...
- Page 12 Component Identification H24d LH Transmission Steering Lever RH Transmission Control Rod Spring / Dampeners Control Rod Parking Brake Safety Switch LH Transaxle RH Transaxle LH Transaxle Lockout Arm RH Transaxle Lockout Arm Parking Brake Lever PTO Clutch Lever Battery Clutch...
-
Page 13: Safety Instructions
When you see the Safety Alert Symbol ( safety. read, understand, and follow the instructions. Fail- The Walker Rider Lawnmower has been designed ure to comply with safety instructions may result in with many safety features to protect the operator personal injury. - Page 14 Safety Instructions H24d Do not wear loose fitting clothing that could e. Replace the machine fuel cap(s) and con- get caught in moving parts. Do not operate tainer cap securely and clean up any this machine while wearing shorts; always spilled fuel before starting the engine.
-
Page 15: Operating
H24d Safety Instructions OPERATING In case the transmission drive belt breaks during operation, and if the machine is on a slope, the machine will freewheel down the WARNING slope. To maintain control, immediately (1) Release the steering levers and simultane- Always keep the ROPS roll bar in the ●... - Page 16 Safety Instructions H24d 12. When moving forward, do not suddenly put 18. In case of a clogged or plugged mower the tractor in reverse by rapidly pulling on the deck: steering levers, especially when going down- a. Disengage the blade clutch (PTO), engage...
-
Page 17: Maintenance
H24d Safety Instructions 25. When equipped with a factory installed hitch or Never attempt to disconnect any safety devic- factory authorized hitch kit, do not exceed es or defeat the purpose of these safety de- recommended tow capacities. Do not tow vices. -
Page 18: Safety, Control, And Instruction Decals
Safety Instructions H24d SAFETY, CONTROL, AND INSTRUCTION DECALS Safety, Control, and Instruction Decals are installed on the machine; if any are missing, illegible, or damaged, a replacement should be ordered and installed before putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual. - Page 19 H24d Safety Instructions SAFETY, CONTROL, AND INSTRUCTION DECALS Safety, Control, and Instruction Decals are installed on the machine; if any are missing, illegible, or damaged, a replacement should be ordered and installed before putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
- Page 20 Safety Instructions H24d SAFETY, CONTROL, AND INSTRUCTION DECALS Safety, Control, and Instruction Decals are installed on the machine; if any are missing, illegible, or damaged, a replacement should be ordered and installed before putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
- Page 21 H24d Safety Instructions SAFETY, CONTROL, AND INSTRUCTION DECALS Safety, Control, and Instruction Decals are installed on the machine; if any are missing, illegible, or damaged, a replacement should be ordered and installed before putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
- Page 22 Safety Instructions H24d SAFETY, CONTROL, AND INSTRUCTION DECALS Safety, Control, and Instruction Decals are installed on the machine; if any are missing, illegible, or damaged, a replacement should be ordered and installed before putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
-
Page 23: Assembly Instructions
Charging Tips: SETUP INSTRUCTIONS Do not allow the battery cables to touch ● Walker Mowers are shipped partially assembled to opposing terminals. When connecting our distribution network, and are typically assem- battery cables attach the positive (+) bled by the selling dealer. For any additional... -
Page 24: Battery Charging
Assembly Instructions H24d Battery Charging Battery Clamp Secured by Wing Nut(s) DANGER BATTERIES PRODUCE EXPLOSIVE GASES Charge the battery in a well-ventilated ● area, so that gases produced while charg ing can dissipate. ● Keep sparks, flames, and smoking ma-... -
Page 25: Deck Discharge Deflector Shield Installation (Ds61)
H24d Assembly Instructions Deck Discharge Deflector Shield Installation PTO Shaft Guard Installation (DS61) Position the shaft guard as shown and mount with two (2) 1/4-20 x 1/2 in. bolts. Attach the side discharge deflector shield using two (2) 3/8-16 x 1-1/4 in. bolts, 3/8-16 ESNA nuts, and 3/8 in. - Page 26 Assembly Instructions H24d Unhook lower edge of rubber debris guard and raise for access to the tractor PTO shaft. Re- Deck Support Arms fer to Mower Deck Installation photo for location of debris guard. Coupler Align Installation Tool Arrows Rubber Debris...
-
Page 27: Deck Leveling
H24d Assembly Instructions IMPORTANT: To prevent damage to the mow- er, make sure the PTO quick disconnect is Counterweight Springs securely locked on the tractor, with the locking Clip Onto Body With balls fully seated in the groove and the ring in... -
Page 28: Deck Leveling Procedure
Assembly Instructions H24d Deck Leveling Procedure The side-to-side measurements should not vary by more than 1/8 in. (3 mm). If neces- Position the mower on a smooth, level sur- sary, raise or lower the left and/or right front face, and set the deck height to the most support chain clevises to level the deck. -
Page 29: Preoperating Checklist
H24d Assembly Instructions PREOPERATING CHECKLIST F CHECK ENGINE CRANKCASE OIL LEVEL Check the engine crankcase oil level before Before operating the mower for the first time, and use and after each 8 hours of continuous as a routine before daily operations, it is important operation. - Page 30 Assembly Instructions H24d F CHECK FUNCTIONS OF WARNING LIGHTS The tilt-up deck is secured in the raised posi- AND WARNING HORN tion using the following procedure: Turn the ignition key to the ON (RUN) position. Remove the tilt bar from the stowed position Glow Plug Activation Light, Low Engine Oil on the carrier frame.
- Page 31 H24d Assembly Instructions F CHECK MOWER BLADE CONDITION, DANGER SHARPNESS, AND SECURITY OF MOUNT- Do not operate the mower with deck in tilt- The blade mounting nuts on gear-driven decks up position. Do not move the tractor with should be torqued to 60 lb·ft (81 N·m), and the the deck in the tilt-up position.
-
Page 32: Operating Instructions
Operating Instructions H24d Operating Instructions Do not hold the key in the “S” position longer than 10 seconds. If the engine does not start, return the key to the “O” position for at least 60 seconds CONTROL IDENTIFICATION, LOCA- before making a restart attempt. Prolonged crank-... -
Page 33: Engine Throttle
H24d Operating Instructions Body Latch The front portion of the tractor body hinges forward for maintenance access and is latched down in the ON (RUN) OPERATING position. To raise the body, first tilt the utility bed back, then pull back and up on body latch and lift the body from behind the seat. -
Page 34: Fuel Pump Priming
Operating Instructions H24d Fuel Pump Priming The Kohler diesel engine is equipped with a mechanical fuel pump and in certain situations (running out of fuel, changing the fuel filter, or other fuel system maintenance) the fuel system may need to be primed by removing air trapped in the system. -
Page 35: Parking Brake
H24d Operating Instructions Parking Brake The parking brake functions by locking a detent arm to a cog in the hydraulic motor rotor. Moving the lever FOR WARD engages the parking brake; moving the lever BACKWARD releases the brake. IMPORTANT: Stop the tractor completely before engaging the parking brake. -
Page 36: Circuit Breakers
Operating Instructions H24d Circuit Breakers IMPORTANT: Continued operation of the engine with an illuminated oil pressure warning light MAY Two manual reset circuit breakers are located on cause severe engine damage (if a low oil pressure the front body. Each has a button that pops out if condition exists). -
Page 37: Transaxle Lockout Arms
** This reminder is only used one time. *** In normal operating conditions, oil changes in 100-hour intervals are acceptable. Walker and the engine manufacturers recommend engine oil changes every 50 hours in extremely dirty or dusty conditions or for units with less than 100 hours annual use. -
Page 38: Roll-Over Protection System (Rops)
Operating Instructions H24d Roll-Over Protection System (ROPS) To Lower the ROPS Roll Bar: Loosen the two (2) tension knobs. WARNING Remove the two (2) hitch pins. The ROPS may offer enhanced operator protection in the event of a roll-over type Remove the two (2) locking pins. -
Page 39: Suspension Seat
Suspension Seat CAUTION A fully adjustable suspension seat is standard on Model H24d. This seat is adjustable for back pitch, Before the tractor is used, the safety switch weight, lumbar support and armrest inclination. must be checked for proper function. The... - Page 40 Operating Instructions H24d For Backrest adjustment, moving the adjustment For adjusting the height of the armrest, pry out the handle upwards loosens the notching of the back- round cap (arrow) of the cover and loosen the rest adjustment. Refer to Figure 3.
- Page 41 H24d Operating Instructions The Forward Speed Control also Establishes the Neutral-Park Position of the Steering Levers FORWARD SPEED CONTROL LEVER (FSC) LEFT WHEEL RIGHT WHEEL STEERING LEVER STEERING LEVER Forward Position (No Control Change) Full Forward Ground Speed Position Neutral-Park...
-
Page 42: Starting The Engine
Failure to fol low these guidelines can damage derstand all Safety Instructions and Oper- the starter motor and shorten battery life. ating Instructions. Consult your Walker dealer or authorized Kohler dealer for additional help. TROUBLESHOOTING NOTE: If the engine WARNING... -
Page 43: Adjusting Ground Speed And Steering
H24d Operating Instructions ADJUSTING GROUND SPEED AND NOTE: If the FSC lever will not stay in the STEERING selected position, the friction lock needs to be adjusted. Refer to Adjustments for Transmis- sion Control Step 7 - Forward Speed Control CAUTION Friction Adjustment on page 77. - Page 44 Remember it is not necessary to hold the steering levers forward (a unique The FSC may be adjusted forward for faster Walker feature); always PULL on the levers for steering or for reverse mo- ground speed and backward for slower ground tion of the mower.
-
Page 45: Engaging The Blade Drive
H24d Operating Instructions ENGAGING THE BLADE DRIVE CAUTION Set the engine throttle at about 1/3 speed. Do not attempt to engage the blade clutch at An operator presence switch (seat switch) high engine speeds. This will drastically will cause the engine to stop if the blade shorten drive belt life. -
Page 46: Fuel Tank Selector Valve
(1) Release the steering levers and si- adjusted or repaired before further opera- multaneously (2) Move the FSC to the NEU- tion of the mower. Contact your Walker TRAL-PARK position. When the machine dealer, or refer to Clutch Disengagement/ is stopped or moving slowly, engage the parking brake. -
Page 47: Adjustable Foot Rests
H24d Operating Instructions ADJUSTABLE FOOT RESTS Cutting Height Some carrier frames are outfitted with adjustable Hitch Pin Release Lever foot rests. To adjust, rotate the footrests upward and slide to the desired position. Rotate the foot- rest down and insert the edge of the footrest into Deck Lift Pedal the nearest notch to lock in position. -
Page 48: Transaxle Lockout
Operating Instructions H24d TRANSAXLE LOCKOUT Transaxle Lockout Arm IMPORTANT: DO NOT TOW this mower faster than 2 mph (3.2 km/h) with the transaxle lockout engaged. Towing can produce excessive internal pressure and damage the transaxle(s). To move the mower with the engine NOT running (dead battery, maintenance, etc.), the transaxles... -
Page 49: Recommendations For Mowing
H24d Operating Instructions RECOMMENDATIONS FOR MOWING ● When mowing, operate the engine at full throttle for the best cutting action. Mowing with a lower engine RPM causes the mowing DANGER blade to not cut clean and tear the grass. The... - Page 50 Operating Instructions H24d Maximum Recommended Slope - Do Not Operate on Steep Slopes Discharge Shield Side Discharge Deflector 16 in. Shield in Lowest Position 15° ● When operating on a slope, reduce speed 60 in. and use caution to start, stop, and maneuver.
-
Page 51: Recommendations For Towing
H24d Operating Instructions RECOMMENDATIONS FOR TOWING When equipped with a factory installed hitch or factory authorized hitch kit, the maximum towing capacity on flat ground is 250 lbs (113 kg) gross trailer weight. The maximum tongue weight is 50 lbs (23 kg). Use caution when towing on slopes, rough terrain or when conditions limit traction. -
Page 52: Maintenance Instructions
Maintenance Instructions CAUTION Maintenance procedures requiring special training or MAINTENANCE SCHEDULE CHART tools should be performed by a trained technician. RECOMMENDED SERVICE INTERVALS - MODEL H24d Every Ref. Service Item Daily Hours Hours Hours Hours Yearly 2 Years Page Check Engine Crankcase Oil Level... -
Page 53: Important Tips For Care Of The Kohler Engine
H24d Maintenance Instructions Kohler Tips IMPORTANT TIPS FOR CARE OF THE ● Never mix different types/colors of coolants. KOHLER ENGINE Maintain proper fluid levels in the radiator ● and overflow tank. Fuel System Air Cleaner System ● Fuel must be clean—free from water, dirt, and ●... -
Page 54: Lubrication
Maintenance Instructions H24d Lubrication LUBRICATION IMPORTANT: DO NOT operate engine with- out a sufficient oil supply in the crankcase. DO NOT operate with the oil level below the WARNING LOW mark or above the FULL mark on the dipstick. DO NOT attempt to lubricate the machine with the engine running. - Page 55 H24d Maintenance Instructions Lubrication Before removing the dipstick, and oil fill cap, Install the new oil filter on the engine. Turn the clean the area around them to keep any dirt or filter clockwise until the rubber gasket con tacts debris out of the engine.
-
Page 56: Mower Deck Spindle Lubrication
Maintenance Instructions H24d Lubrication Mower Deck Spindle Lubrication Transaxle Oil and Filter Change For mower decks with belt-driven blades, lubricate Change the transaxle oil after the initial break-in each deck spindle grease fitting every 25 hours. period of 75-100 hours. Thereafter, change oil... -
Page 57: Grease Fitting And Oil Point Lubrication
H24d Maintenance Instructions Lubrication Grease Fitting and Oil Point Lubrication Screw Locking Elbow Lubricate the grease fittings and oil points after Nut Down every 25 hours of operation. Lubricate more often when operating in dusty or dirty condi- tions. Use SAE general purpose lithium or molyb- denum base grease for grease fittings and light machine oil (SAE 10) to lubricate oil points. - Page 58 Maintenance Instructions H24d Lubrication Ident Lubrication Ident Lubrication Location Type Places Location Type Places Deck Caster Wheel Fork Pivot Grease Engine Oil Fill Oil** Deck Caster Wheel Bearing Grease PTO Belt Tightener Pivot Grease Front Deck Lift Pivot Grease Clutch Actuator Push Rod...
- Page 59 H24d Maintenance Instructions Lubrication 17 & 28 Chassis and Deck Lubrication Points...
-
Page 60: Cleaning
IMPORTANT: Use only Donaldson air filter ele- ments for replacement (Donaldson P821575 or Walker 5090-8 Primary/Donaldson P822858 or 5090-7 Safety Filter). Aftermarket filters may not seal properly or filter efficiently. Donaldson... - Page 61 H24d Maintenance Instructions Cleaning Remove the filter element by pulling it out of the canister. There will be some initial resis- Cover Canister Dust Ejection tance as the filter seal breaks loose and slides Valve off of the outlet tube. Gently move the end of the filter up and down and side to side or twist to loosen the seal.
-
Page 62: Engine Cooling System
Maintenance Instructions H24d Cleaning After removing the safety filter, use a clean, Cover damp cloth and wipe the interior of the air Orient to Top Latch cleaner canister clean. Use special care to of Canister clean both the inside and outside surfaces of the outlet tube. -
Page 63: Flushing Radiator And Changing Coolant
H24d Maintenance Instructions Cleaning IMPORTANT: Maintain proper coolant level in Inspect the radiator cooling fins for material lodged in this area which would restrict cooling the radiator and coolant recovery tank. The cool- ant level should be maintained between FULL and airflow. - Page 64 Maintenance Instructions H24d Cleaning Hitch Pin Tilt-Up Hook and Latch Connected Tilt Bar Use Hitch Pin to Secure Tilt Bar. Tilt-Up Tilt-Up Tilt Bar Installed Latch Hook Remove footrest or, if equipped with adjust- able footrests, move the footrest to the full forward locking position.
-
Page 65: Transaxle Housing
Pay close attention to any oily dirt buildup on the transaxle housings. This may be the result of an oil leak. If an oil leak is noticed, contact your local Walker dealer. Cooling Fins Transaxle Housing and Cooling Fins... -
Page 66: Checking/Servicing
Maintenance Instructions H24d Checking and Servicing CHECKING/SERVICING IMPORTANT: The coolant solution of antifreeze and distilled water must be thoroughly pre-mixed before putting it in the engine (adding pure anti- DANGER freeze into the radiator may cause damage to the engine by causing overheating). -
Page 67: Cleaning The Terminals
H24d Maintenance Instructions Checking and Servicing Disconnect the battery terminals–negative (-) CAUTION first. Important Battery Service, Installation, and Charge the battery at 15 amps for 10 minutes. Charging Tips: DO NOT exceed 20 amps maximum recom- mended charging rate. Total charging time ●... - Page 68 Maintenance Instructions H24d Checking and Servicing DANGER Sharpen at Original Intersection 30° Angle Wear Area NEVER operate cutter blades with the deck in the raised position. 30° NOTE: PTO shaft must be disconnected Wing Tip before checking blades for straightness.
-
Page 69: Drive Belts
H24d Maintenance Instructions Checking and Servicing Drive Belts refer to Adjustments for Transmission Control Step 5 - Straight Tracking Adjustment on page 76. Raise the body and inspect the condition of the four (4) drive belts after every 25 hours of opera- Blade Brake Action tion–engine/PTO drive (3), ground drive (1). -
Page 70: Safety Switch System
With a proper amount of friction adjusted, the starting or operating, a safety interlock switch may FSC lever should move back with a slight be malfunctioning. Contact your Walker dealer for amount of resistance (friction). If the FSC troubleshooting and/or replacement. -
Page 71: Replacing/Repairing
H24d Maintenance Instructions Replacing and Repairing REPLACING/REPAIRING Drive Belts There are five (5) individual drive belts on the machine: DANGER ● Engine/PTO Belt (Matched Set of 3) To prevent accidental starting of the engine when replacing parts or repairing the ma- ●... -
Page 72: Engine/Pto Belt
Maintenance Instructions H24d Replacing and Repairing Engine/PTO Belt b. Remove two (2) wire lock pins and open Lower LH Belt Guard and PTO Belt Guard. To remove the engine/PTO belt: c. Roll the belt off the pulley(s) and remove a. Remove Upper LH Belt Guard and RH Belt the belt. -
Page 73: Ground Drive Belt
H24d Maintenance Instructions Replacing and Repairing Ground Drive Belt b. Slide belt off pulleys, then release the idler pulley. To remove the ground drive belt: a. Remove belt tension by raising the spring- loaded idler pulley with the deck tilt bar. -
Page 74: Deck Drive Belt
Maintenance Instructions H24d Replacing and Repairing Deck Drive Belt d. From a position on the LH side of the deck, grasp belt midsection and pull to compress To remove the deck drive belt: the belt tensioner springs and move the tensioning pulley inward. -
Page 75: Fuel Filter
H24d Maintenance Instructions Replacing and Repairing Fuel Filter Mower Blades Mower blades are removed and remounted as de scribed in Sharpen Mower Blades on page 63. During the course of sharpening and Fuel inspecting mower blades, if there are any of the... - Page 76 Reinstall the blades following procedure from Sharpen Mower Blades on page 63. If blades are re placed, always use Walker original equip- ment blades to ensure safety and optimum perfor- mance. The quality and performance of replace- ment blades offered by other manufacturers cannot be guar anteed, they could be dangerous.
-
Page 77: Adjustments
H24d Maintenance Instructions Adjustments ADJUSTMENTS Adjust the position of the RH lever by turning the stop bolt in the Speed Control Actuator in or out. Turning the stop bolt in will make the Transmission Control RH lever move back, and turning it out will IMPORTANT: The proper adjustment of the trans- make it move forward. -
Page 78: Neutral Function Adjustment
Maintenance Instructions H24d Adjustments Step 3 - Neutral Function Adjustment Securely block the tractor up so the drive tires are off the ground. With the Forward Speed Control (FSC) in NEU TRAL-PARK, the lever should be straight Adjust the tracking adjustment nuts at the front up. -
Page 79: Full Forward Speed Adjustment
H24d Maintenance Instructions Adjustments Step 4 - Full Forward Speed Adjustment WARNING Move the FSC to the full FORWARD speed position. The following adjustments are made with the engine running. Keep all body parts Raise the body. The maximum speed tracking... -
Page 80: Straight Tracking Adjustment
Maintenance Instructions H24d Adjustments Step 5 - Straight Tracking Adjustment Step 6 - FSC Neutral Switch Adjustment Sit in the seat, start the engine, set throttle at Place the FSC lever in the NEUTRAL-PARK full speed, and with the FSC in the NEUTRAL- position. -
Page 81: Forward Speed Control Friction Adjustment
H24d Maintenance Instructions Adjustments Check operation of the FSC Neutral Switch by placing the FSC lever in the full FORWARD position. While holding the ignition switch in the START position, slowly move the FSC FSC Friction lever back towards the NEUTRAL-PARK Adjustment Nut position until the starter motor engages. -
Page 82: Blade Clutch (Pto)
Maintenance Instructions H24d Adjustments Blade Clutch (PTO) Adjust the length of the clutch actuator link to achieve a clutch spring assembly bolt head clear- Clutch Engagement/Belt Tension ance of 1/4 in. to 5/16 in. (6 mm to 8 mm) with the clutch engaged. -
Page 83: Clutch Disengagement/Brake Action
H24d Maintenance Instructions Adjustments Use the following procedures to check and adjust clutch disengagement and brake action: Step 1 - Idler Pulley Maximum Travel Adjust- ment Loosen the brake band adjustment nut allowing clutch pivot stop arm and stop bolt to make contact (refer to Blade Brake Band Adjustment illustra- 6-1/4 in.*... -
Page 84: Blade Brake Band Adjustment
Maintenance Instructions H24d Adjustments Step 2 - Blade Brake Band Adjustment After the maximum pulley travel is set, adjust the working travel of the clutch idler pulley by adjusting the brake band nut and make the following adjust- ment as needed:... - Page 85 MAINTENANCE AND SERVICE RECORD SHEET DATE SERVICE ENGINE ITEM HOURS ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________...
- Page 86 MAINTENANCE AND SERVICE RECORD SHEET DATE SERVICE ENGINE ITEM HOURS ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________...
- Page 87 (2) years* after the date of sale to the original retail purchaser unless the product is used for rental purposes, in which case this warranty is limited to ninety (90) days. At Walker’s request, customer will make the defective part available for inspection by Walker and/or return the defective part to Walker, transportation charges prepaid.
- Page 88 WALKER MFG. CO. • 5925 E. HARMONY ROAD, FORT COLLINS, CO 80528 • (970) 221-5614 FORM NO. 052422 PRINTED IN USA www.walker.com ©2022 WALKER MFG. CO...
