Mounting Instructions
Overfill Alarm and Acknowledgment Switch Dimensions
Figure 1 shows the Overfill Alarm mounting dimensions and Figure 2 shows the Acknowledgment Switch
mounting dimensions.
6'' (152.4 mm)
0.313'' (8 mm) dia.
4 holes
Red Flashing Light
Hinge
side
10.3 ''
(261.9 mm)
Horn volume
adjustment screw
(1/16'' Hex Hd)
VEEDER-ROOT
6'' (152.4 mm)
8'' (203 mm)
4 ''
(101 mm)
1.6 ''
(40.6 mm)
2 ''
1/2 ''
(50.8 mm)
conduit
connector
Figure 1. Overfill Alarm Mounting Dimensions
