Setup and Test

Testing Overfill Alarm W/o Acknowledgment Switch

1. Reapply power. If the Overfill Alarm was wired properly, the alarm horn will sound immediately followed by the
red alarm light flashing.
2. Turn Off power to the console and to the Overfill Alarm. Remove the test jumper between the Output Relay
connections.

Testing Overfill Alarm With Acknowledgment Switch

1. Turn power Off to the console and the Overfill Alarm. Put a jumper between the two Overfill Alarm relay
connections in the console (see Figure 6).
2. Stand by the Acknowledgment Switch and have someone reapply power to the console and Overfill Alarm. If
the Overfill Alarm was wired properly, the alarm horn will sound immediately followed by the red alarm light
flashing.
3. Press the RESET button on the front of the Acknowledgment Switch. The alarm horn and red flashing light
should shut off. The ACKNOWLEDGED light on the front of the switch should be On. (Pressing the RESET
button shuts Off the alarms but does not clear the alarm. The cause of the alarm must be removed before the
ACKNOWLEDGED light will turn Off.)
4. Turn Off power to the console and to the Overfill Alarm. Remove the test jumper between the console's
Output Relay connections.
5. Reapply power to the console and to the Overfill Alarm. The ACKNOWLEDGED light should now be Off
because the cause of the alarm (in this case, the test jumper) has been removed.
Testing the Overfill Alarm with the Console
