Launch Creader Elite Quick Start Manual page 2

Components & Controls
Touch
Screen
Charging Port
Powering Up
The tool can receive power via either of the following ways:
Method 1: Via Diagnostic Cable
Connect the diagnostic cable of the tool
to the vehicle's DLC (Data Link
Connector) port.
*Note: The
DLC
is
usually
located
12

inches
from the
center
of
the
instrument

panel
(dash), under
or
around
the

driver's
side
for most
vehicles. See
diagram for possible DLC location.
Method 2: Via Data Cable
Connect one end of the included data cable to charging port of the tool,
and the other end to the PC.
Diagnostic Cable
Setting
Button
Home
Button
Return
Button
Memory Card Slot
(Reserved
for
future
use)
