Tap CHANNEL DETAILS at the bottom to
l
open the
lets you examine the addresses and devices
operating on the channel and perform a
deeper analysis.
Tap SPECTRUM at the bottom to open
l
Spectrum. This application provides a Wi-Fi
spectrum analyzer to provide data about
signal strength and noise.
Overlap Tab
Tap Overlap to view access point channel,
coverage, and overlap. This can help you spot
potential coverage issues. Each discovered AP is
shown as a colored trapezoid a graph based on
channel coverage (on the x-axis) and signal
strength in dBm (on the y-axis).
Channel Details screen. This screen
