netAlly EtherScope nXG Quick Start Manual

The EtherScope nXG is a rugged, hand-held tool for testing and analyzing copper, fiber, and Wi-Fi
networks. It features applications developed by NetAlly for network discovery, measurement, and
validation, which are available from the Android Home and Apps screens:
AutoTest – Verify your network layers 1
through 7 in seconds.
Capture – Record Wired or Wi-Fi frames
with filters.
Wi-Fi – Identify APs, SSIDs, clients, and
channels from your location.
Performance – Measure up to four
streams at 10G line rate.
Link-Live – Upload, manage, and
analyze results and data in the Cloud.
NetAlly App Store – Download third-party Android applications to use on your
EtherScope nXG.
NetAlly.com
EtherScope
Quick Start Guide
External
Antenna Port
USB Type-A
Port
RJ-45 Cable Test
and Management
Port
Touchscreen
USB Type-C
Power Button
and Power
and LED
Port
Micro SD
Card Slot
Microphone
®
RJ-45 Ethernet
Port with Link
and Activity LEDs
Volume
Buttons
Ping/TCP – Validate and monitor
responsiveness and connectivity.
Discovery – Identify and analyze all
devices on your network.
Path Analysis – Trace Layer 2 and 3
routes.
iPerf – Test Wired or Wi-Fi connections
to a NetAlly Test Accessory or server.
Cable Test – Determine length, status,
and wiremapping, and employ toning.
View the complete User Guide on the
Home screen of your EtherScope nXG.
nXG
1G/10G Fiber Port
Camera
and
Flash
Speaker
