5.3 Observation systerm operations

5.3.1
l
l
l
l
l
l
l
Magnification times
Diameter of filed-of-view

5.3.2 Operation

CCDimage trimming device
PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ

Basic parameters

Binocular eyepiece foucus：160mm。
Eyepiece：12.5×，wide-angle vision adjustment±5D。
Work distance：300mm。
Eye-distance adjustment range：50-75mm。
Mico focusing range：0-40mm。
Image collection raster ：f4.5-f32。
Eyepiece magnification times and field of view：
Input data
Digital CCD
Pic 5-26 Front of Observation systerm
0.4 0.6
3.4 5.1
75mm 50mm
36
www.fineprint.com.cn
Colposcope Digital Imaging System
1.0 1.6
8.5 13.6
30mm 19mm
Binocular eyepiece
Optical lens
Five-speed zoom focus knob
Filter knob
2.5
21.3
12mm
