Kernel KN-2200B Manual page 31

Colposcope Digital Imaging System
Standard atlas
Back browsing
Patient images
Forward browsing
Patient atlas diagnosis opinion
Standard atlas diagnosis opinion
Figure 5-11
The left area of the window is the standard atlas area, right one is the patient atlas
area.175 kinds of standard atlases had been provided in the standard atlas area and the
corresponding diagnosis opinions to make contras with the patient atlas and convienent to
doctor's clinical diagnosis. some clinical value patient atlas can be added to the standard
atlas base data for rich the clinical experiences.
Function introduce:
Click " "forward browsing the atlas images;click" "back browsing the altas
images.
input altasNo.in the "Index" for searching.
click this button,list up the standard altas list,as the Figure5-12
27
