Digital Camera

EX-Z6/EX-Z7
User's Guide
Thank you for purchasing this CASIO
product.
• Before using it, be sure to read the
precautions contained in this User's Guide.
• Keep the User's Guide in a safe place for
future reference.
• For the most up-to-date information about
this product, visit the official EXILIM
Website at http://www.exilim.com/.
All example procedures in this User's Guide
are based on the EX-Z7. The same
procedures also apply to the EX-Z6, unless
specifically noted otherwise.
K819PCM1DKX
E

Advertisement
