OTHER SETTINGS

OTHER SETTINGS
Configuring Sound Settings
You can configure different sounds to play whenever you
turn on the camera, press the shutter release button half-
way or all the way, or perform a key operation.

To configure sound settings

1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the "Set Up" tab, select "Sounds", and
then press [ ].
3.
Use [ ] and [ ] to
select the sound
whose setting you
want to configure, and
then press [ ].
4.
Use [ ] and [ ] to change the setting, and
then press [SET].
To do this:
Select a built-in sound
Turn off the sound
NOTE
• The default sound setting for all operations is "Sound
1".
117
Select this setting:
Sound 1 through Sound 5
Off
