USER MANUAL
ROBOTIC POOL CLEANER
RoadRunner Plus
Model: HJ3172P
READ AND KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Thank you for purchasing Winny® Robotic Pool Cleaner. Please read through the entire manual
before using your new robotic pool cleaner. We are not held liable for any loss or injury caused by
improper use. If you encounter a problem with your Winny® product, please contact your local
dealer for customer services.
MANUFACTURED BY:
TIANJIN WANGYUAN ENVIRONMENTAL PROTECTION AND TECHNOLOGY CO LTD
NO. 30, ZHONGNAN 4
TH
STREET, WEST ZONE, TEDA, TIANJIN, CHINA
Advertisement
Table of Contents
Related Manuals for Winny RoadRunner Plus
Summary of Contents for Winny RoadRunner Plus
- Page 1 Thank you for purchasing Winny® Robotic Pool Cleaner. Please read through the entire manual before using your new robotic pool cleaner. We are not held liable for any loss or injury caused by improper use. If you encounter a problem with your Winny® product, please contact your local dealer for customer services.
-
Page 2: Limited Warranty
Winny®, owned by TIANJIN WANGYUAN ENVIRONMENTAL PROTECTION AND TECHNOLOGY CO LTD makes products at the best quality we are able to offer. All Winny® products have been inspected against defects in materials and workmanship prior to leaving factory. Winny® is happy to offer warranty for the repair or replacement of pool products for one (1) year only for battery, motor and PCB from the date of purchase. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS Failure to comply with the following cautions could cause damage to pool cleaner or personal loss and injury. 1. The cleaner must be operated as specified. 2. To reduce the risk of injury, do not permit children to operate this cleaner. 3. -
Page 4: Table Of Contents
Contents LIMITED WARRANTY..........................1 IMPORTANT SAFETY INSTRUCTIONS....................2 Section 1. Introduction........................4 Section 3. Product Diagram....................... 4 Section 2. Packing List........................4 Section 4. Specifications ........................5 Section 5. Operating Instructions......................6 5.1 Power button and indicator.................... 6 5.2 Turn on the power......................6 5.3 Let it clean........................ -
Page 5: Section 1. Introduction
Section 1. Introduction The robotic pool cleaner HJ3172 Plus is a new type of highly efficient and energy-saving swimming pool cleaning robot. It cleans the pool walls and bottom automatically without replacing the pool water. It is totally environmental-friendly. For safe operation, the cleaner is powered by a rechargeable lithium battery (12.1V, 8.8Ah). Section 2. -
Page 6: Section 4. Specifications
Section 4. Specifications Model HJ3172P Rated input voltage of charger 100VAC-240VAC Rated input frequency of charger 50Hz/60Hz Maximum charging voltage 12.6VAC Charging current 1.8A Battery runtime max. 90min Battery capacity 8800mAh Maximum cleaning surface 150m² Maximum pool depth 180μm Filter density 180μm Running speed max. -
Page 7: Section 5. Operating Instructions
Section 5. Operating Instructions 5.1 Power button and indicator ② Indicator ① Power button Item Function Description Push the button to ON to power on the cleaner; ① Switch to power on/off Push the button to OFF to power off the cleaner 1. -
Page 8: Let It Clean
sure to empty the inside air in order to make the robot work well), then the cleaner can immerse into the pool floor. 5.3 Let it clean The robotic cleaner shall run around the pool floor and wall and vacuum the debris automatically for about 90 minutes until it runs out of battery and stops. -
Page 9: Filter Cleaning
5.5 Filter cleaning 5.5.1 Open the top cover: Put the robot aside the pool and open the top cover (Figure 4-1), the filter basket is located as show in Figure 4-2. Figure 4-1 Figure 4-2 5.5.2 Take out the filter basket (Figure 4-3) Figure 4-3 5.5.3 Wash filter basket (Figure 4-4) 5.5.4 Re-install the filter basket in reverse steps... -
Page 10: Charge The Battery
5.6 Charge the battery 5.6.1 Remove the cleaner from the pool ① Power off (no indictor flashes) the cleaner ② Attach the charging connector to the charging socket. The indicator lamp on the charger shall turn red when charging. It should turn green once fully charged. Charging socket LED Indicator Red - Charging in Progress... -
Page 11: Section 6. Smartphone Control
4. Click on the search button. The app searches for and displays the serial number of the nearest Winny robot. Figure 6-1 5. Click on the Winny serial number displayed on your screen. 6. Set up the pool information and cleaning mode. Shape... - Page 12 7. Push the power button backward to finish the set-up. 8. Power on the cleaner. 9. Synchronize the data to Winny robot after set-up and enter the dashboard interface. Hereafter the program runs every time, you will enter the dashboard interface. You can view and modify the settings.
- Page 13 10. Reset data as below Figure 6-4...
- Page 14 FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
