- Page 1 720 S 850 E Lehi, UT 84043 1-385-248-0777 | 1-888-777-5557 www.ReallyRightStuff.com FH-7240 CINEMA FLUID HEAD © 1990-2019 Really Right Stuff, LLC. All rights reserved.
- Page 2 IN THE BOX (1) FH-7240 FLUID HEAD (1) BENG-5 MOUNTING PLATE 5” WITH SPRING-LOADED SAFETY STOPS (1) TA-LBLP LOW PROFILE LEVELING BASE LOCK KNOB (2) B113 CUSTOM 3/8-16 MOUNTING SCREWS (2) B114 CUSTOM 1/4-20 MOUNTING SCREWS (1) 5/32 HEX KEY (1) FH-7240 USER’S GUIDE...
- Page 3 Introducing the Really Right Stuff FH-7240. Three years in the making, this video fluid head is a culmi- nation of countless hours of research and testing. MEASUREMENTS The FH-7240 combines class-leading performance, high quality, precision, ergonomics, fast setup, and smooth operation seamlessly into one product.
- Page 4 Quick-Release Clamp Key in place while not in use. Tilt Damping Adjustment Wheel Clamp Lever QUICK-RELEASE CLAMP — Lever-release clamp* accepts all Really Right Stuff- Leveling Base Top-Load Release Button compatible plates and rails. Folding Counterbalance Adjustment Crank Arm Spirit Level and Light...
- Page 5 FEATURES CONTINUED CLAMP LEVER — The clamp lever incorporates a Safety Latch. To unlock the clamp for sliding, first push the Safety Latch forward, then swing the lever open. The clamp is fully closed and locked on the quick-release plate when the lever is firmly closed back to its original position and the Safety Latch has clicked back into place.
-
Page 6: Suggested Accessories
ATTACHING THE QUICK-RELEASE PLATE STEP 1 RELEASE THE LOCK LEVER QUICK-RELEASE PLATE STEP 2 The camera must be fitted with DEPRESS THE RED TOP-LOAD RELEASE BUTTON a Really Right Style quick release plate; BENG-5 included. SUGGESTED ACCESSORIES The BENG-8 and Arri-Dvtl-300 mounting plates are available as optional accessories during purchase. -
Page 7: Additional Features
ADDITIONAL FEATURES LEVELING BASE ARRI ROSETTES Loosen the Leveling Base Knob to Any Arri-Compatible M6 Rosette allow for fine leveling adjustment up accessories can be placed on either to 15°. Tightening the knob locks the side of the fluid head. fluid head’s position with the stability of a 100mm bowl. -
Page 8: Troubleshooting
TROUBLESHOOTING PAN OR TILT AXIS FEELS ROUGH TO OPERATE Verify that the pan or tilt axis locks are fully released and in the unlocked positions. It is possible the knobs were inadvertently bumped during operation or movement. THE DAMPING HAS BACKLASH OR A CLICKING FEEL DURING OPERATION Ensure that the damping selector knob is set at the selected number and not partially between numbers. - Page 9 GUARANTEE All Really Right Stuff Brand Products are guaranteed to the original purchaser to be free of defects in materials or workmanship for 5 years from the date of purchase. Products will be repaired or replaced at our option.
