- Page 1 © 1990-2021 Really Right Stuff, LLC. All rights reserved. TRIPOD & MONOPOD USER MANUAL 720 S 850 E Lehi, UT 84043 1-385-248-0777 | 1-888-777-5557...
- Page 2 Office. Any party that manufactures, imports, uses, sells, or offers for sale the patented technology without permission/license from Really Right Stuff, LLC, during the term of the patent and within the country that issued the patent, is considered to infringe the patent.
- Page 3 PRODUCT LINES PRODUCT LINES ASCEND VERSA Our adventure tripod with Versa tripods have a removable an integrated ball head and platform that can be replaced innovative center column. It’s the with a leveling base, quick- best combination of versatility column, or video bowl.
- Page 4 UNIVERSAL FEATURES CNC-Machined Aluminum is durable and anodized to protect against wear. Proprietary Carbon Fiber is rigid, and lightweight. Twist Locks are sealed to minimize fouling and extend their life. Rubber Feet are removable and can be replaced with RRS Rock Claws or Spike Feet (see next page).
- Page 5 Universal / 2 Series 4 Series QD Leg Collar Apex QD Mount TA-3-FRC TA-3-FS Series 1-4 Series 1-4 Rock Claws Foot Spikes Versa Quick-Columns Threaded Leg Collar Series 2 & 3 TA-3-LB-LP TA-3-LC-LP TA-3-LB TA-3-LC TA-3-LB-HK TA-3-LC-HK PF / Knob LR Clamp / Knob PF / 2.5"...
- Page 6 However, never lubricate the carbon fiber legs. with one hand and tighten. • Check for metal corrosion. Contact Really Right Stuff for any necessary replacement parts. • Always keep your tripod in a protective bag when transporting or storing.
- Page 7 Changing Apex Accessories Note: Apex Accessories are only available for Versa Tripods. Your tripod head should first be removed from the mounting stud/platform. Use provided 5/32" hex key to loosen all three SureGrip set screws around Apex. Two rotations are sufficient, complete removal is not required.
- Page 8 Adjust the Set Screw Note: If you tighten the set screw, you will likely mar the bottom of your tripod head. To semi-permanently install your tripod head and avoid using set screws, use one drop of blue or medium strength threadlocker fluid on the stud when you install your head.
- Page 9 Raise Quick-Column Turn the column lock knob counter- clockwise to loosen (about 1/2 turn). Raise the column to the desired height. Turn the column lock knob clockwise to tighten column in place. Remove Quick-Column Loosen the 2 set screws on top of the column with the provided 1/8"...
- Page 10 Photo by Bruce Omori Integrated Head & Apex Features Quick-Release Clamp Spirit Levels enables you to quickly help you level the attach or release any panning clamp or RRS standard dovetail apex. plate. Drop Notch Hex Key Storage is repositionable and Convenient storage allows you to quickly to easily make...
- Page 11 Optional QD Strap & Leg Collar Quick-Release Clamp Carry your tripod easily with a QD strap Open lever to the FULLY OPEN position to top-load your quick- and QD leg collar (sold separately). release plates. To attach a QD swivel, depress the button With your quick-release plate engaged in the clamp, flip the lever to on the QD swivel and insert it into the QD the HALFWAY OPEN position.
- Page 12 Raise Quick-Column Reposition Drop Notch Lift the column lock lever to unlock the When the ball lock lever is loosened, the entire head can be rotated. column. This allows the drop notch to be positioned in any location. Raise the column to desired height. Lock the column in place by pushing lock lever back down.
- Page 13 Reverse Quick-Column Detach Lower Section of Column Turn the safety stop to the OFF position if not already turned off Turn safety stop to the OFF position if not already turned off (See (See Safety Stop Details). Safety Stop Details), lift column lever lock, and remove column completely from apex.
- Page 14 TFCT-ANVIL TRIPODS MONOPODS Features Features 3/8" Mounting Stud securely attaches to monopod heads. Lever-Release Clamp features a dual dovetail that accommodates both RRS plates & Picatinny rails. Ball Head Lever Foam Grip is large and ergonomic for easy for increased comfort. adjustments.
- Page 15 www.ReallyRightStuff.com Product Lines 1-385-248-0777 or TOLL FREE 1-888-777-5557...
