- Page 1 OWNER’S MANUAL WIRED CONTROLLER XK55 Mon 12:30 Cool Func Heat Cool (English) (XK55)
- Page 2 IMPORTANT As with any product that has moving parts or is subject to wear and tear, it is that you maintain your air conditioner and have it regularly VERY IMPORTANT serviced. Accordingly, it is a condition of warranty cover for your air conditioner that you comply with all of the maintenance and service requirements set out in this Manual.
-
Page 3: Table Of Contents
TROUBLESHOOTING ..................35 ERROR......................18 ERROR CODES FOR OUTDOOR UNIT............ERROR CODES FOR INDOOR UNIT MALFUNCTION......ERROR CODES FOR DEBUGGING............STATUS CODES..................MAINTENANCE & SERVICE................MAINTENANCE SCHEDULE ................OPERATION TIPS.................... TROUBLESHOOTING ..................SEELEY INTERNATIONAL – OWNER’S MANUAL SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 4: Introduction & Safety
INTRODUCTION & SAFETY Congratulations on purchasing a new when the Braemar Air Conditioning Unit Braemar Air Conditioner! is used. Note: the manufacturer recommends that low level return air grilles Please keep this Manual and the are installed. Warranty Booklet in a safe place, along with the original purchase IMPORTANT! documents, plus all relevant... -
Page 5: Operation
6. Before operating the air conditioner, please read this manual carefully and keep it in a safe place for future reference. SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 6: Lcd Icons
OPERATION cont. LCD ICONS Display Definition Display Definition Auto Cooling Heating Floor Heating 3D Heating Space Heating Gate-control Comfort (reserved Clean function) E-Heater Error Health Defrost 12-drying Light Left-right Swing Master Indoor unit Memory Absence Rapid Quiet Save Sheild Slave wired Sleep controller Timer... -
Page 7: On/Off
Displaying temperature display Fan speed Display set fan speed display ON / OFF Press the ON/OFF Button to turn the unit on or off. Mon 12:30 Mon 12:30 Heat Heat Func Heat Func Heat Cool Cool SEELEY INTERNATIONAL – OWNER’S MANUAL... - Page 8 OPERATION cont. MODE TEMPERATURE SETTING Under the ON state of the unit, press Press button to increase or the MODE button to switch the decrease setting temperature when operation modes as the sequence the unit is on. Pressing either of them shown below.
-
Page 9: Fan Speed Setting
1. Under drying mode, the fan speed is set to low speed by default and cannot be below. adjusted. 2. Under floor heating mode, the fan speed is invalid. Mon 12:30 Heat Func Heat Cool Mon 12:30 Cool Func Heat Cool SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 10: Function Page
OPERATION cont. FUNCTION PAGE FUNCTION PAGE cont. MORE Press More to enter into more functions operation. Function Rapid Sleep Absence TIMER Press Timer to enter into timer page. Swing Swing More Back Timer View Preset Set to enter into set page. SLEEP FUNCTION VIEW Indoor unit will enter into sleep... -
Page 11: More Function Page
3D space heating mode, turn off the - Press ON to turn on or turn off the air auxiliary heating to save energy. function. - Press to set the air grade level. SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 12: Save Function Page
OPERATION cont. SAVE FUNCTION PAGE FIX ANGLE SWING PAGE Save Swing Position Lower Temp Limit Setting: 16 C Cool Save Cancel Back U & D L & R Home SAVE FUNCTION Set temperature lower limit under cooling or drying mode or temperature upper limit for heating or 3D heating or space heating mode to let the air Swing Position... -
Page 13: Filter Cleaning Page
When the cleaning frequency is “0”, the operation time is 5500 hours. For every level increase this extends the operation time by 500 hours. When the cleaning frequency is “9”, the accumulative operation time is 10000 hours. SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 14: Timer Function Page
OPERATION cont. TIMER FUNCTION PAGE WEEKLY TIMER SETTING PAGE Timer Timer 1 Timer 1 Click Set First On Time Timer 2 08:30 Click Set First Off Time Timer 3 17:30 Click Set First Repeat: No > Auto Off After 0.5 hrs Back Home Cancel... -
Page 15: Time Setting Page
Press the 12-hour time to toggle Use the buttons to adjust the values. between 24 hour or 12 hour time. - Press the semi-circle button to the right to change between AM and PM. Press OK to confirm. SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 16: Setting Page
OPERATION cont. SETTING PAGE ENGINEERING SETTING PAGE Project Setting Backlight Time > Date & Time > Master Wired Controller Brightness > Project Setting > Master IDU Sound > About Unit > Parameter View > Language > Hotline > Parameter Setting >... -
Page 17: Parameter Setting
Auto Temp setting temperature Automatic Automatic heating heating Clear Filter Cleaning Clear, not not clear Time clear cooling cooling Fresh Air IDU Output It is only applicable for new duct indoor heating heating Temp* units. SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 18: Parameter View
OPERATION cont. PARAMETER VIEW Parameter name Display scope Parameter name Display scope Number of IDUs 1~16 Filter Dirty Alarm Actual value cool only, heat Max Distribution 135% 150% 110% Cool & Heat Modes only, cool & heat, Ratio Wired Controller's Master IDU's Project No. -
Page 19: View Page
After removing the door card, the system will memorise the settings and resume operation once the door card has been inserted. The symbol for pulling out the card will be displayed, neither the remote control or wired controller will be respsonsive. SEELEY INTERNATIONAL – OWNER’S MANUAL... - Page 20 ERROR cont ERROR CODES FOR OUTDOOR UNIT When there is any abnormalities occur during system operation, the main interface of wired controller will show multifunction icon, the specific code and indoor units located so as to let you understand the operation status of air conditioner at first time.
- Page 21 Defrosting Current sensor Fan driver board temperature abnormality of operation sensor 1 compressor 5 abnormality malfunction Defrosting Current sensor Supply voltage temperature abnormality of protection of fan sensor 2 compressor 6 driver board malfunction SEELEY INTERNATIONAL – OWNER’S MANUAL...
-
Page 22: Error
ERROR cont. ERROR CODES FOR INDOOR UNIT MALFUNCTION Code Description Code Description Code Description Inconsistent series Indoor unit of indoor units for Humidity sensor malfunction one controlling malfunction multiple units Indoor fan Severe turbidity of Water temperature protection air quality alarm sensor malfunction Mismatching of Auxiliary heating... -
Page 23: Error Codes For Debugging
Target low pressure Vacuum pumping mode modification High temperature prevention under heating mode Defrosting temperature n i l adjustable value Clean the long-distance shielding order of indoor unit SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 24: Maintenance & Service
MAINTENANCE & SERVICE with other debris that may build up AIR FILTER over time, namely, leaves and the like. It is important to check and clean the air filter as per the Maintenance Schedule below. A dirty air filter will not REFRIGERANT allow the correct amount of clean air to pass through your air conditioner,... -
Page 25: Maintenance Schedule
Braemar Ducted Inverter Air Conditioning Unit as per the items and frequency set out in the Schedule, and as indicated elsewhere in this Manual. SEELEY INTERNATIONAL – OWNER’S MANUAL... -
Page 26: Operation Tips
OPERATION TIPS MAIN COMPONENTS OPERATION TIPS The following events may occur during normal operation: The following events may occur during normal operation: 1. Protection of the air conditioner. INDOOR UNIT 1. Protection of the air conditioner. Compressor protection Compressor protection •... -
Page 27: Troubleshooting
Remedy LCD ICONS Problem Probable Cause Remedy 1. The air conditioner Seeley International strives for continuous product improvements, therefore specifications are subject to change 1.1 Power failure. 1.1 Wait for power to resume. Icons Introduction 1. The air conditioner 1.1 Power failure. - Page 28 It is the policy of Seeley International to introduce continuous product improvements. Accordingly, specifications are subject to change without notice. Please consult with your dealer to confirm the specifications of the model selected. Warranty Service Refrigerated Cooling 1300 526 477 seeleyinternational.com...
