ZyXEL Communications PMG1006-B20A Quick Start Manual

Quick Start Guide
Hardware Connections
An installation technician must have already
connected the fiber optic cable. See the Fiber
Connection section on the next page for more
1
information
Warning! To avoid possible eye injury, do NOT
look into an operating fiber-optic module's
connector.
Connect computer using an Ethernet cable.
2
Connect power and press the power button.
3
Make sure the LEDs are on and check the
PON LED.
4
Declarations
EU Importer: ZyXEL Communications A/S∣Generatorvej 8D, 2730 Herlev∣http://www.zyxel.dk
1/2
US Importer: ZyXEL Communications, Inc∣1130 North Miller Street Anaheim, CA 92806-2001∣http://www.us.zyxel.com
GPON SFU with 4-port GbE Switch
1
INTERNET
4
PON
PON connected and registered.
GREEN
PON
PON not connected. Turn off, disconnect power,
and repeat hardware connection steps.
RED
www.zyxel.com
