1.50 Release Note/Manual Supplement
Date: August 17, 1998
This Release Note/Manual Supplement contains information about the new features, and bug
fixes since the incremental release v1.42(B.03I).
The New Features section lists the new features added to this release. Please read through the
Enhancement Details section for detail information. A new section, Changes not Compatible
to Previous Versions, is added to this release notes. It is important to read it too.
1 New Features
SUA Enhancements
In this release, SUA has been enhanced to support the popular applications: Microsoft's
tracert under Windows9x and Windows NT, CuSeeMe, IRC, RealAudio, VDOLive,
Quake, and PPTP. Besides above, multiple SUA servers are supported.
Advanced ISDN Features
ISDN Supplementary Services are supported in this release. These services work
properly only if the needed functions subscribed from the Telephone Company or PTT.
B-channel, CLID, and WAN IP Address Shown on Menu 24.1
B-channel, CLID, and WAN IP address are shown on Menu 24.1. Due to the space
limitation in Menu 24.1, Menu 24.1 has been separated into to two screens. The original
static information in Menu 24.1 has been moved to Menu 24.2.1. Now, Menu 24.1 only
displays the dynamic information.
2 Changes not Compatible to Previous Versions
2.1 ISDN EPA Mechanism is Moved to PC
The CI (Command Interpreter, menu 24.8) command, "isdn ana display", is disabled in this
release. A new CI command "sys epalog" is added for displaying the ISDN raw trace data. "isdn
ana display" could not work with Telnet before, but "sys epalog" works fine with Telnet. So you
do not have to rely on terminal emulator via serial port to capture the ISDN trace any more.
A new DOS tool - epapc, will be used to decode the ISDN raw trace data into meaningful Q.921
and Q.931fields. epapc is part of this release. If you have difficulties to run epapc, please send
the raw ISDN trace to ZyXEL support for decoding. The proper steps to take the raw ISDN trace
are:
1. type "isdn analyzer on"
2. try your ISDN call now
3. after failed ISDN connection type "isdn analyzer off"
4. Type "sys epalog"
5. Start to capture the data displayed on the screen
1
ZyXEL Prestige P128
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZyXEL Communications DES-5004
Summary of Contents for ZyXEL Communications DES-5004
-
Page 1: New Features
ZyXEL Prestige P128 1.50 Release Note/Manual Supplement Date: August 17, 1998 This Release Note/Manual Supplement contains information about the new features, and bug fixes since the incremental release v1.42(B.03I). The New Features section lists the new features added to this release. Please read through the Enhancement Details section for detail information. -
Page 2: Supported Platforms
6. Type <CR> to show the raw ISDN trace on screen 7. Press <space bar> to keep Prestige displaying the trace until hit end 8. Stop the capturing mechanism 2.2 Busy Tone Generated after Far-end Hanging up In the previous releases, Prestige kept silent after far-end hanging up the phone. In this release, Prestige generates busy tone after far-end hanging up. - Page 3 SMTP DNS (Domain Name Server) www-http (Web) PPTP 4.2 Advanced ISDN Features Supplemental Services are supported for North American and DSS-1 switches. The relationship among the advanced ISDN features and switch types is: IP Address ----------------- 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0...
- Page 4 Reminder Ring on the Prestige POTS ports. There are services on the serving Central Office switch that works in cooperation with the Prestige software must first be enabled. These services usually are extra charges in addition to your monthly payment.
- Page 5 Menu 2 - ISDN Setup Switch Type= xyz B Channel Usage= Switch/Switch 1st Phone #= 5552000 SPID #= 0555200001 Incoming Analog Call= Phone 1 2nd Phone #= 5554000 SPID #= 0555400001 Incoming Analog Call= Phone 2 Advanced Setup = No...
- Page 6 DN-2 is used to place the out data call, and the preferred B-channel is B2. We have to emphasize that the above selection is only a preference. Switch may reject the B- channel request; and different DN is used because the desired Directory (Phone) number used by other call.
- Page 7 Then answer the incoming call. Hang up on the current active call and switch back to the other call – hang up the phone and wait for the phone to ring. Then pick up the phone to return to the other call.
- Page 8 4.2.2.7 Call Forwarding The Call Forwarding feature is supported by ISDN switch directly. The Call Forwarding feature of the POTS port can be activated and deactivated by using the phone set. The Call Forwarding is a telephone feature and will not impact incoming data call. Please request your phone company...
- Page 9 for the instruction activate or deactivate the Call Forwarding feature. Here is the instruction written in Custom Calling Service section of Pacific Bell White Pages: To turn on, press 72#. At the dial tone, enter the number you want your calls forwarded to. If the line is busy or does not answer, repeat the above process and it will be activated even if the line is still busy.
-
Page 10: Bug Fixes
Menu 24.2.1 - System Maintenance - Information Name: 1.5FCS Routing: IP/IPX RAS S/W Version: V1.50(B.00) | 8/17/98 ISDN F/W Version: V 07f Country Code: 255 Ethernet Address: 00:a0:c5:40:00:ee IP Address: 204.237.202.151 IP Mask: 255.255.255.192 DHCP: None Menu 24.1 only displays the dynamic information now. The B-channel instead of the logical channel is shown under CHAN now. - Page 11 22. For eliminating new user's confusion on entering ISP's IP address. ISP IP Addr field in Menu 4 is removed. 23. For Denmark ISDN switch, the right ring frequency has now been set in the A/B ports defaults. You need no longer manually enter the CI command "isdn set initstring s121=2" as in the past.
- Page 12 Application notes: Call waiting support Setup: User set DN1 ( “ Phone #” 2) to Phone2. In Menu2.1, all Access Codes are set correctly according to the local Telco switch. The “ Preferred Phone # for 1st Out Data Call”...
- Page 13 If the behavior of the Prestige is different for different switch type, we will also mention it in this example. POTS-1 Prestige (DN1) xxx0101 Menu 2 - ISDN Setup...
- Page 14 Phone Ring / Dial tone Phone 2. Two data connections up Two data connections could be to the same destination or to different destination. Therefore, we discuss two different cases here. (1) Both channels are connected to user’s ISP. When a voice incoming call to any DN, one data connect will be bumped, and the corresponding phone will ring.
- Page 15 DN2, user will hear ring from Phone2. For incoming voice call to DN1, the result will depend on the switch type. For AT&T NI-1, the call can be ‘rolled over’, so Phone1 will ring and user can answer it. For other switch type, since the switch can’t do rollover, so the switch won’t accept Prestige use DN2 to answer calls to DN1, the caller will hear busy tone.
- Page 16 Phone Ring / Dial tone (2) OTHER SWITCH TYPE: CASE 1: An incoming voice call to the DN that’s been used by a data connection can not be rolled over, and therefore, the caller will hear busy tone. Action 1...
- Page 17 Action 1 Call to DN2 / Offhook phone 2 Phone Phone Caller get busy tone / Busy tone (2) phone 2 (DN2) is used to connect to “peer”, and then a data call is triggered to ISP (DN1). Action 1 Call to DN1 / Offhook phone 1 Phone...
